TASKalfa 351ci

PRINT COPY SCAN FAX

PRINT COPY SCAN

ECOSYS M6230cidn

ECOSYS M6235cidn Card Authentication Kit (B)

OPERATION GUIDE

PRINT COPY SCAN FAX

ECOSYS M6630cidn

ECOSYS M6635cidn

Card Authentication Kit (B) Operation Guide

Introduction

Thank you for purchasing our Card Authentication Kit (B).

This product enables you to use the ID card user

authentication system.

Precautions

To install the optional function, you need the License Key.

Please access the designated website of your dealer or

service representative, and register “Machine No.”

indicated on your machine and “Product ID” indicated on

the License Certificate supplied with the product to issue

the License Key.

For ID card reading, refer to the instructions of the card

reader.

For User Login setting and user registration, refer to User

Authentication and Accounting (User Login, Job

Accounting) in the Operation Guide of the machine.

To make local authentication using your ID card, you need

to register the ID card information in the Local User List you

are pre-registered on. For registration procedure, refer to

the To register the ID card information.

To make network authentication using your ID card, you

need to install the KYOCERA Net Manager on the network

authentication server. Register the user from the server and

enter the ID card's ID number. Refer to the KYOCERA Net

Manager Install Manual for details.

Activation of Card Authentication Kit(B)

Activate the ID CARD from the operation panel on the

machine.

1 Press the System Menu/Counter key and then press

[System/Network]. If user login administration is

disabled, the user authentication screen appears. Enter

your login user name and password and then press

[Login]. For this, you need to log in with administrator

privileges.

2 Press [Optional Function].

3 The optional function screen is displayed. Select CARD

AUTHENTICA... and press [Activate].

4 Select [Official] and press [Next].

NOTE: To use the application as a trial, select [Trial] without

entering the license key.

5TheLicense Key entry screen is displayed. Enter the

License Key using the numeric keys and press [OK].

6 The confirmation screen appears. Confirm the product

name CARD AUTHENTICATION KIT(B) and press

[Yes].

Setting User Login

Make the settings of Local Authentication or Network

Authentication of User Login in User Login/Job Accounting

on the machine.

NOTE: For User Login setting, refer to User Authentication

and Accounting (User Login, Job Accounting) in the

Operation Guide of the machine.

When you enable User Login on the machine, you need to

make the setting of user account for the printer driver in

order to print by the computer. For details, refer to the

Printer Driver User Guide, Device Settings, and

Administrator Settings.

Registering/deleting the ID card

information

The procedures below are to register or delete the card

information of a pre-registered user.

For new registration or change of user information on Local

User List, refer to Management in the Operation Guide of

the machine.

To register the ID card information

To login using the ID card, you need to register the ID card

information in the user information.

Follow the steps below.

1 Press the System Menu/Counter key.

NOTE: If Local Authentication has been set in User Login,

the ID Card Login screen appears. Refer to Login on the

back side or the procedure of Keyboard Login, and login

using the ID card registered with administrator privileges or

using the login user name.

To enter your login user name and login password, refer to

the machine's Operation Guide.

2 Press [User Login/Job Accounting].

NOTE: If User Login is disabled, the ID Card Login screen

appears. Refer to Login on the back side or the procedure

of Keyboard Login, and login using the ID card registered

with administrator privileges or using the login user name.

To enter your login user name and login password, refer to

the machine's Operation Guide.

3 Press [User Login Setting] and then press [Local User

List].

4 Select the user for whom you wish to register the ID

card information, and press .

5 Press or , and then press [ID Card info.].

6 Hold the ID card to be registered over the card reader,

and then press [OK]. When Completed. appears on the

screen, press [OK]. The screen returns to the Detail

menu.

7IntheDetail menu, press [Save]. The confirmation

screen appears.

8 Press [Yes]. The ID card information is now registered.

To delete the ID card information

You can delete the ID card information registered in the

user information.

Follow the steps below.

1 Perform the step 1 to 3 of To register the ID card

information.

2 Select the user from whom you wish to delete the ID

card information, and press .

3 Press or , and then press [ID Card info.].

4 Press [Delete].

5 In the confirmation screen, press [Yes] and then press

[OK]. The screen returns to the Detail menu.

6 In the Detail menu, press [Save]. The confirmation

screen appears.

7 Press [Yes]. The ID card information is now deleted.

Connecting the USB cable

Connect the USB cable of ID card reader to the USB

memory slot on the machine.

After installing the Card Authentication Kit (B) and setting

User Login, Use ID card to login. will appear when you use

the machine.

To login, hold the ID card over the ID card reading part.

Caution: Do not attempt to read two ID cards at once.

NOTE: When Additional Authentication is set to Use

Password, the Login Password is entered after

authentication using the ID card. For the setting procedure,

refer to Additional Authentication.

Keyboard Login

You can login by entering the login user name and login

password without using the ID card.

NOTE: You can make the login permission or prohibition

setting. For the setting procedure, refer to Keyboard Login

setting.

Follow the steps below.

1 Select the [Menu] in the ID card login screen.

2 Press [Keyboard Login].

3 Enter the login user name and login password, and

then press [Login].

NOTE: To return to the ID Card Login screen, press [ID

Card Login].

Logout

After completing the procedure, press the Logout key on

the control panel.

Keyboard Login setting

You can make the Keyboard Login permission or prohibition

setting.

Follow the steps below.

1 Press the System Menu/Counter key.

NOTE: If Local Authentication has been set in User Login,

the ID Card Login screen appears. Refer to Login or refer to

the procedure of Keyboard Login, and login using the ID

card registered with administrator privileges or using the

2 Press [User Login/Job Accounting].

NOTE: If User Login is disabled, the ID Card Login screen

appears. Refer to Login or refer to the procedure of

Keyboard Login, and login using the ID card registered with

administrator privileges or using the login user name.

3 Press [User Login Setting] →[ID Card Setting], and

then press [Keyboard Login].

4 Press [Permit] or [Prohibit].

5 Press [OK].

Additional Authentication

This sets whether or not to require the entry of a Login

Password after authentication using an ID card. When set

to Use Password, the Login Password entry screen is

displayed after the ID card is authenticated.

Follow the steps below.

1 Press the System Menu/Counter key.

NOTE: If Local Authentication has been set in User Login,

the ID Card Login screen appears. Refer to Login or refer to

the procedure of Keyboard Login, and login using the ID

card registered with administrator privileges or using the

2 Press [User Login/Job Accounting].

NOTE: If User Login is disabled, the ID Card Login screen

appears. Refer to Login or refer to the procedure of

Keyboard Login, and login using the ID card registered with

administrator privileges or using the login user name.

3 Press [User Login Setting] →[ID Card Setting], and

then press [Additional Authentication].

4 Press [Off], [Use Password] or [Use PIN].

NOTE:To use PIN code authentication, you must enable

network authentication and set the server type to [Ext.].

For details, refer to the machine's Operation Guide.

Responding to Error Messages

If the panel displays any of these message, follow the

corresponding procedure.

Error Message Corrective Actions

Cannot recognize. Make sure your ID card has been

registered.

This ID card is

already registered to

another user.

Your ID card has already been

registered. Change it to another ID

card.

Cannot read data in

this ID card.

In registration process, the ID card

information was not read correctly. Hold

again the ID card over the ID card

reading part.

If the same message still appears, the

ID card may not be compatible with this

product. Change it to another ID card.

2017.12

3MT2V1KDEN1
