Kyocera KM-C3130 Manuale utente

OPERATION GUIDE

(Advanced Operations)

Please read the Operation Guide before using

the copier.

Keep it close to the copier for easy reference.

4581-7773-01

KM-C2030

KM-C3130

Contents

Introduction

Structure of the Manual

This manual is divided into three parts: Administrator Operations, Basic Opera-

tions and Advanced Operations.

The Administrator Operations volume of this User Manual contains precautions

on the use of this copier. Be sure to read this volume before using the machine.

The Basic Operations and Advanced Operations volumes of the User Manual

contain information on the many functions available. After reading the User

Manual, be sure to store it in a safe place for future reference.

GAdministrator Operations

This volume provides precautions for using the machine, descriptions on func-

tions for use by the administrator (Utility Mode and Administrator Mode func-

tions), procedures for replacing parts and supplies, troubleshooting procedures

and machine specifications. Before using the copier, be sure to read chapters 1

through 4 of the Administrator Operations volume.

GBasic Operations

This volume contains precautions for using the machine and descriptions on the

procedures for basic operations. The Basic Operations volume is a quick refer-

ence for immediate use of the copier.

GAdvanced Operations

This volume includes descriptions on the Auxiliary functions in addition to pre-

cautions for the use of the copier. Read the Advanced Operations volume for

more information on the various functions that this copier provides for any need.

Contents

The topics listed below are described in the “Advanced Operations” volume.

For details on other topics, refer to the “Administrator Operations” volume and

the “Basic Operations” volume.

Available Features

“Color Image Adjust” Function...................................................... 4

“Creation” Functions .................................................................... 18

1 Auxiliary Functions

1.1 Improving Color Copy Quality

(“Color Image Adjust” Function) ................................................ 1-2

To make color adjustments ............................................................ 1-2

To make test prints ......................................................................... 1-4

To adjust the “Brightness” parameter ............................................. 1-5

To adjust the “Contrast” parameter ................................................ 1-5

To adjust the “Saturation” parameter.............................................. 1-6

To adjust the “Sharpness” parameter............................................. 1-6

To adjust the “Red” parameter ....................................................... 1-7

To adjust the “Green” parameter .................................................... 1-7

To adjust the “Blue” parameter....................................................... 1-8

To adjust the “Color Balance” parameter ....................................... 1-9

To adjust the “Portrait” parameter ................................................ 1-10

To adjust the “Hue” parameter ..................................................... 1-10

To adjust the “Density” parameter ................................................ 1-11

1.2 Editing Images (Creation Functions)........................................ 1-12

To set a Creation function ............................................................ 1-12

To make settings for the “Monotone” function .............................. 1-14

To make settings for the “Background Color” function ................. 1-15

To make settings for the “Color Separation” function ................... 1-16

To set the “Neg. Pos. Reverse” function ...................................... 1-16

To make settings for the “Multi-Page Enlargement” function ....... 1-17

To make settings for the “Mirror Image” function.......................... 1-21

To make settings for the “Postcard” function................................ 1-23

1.3 Making Copies for Filing (“File Margin” Function).................. 1-25

To make settings for the “File Margin” function ............................ 1-25

1.4 Erasing Sections of Copies (“Edge/Frame Erase”

Function) ..................................................................................... 1-27

To make settings for the “Edge/Frame Erase” function................ 1-27

Contents

iii

1.5 Adjusting the Image To Fit the Paper Size

(“Image Adjust”Function) .........................................................1-30

To make settings for the “Image Adjust”function..........................1-30

1.6 Tiling Copies (“Image Repeat”Function) .................................1-32

To make settings for the “Image Repeat”function ........................1-32

1.7 Inserting Pages Between Copies of Transparencies

(“OHP Interleaving”Function) ...................................................1-34

To make settings for the “OHP Interleaving”function ...................1-34

1.8 Storing the Scanned Image in the Memory

(“Scan to Memory”Function) ....................................................1-36

To set the “Scan to Memory”function ...........................................1-36

To combine scanned data saved in the memory ..........................1-36

To delete scanned data from the memory (to print stored data) ...1-37

1.9 Scanning the Document in Separate Batches

(“Separate Scan”Function) .......................................................1-38

To set the “Separate Scan”function .............................................1-38

1.10 Printing Control Numbers on Copies

(“Distribution”Function)............................................................1-40

To make settings for the “Distribution”function.............................1-40

2 Scanning Operations

2.1 Available Scanning Features .......................................................2-2

Function Descriptions......................................................................2-2

Operation Description .....................................................................2-3

Contents

Administrator Operations

For details on the following topics, refer to the Administrator Operations

volume of this User Manual.

1Introduction

2 Safety Information

3 Precautions

4 Part Names and Their Functions

5 Utility Mode Operations

6 Touch Panel Messages

7 Troubleshooting

8 Appendix

Basic Operations

For details on the following topics, refer to the Basic Operations volume of

this User Manual.

1 Before Making Copies

2 Basic Copy Operations

3 Loading Paper

4 Original Documents

5 Specifying Copy Settings

6 Controlling Jobs

Available Features

This chapter contains many useful copy samples that will give you a better understanding

of the wide range of applications for the various functions available with this full-color

copier. These functions are explained in an easy-to-understand way using the many

copy samples.

For more details on the operating procedures for these functions, refer to chapter 1

“Auxiliary Functions”.

Available Features

*Since the copy samples provided in this chapter were printed with photoengraving, they may slightly differ in

color with actual color copies.

Contents

o n t e n t s

“Contrast”

Parameter

“Sharpness”

Parameter

“Hue”

Parameter

“Brightness”

Parameter

“Saturation”

Parameter

“Red”

Parameter

“Blue”

Parameter

“Color Balance”

Parameter

“Density”

Parameter

Adjusts the vividness

Adjusts the level of red

Adjusts the level of blue

Adjusts the concentration of

cyan, magenta, yellow and black

Adjusts the copy density

Adjusts the difference between

highlights and shadows

Adjusts the sharpness of text

Adjusts the level of green

Adjusts the tint of fresh color Adjusts the color

. . . . . . p.14

. . . . . . . p.6 . . . . . . p.13

. . . . . . p.15

. . . . . . . p.9 . . . . . . p.16

General Information

About Color . . . . . . p.12

. . . . . . p.17

“Color Image Adjust” Function

. . . . . p.4,5

“Portrait”

Parameter

. . . p.10,11

(CMYBK color adjustment)

Adjusts the brightness

“Green”

Parameter . . . . . . . p.7

. . . . . . . p.8

Contents

“Creation” Functions

“Monotone”

Function

Copies using only one selected color (monotone)

Copies with the selected background color

“Color Separation”

Function

Copies while separating the four CMYK colors

“Neg. Pos. Reverse”

Function

Copies with the light-colored areas and the dark-

colored areas of the image inversed

Prints multiple copies of the document, reduced

to postcard size, on a single sheet of paper

Prints a mirror image of the original

Splits an enlargement of the document and copies

each part onto a separate page

“Postcard”

Function

“Mirror Image”

Function

“Multi-Page

Enlargement”

Function

“Background Color”

Function

. . . . . p.18

. . . . . p.19

. . . . . p.20

. . . . . p.21

. . p.22

. . . . . p.22

. . p.23

General Information

About Color

Everybody has an idea of what hue an object has, for example, an apple is

red, a lemon is yellow, and the sky is blue. Hue is the tint by which the color of

an object is classied as red, yellow, blue, etc.

Brightness is the degree of lightness in a color,

as compared with another color, which makes

it a light color or a dark color. For example,

when comparing the yellow of a lemon and

the yellow of a grapefruit, it is obvious that the

yellow of the lemon is brighter. But what about

when comparing the yellow of a lemon and the

red of a bean? Obviously, the yellow of the

lemon is brighter. Brightness is this degree of

lightness that enables comparison regardless of

the hue.

What makes the difference between the

yellow of a lemon and the yellow a pear? By

saying that the lemon is a more vivid yellow

and the pear is a duller yellow, the difference

between the two colors is stated in terms

of saturation, as opposed to brightness. As

opposed to hue and brightness, saturation is

the characteristic that indicates the degree of

vividness.

What is

saturation?

What is hue?

General Information About Color

Darker

What is

brightness?

Lighter

More vivid

Duller

General Information

About Color

“Color Image Adjust” Function

Figure 2

White

Brightness

Black

White

Brightness

Saturation

Hue

Black

Hue, brightness and saturation are the elements that we call the “three attributes of color”. We can

think of their affects using the solid object shown in gure 1, where the outer edge is the hue, the

vertical axis is the brightness, and the horizontal axis from the center is the saturation.

Assigning colors to the solid object, representing the three attributes of color, shown in gure 1

produces the color model shown in gure 2. Although the level of saturation differs for each hue

and degree of brightness, creating a complex color model, we can get a better understanding of

the conditions under which the hue, brightness and saturation vary.

Color model

Figure 1

Relationship between hue, brightness and saturation (color model)

Altri manuali per KM-C3130

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Kyocera Stampante tutto in uno

Kyocera

Kyocera ECOSYS P6035cdn Manuale utente

Kyocera

Kyocera FS-1118MFP Manuale utente

Kyocera

Kyocera KM-2050 Istruzioni per il montaggio

Kyocera

Kyocera TASKalfa 620 Manuale utente

Kyocera

Kyocera ECOSYS MA2100cwfx Manuale utente

Kyocera

Kyocera ECOSYS M6035cidn Manuale utente

Kyocera

Kyocera TASKalfa 2551ci Manuale di installazione e funzionamento

Kyocera

Kyocera KM-C2230 Manuale utente

Kyocera

Kyocera TASKalfa 255 Manuale utente

Kyocera

Kyocera TASKalfa 3500i Manuale di installazione e funzionamento

Kyocera

Kyocera TASKalfa 7002i Manuale utente

Kyocera

Kyocera 1815 Istruzioni per il montaggio

Kyocera

Kyocera ECOSYS M2835dw Manuale utente

Kyocera

Kyocera FS-C1020MFP Manuale utente

Kyocera

Kyocera TASKalfa 250ci Manuale utente

Kyocera

Kyocera TASKalfa 3501i Manuale utente

Kyocera

Kyocera C5020N - FS Color LED Printer Manuale utente

Kyocera

Kyocera TASKalfa 8000i Manuale di installazione e funzionamento

Kyocera

Kyocera ECOSYS FS-6525MFP Manuale

Kyocera

Kyocera TASKalfa 3050ci Manuale utente

Kyocera

Kyocera ECOSYS M6035cdn Manuale utente

Kyocera

Kyocera TASKalfa 180 Manuale utente

Kyocera

Kyocera FS-1028MFP DP Manuale utente

Kyocera

Kyocera ECOSYS FS-1135MFP Manuale utente

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Canon

Canon ImageCLASS 2300 Manuale

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente
