Kyocera Duraxa Manuale utente

5KKTI22KFNRX-

Printed in Mexico

U.S. Cellular®Customer Care

1-888-944-9400

quick start guide

DuraXA

Quick Start Guide for the

KYOCERA DuraXA

Get Started 2

Important Safety Information 15

Manufacturer’s Warranty 29

End User License Agreement 32

the property of their respective owners.

This product contains NetFront Browser of ACCESS CO., LTD. ACCESS and NetFront are trademarks or registered trademarks of ACCESS

CO., LTD. in Japan and other countries. This software is based in part on the work of the Independent JPEG Group.

The

Bluetooth

®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Kyocera

Corporation is under license. Other trademarks and trade names are those of their respective owners.

Get Started 2

♦Your KYOCERA DuraXA (page 2)

♦Get Your Phone Ready (page 3)

♦Use Your Phone (page 6)

♦U.S. Cellular Customer Support (page 13)

♦Notes (page 14)

This section introduces you to the basics of getting started with your

KYOCERA DuraXA. Visit http://www.uscellular.com/ for the complete

User Guide and additional information.

Get Started

Your KYOCERA DuraXA

< Front Open > < Top >

< Bottom >

Main Screen

Softkeys

Navigation

Key

MENU/OK Key

CAMERA Key

SEND Key

CLEAR Key

SPEAKER Key

END/POWER Key

Keypad

Smart Sonic

Receiver (internal)

Call List Button

External Speaker

Button

Speaker

3 Get Started

Install the Battery

1. Using a coin, rotate the battery cover screw in a counter-

clockwise direction as far as it goes (1).

Note: The battery cover screw is permanently mounted on the

cover and cannot be removed.

2. Insert your thumbnail or fingernail into the slot and lift the

battery cover gently (2).

3. Insert the battery, contacts end first, and gently press the

battery into place (3).

< Sides >

< Back >< Front Closed >

Outer Screen

Flash

Secondary

Microphone

Primary

Microphone

Camera Lens Internal

Antenna

SIM Card

Slot (internal)

Battery Cover

Screw

microSD Card

Slot (internal)

Volume Button

USB/Charging

Port

Headset Jack

Get Your Phone Ready

31 2

Get Started 4

4. Replace the battery cover, making sure all the tabs are

secure and there are no gaps around the cover (4).

5. Using a coin, rotate the battery cover screw in clockwise

direction until the cover locks (5).

Charge the Battery

Important: Before turning on your phone, fully charge the

battery. Be sure to use the charger that came with

your phone.

1. Open the cover to the USB/charging port on the left side of

the phone.

2. Plug the smaller end of the micro-USB cable into the

phone’s USB/charging port.

3. Plug the other end of the USB cable into the charger, and

then plug the charger into an electrical outlet.

4. When charging is complete, remove the cable from the

port and close the cover. Press around the edges of the

cover to ensure that it is securely closed.

Warning:Be sure all ports and covers are properly sealed to

maintain the phone's waterproof capability.

5 Get Started

Insert the microSD Card

A microSD™ card is an optional accessory that allows you to store

images, videos, music, documents, and voice data.

1. Remove the battery cover and the battery.

2. Slide the card holder in the direction of the arrow to unlock

it (1).

3. Raise the card holder with your finger (2).

4. Insert a microSD card into the holder. Make sure to check

the position of the gold terminals (3).

5. Gently press the card and the card holder (4), and then

slide the holder in the direction of the arrow to lock it (5).

6. Place the battery back into its compartment and replace

the battery cover.

Warning:Make sure you lock the battery cover properly to

maintain the phone's waterproof capability.

Turn the Phone On

Press to turn your phone on.

Turn the Phone Off

Press and hold to turn the phone off.

31 2

Gold Terminals

microSD Card Holder

Get Started 6

Voicemail

Set Up Your Voicemail

All unanswered calls are automatically transferred to your

voicemail, even if your phone is in use or turned off. You should

set up your voicemail and personal greeting as soon as your

phone is activated:

1. Press and hold in standby mode.

2. Follow the voice prompts to create your password and

record your name and greeting.

It is strongly recommended that you set a voicemail password.

Without a password, anyone who has access to your phone can

access your messages.

Retrieve Your Voicemail

Press and hold in standby mode.

From any other phone:

1. Dial your wireless phone number.

2. When your voicemail answers, press the asterisk key (*).

3. Enter your password.

Phone Calls

Make a Phone Call

1. Enter a number from standby mode.

2. Press to delete one or more digits.

3. Press , , or the external speaker button.

4. Press when you are finished.

Answer an IncomingCall

Press to answer an incoming call.

When the phone is closed, open the phone to answer an

incoming call.

Use Your Phone

7 Get Started

In-Call Options

Pressing OPTIONS(right softkey) during a call displays a list of

available in-call features. To select an option, highlight the option

and press .

●Transfer Audio to switch the call to a Bluetooth device (if

applicable).

●Save to save the current call’s phone number in your

Contacts.

●Contact Detailsto display information about the caller stored

in your Contacts.

●Main Menu to display the phone’s main menu.

●3-Way Call to open a call with two other parties.

●Contactsto display your Contacts list.

●Phone Info to display information about your phone.

Further options may also be available:

Press MUTE/UNMUTE (left softkey) to mute/unmute the

microphone.

Press the volume button up or down to adjust the receiver

volume.

Press or the external speaker button to turn the

speaker on. Press again to turn it off.

Warning:Because of higher volume levels, do not place the

phone near your ear during speakerphone use.

Display Settings

Change the Wallpaper

1. Press > Settings > Display > Wallpaper.

2. Select a wallpaper option by pressing the navigation key up

or down, and select a wallpaper.

Get Started 8

SoundSettings

Adjust the Volume

1. Press > Settings > Volume.

2. Select IncomingRingtone, Playback Volume, Power

Up/Down, Key Beeps, or E911 Alert.

▪If you select Power Up/Down or E911 Alert, select On

or Off.

▪If you select Key Beeps, select Tone Volume or Tone

Type.

3. Select a volume level and press .

Tip: You can adjust the ringtone volume in standby mode or

during an incoming call and the volume during playback by

using the volume button.

Mute All Sounds

Press and hold the volume button down in standby mode to

activate Silence All. (The screen will display “Silence All.”)

Press the volume button up repeatedly to deactivate Silence

All and select a volume level.

Select Ringtonesfor IncomingCalls/Messages

1. Press > Settings > Ringtones> IncomingCallsor

Messages.

2. Select Contacts, UnsavedNumbers, or Private /

Unknown.

▪If you select Contacts, select All Contacts, or select

One Contact, and then select an entry.

3. Select a ringtone option by pressing the navigation key up

or down, and then select a ringtone.

Select Ringtonesfor Voicemail, Calendar, andPower Up/

Down

1. Press > Settings > Ringtones.

2. Select Voicemail, Calendar, or Power Up/Down.

3. Select a ringtone option by pressing the navigation key up

or down, and then select a ringtone.

9 Get Started

Select Vibrate Type for IncomingCallsandMessages

1. Press > Settings > Others> Accessibility >

Vibrate Type > IncomingCallsor Messages.

2. Select Contacts, UnsavedNumbers, or Private /

Unknown.

▪If you select Contacts, select All Contacts, or select

One Contact, and then select an entry.

3. Select a vibrate type option by pressing the navigation key

up or down, and then select a vibrate type.

Select Vibrate Type for Voicemail andAlarm/Calendar

1. Press > Settings > Others> Accessibility >

Vibrate Type.

2. Select Voicemail or Alarm/Calendar.

3. Select a vibrate type option by pressing the navigation key

up or down, and then select a vibrate type.

Contacts

View Contacts

1. Press CONTACTS(right softkey) from the standby screen.

2. Use the navigation key to scroll through the list to view your

contacts.

Add a New Contact

1. In standby mode, press CONTACTS(right softkey) > Add

New... > New Contact.

2. Enter a name for the new entry and press the navigation

key down.

3. Enter the phone number and press .

4. Highlight a number type for the entry (Mobile, Home,

Work, Pager, Fax, or Other) and press .

5. Press DONE (left softkey).
