Quick Start Guide for the

KYOCERA Hydro XTRM

Get Started 2

Important Safety Information 16

Manufacturer’s Warranty 30

End User License Agreement 33

the property of their respective owners.

Android, Google Play, Google Maps, Gmail, Google Talk, and YouTube are trademarks of Google Inc.

The

Bluetooth

®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Kyocera

Corporation is under license. Other trademarks and trade names are those of their respective owners.

Get Started 2

♦Your KYOCERA Hydro XTRM (page 2)

♦Get Your Phone Ready (page 3)

♦Use Your Phone (page 5)

♦Customer Support (page 15)

♦Notes (page 15)

This section introduces you to the basics of getting started

with your KYOCERA Hydro XTRM. Visit http://

www.uscellular.com/ for the complete User Guide and

additional information.

Get Started

Your KYOCERA Hydro XTRM

Smart Sonic Receiver

(Internal)

Touchscreen

Charger/Accessory Jack

Power Button

Proximity Sensor/

Light Sensor

Self Camera Lens

Headset Jack

Microphone

< Front > < Top >

< Bottom >

LED Indicator

3 Get Started

Install the Battery

1. Insert the battery, contacts end first, and gently press

into place.

2. Replace the cover, making sure all tabs on the cover

align with the battery compartment slots and press

down until the cover snaps into place.

Charge the Battery

1. Plug the smaller end of the micro-USB cable into the

phone’s charger/accessory jack.

2. Plug the other end of the USB cable into the charger,

and then plug the charger into an electrical outlet.

Back Camera Lens

Volume

Button SIM CardSlot/

microSD CardSlot

(Internal)

Internal Antennas

Camera Flash

Microphone

< Side > < Back >

Speaker

Get Your Phone Ready

Get Started 4

Insert the SIM Card

1. Remove the battery cover. Grasp the white pull-tab

extending from the battery pack and pull the battery

out of its compartment.

2. Hold the SIM card so that the metal contacts on the

SIM card face down and the cut off corner points to

the top and left. Insert the SIM card into the SIM card

holder.

Insert the microSD Card

A microSD™ card is an optional accessory that allows you

to store images, videos, music, documents, and voice data

on your phone.

Remove the battery cover and insert a microSD card into

the microSD card holder with the gold terminals facing

down. Gently push the card in until it snaps into place.

Cut

5 Get Started

Turn the Phone On

Press and hold the Power button to turn your phone on.

Turn the Screen On and Off

Press the Power button to turn the screen on and off.

Unlock the Screen

Touch and hold the screen and flick the key icon

which appears under your finger toward the unlock

icon .

Turn the Phone Off

Press and hold the Power button and then touch Power

off > OK to turn the phone off.

Voicemail

Set Up Your Voicemail

All unanswered calls are automatically transferred to your

voicemail, even if your phone is in use or turned off. You

should set up your voicemail and personal greeting as soon

as your phone is activated:

1. Touch the Phone icon on the home screen to display

the phone dialpad.

2. Touch and hold .

3. Follow the voice prompts to create your password and

record your name and greeting.

It is strongly recommended that you set a voicemail

password. Without a password, anyone who has access to

your phone can access your messages.

Use Your Phone

Get Started 6

Retrieve Your Voicemail

Touch and hold on the phone dialpad.

From any other phone:

1. Dial your wireless phone number.

2. When your voicemail answers, press the asterisk key (*).

3. Enter your password.

Phone Calls

Make a Phone Call

1. Touch the Phone icon on the home screen to display

the phone dialpad.

2. Touch the digits of the number you want to call on the

dialpad. Touch to delete one or more digits.

3. Touch at the bottom of the screen to place the call.

4. Touch when you are finished.

Respond to an IncomingCall

On the incoming call screen, flick the Answer icon .

Flick the Ignore icon to send the call to your voicemail

inbox.

Flick the Ignore & Text icon to ignore the call and

send a message to the caller.

Note: While on a call and holding the phone near your face

to speak, the touchscreen automatically deactivates

to avoid accidental screen presses. When you move

the phone away from your face, the touchscreen

automatically reactivates.

7 Get Started

Display Settings

Add App Shortcutsor Widgetsto the Home Screen

1. Touch > .

2. Slide the APPSor WIDGETSscreens to find the item

you want to add to the home screen.

3. Touch and hold the app icon or a widget and move

your finger to find the place to add it to. The blue

frames which appear on the screen indicate where you

might place the item.

4. Release your finger.

Move or Remove Itemson the Home Screen

Touch and hold the item you want to move or remove

from the home screen.

▪To move the item, drag it to a new area and release it.

▪To remove the item, drag it to “X Remove” at the top of

the screen and release it when it turns red.

Change the Wallpaper

1. Touch and hold the empty area on the home screen.

2. Select an option:

▪Gallery/Graphicsto use saved or captured images

on your phone.

▪Live Wallpapersto use Live wallpapers.

▪Wallpapersto use preset wallpapers.

3. Select an image, crop it if necessary, and touch OK or

Set wallpaper.

Get Started 8

Sound Settings

Adjust the Volume

1. Touch > > Settings > Sound.

2. Touch Volumesand use the sliders to set the volume

level for Music, video, games, & other media,

Ringtone & notifications, and Alarms.

3. Touch OK to save your settings.

Tip: You can adjust the ringer volume in standby mode (or

the earpiece volume during a call) by using the volume

button on the left side of your phone.

Mute All Sounds

Press the volume button down in standby mode until you

see or on the status bar.

Select a Ringtone

1. Touch > > Settings > Sound > Phone

ringtone.

2. Select the app to use and select if using the app

Alwaysor Just once.

3. Select a ringtone from the available list. Touch OK if

required.

Select a Notification Sound

1. Touch > > Settings > Sound > Default

notification.

2. Select the app to use and select if using the app

Alwaysor Just once.

3. Select a notification sound from the available list.

Touch OK if required.

9 Get Started

Select a Vibration Pattern

1. Touch > > Settings > Sound >

Vibrate pattern.

2. Touch a vibrate pattern from the available list and

touch OK.

Contacts

View Contacts

1. Touch the People icon on the home screen.

2. Scroll through the list to view your contacts.

Add a New Contact

1. Touch the People icon on the home screen and then

touch .

2. Add as much or as little information as you want.

▪To add information in a field, touch the field to display

the touchscreen keyboard.

▪To assign a number or address type (such as

MOBILE, WORK, HOME, etc.), touch the label next to

the number or address field.

▪To assign a picture, touch the icon next to the name,

and select to take a picture or choose a picture from

Gallery.

3. Touch DONE when you are finished.

Edit Contacts

1. Touch the People icon on the home screen.

2. Touch a contact to open it, and then touch > Edit.

▪Touch a field to add or edit information.

3. Touch DONE when you are finished.

Note: To delete a contact, touch > Delete > OK.

Get Started 10

Messaging

Send a Message

1. Touch the Messagingicon on the home screen and

then touch .

2. Enter a phone number or email address in the Enter

up to 10 recipientsfield.

Tip: Enter a name saved in contacts to call up the phone

number or email address. Touch a match from an

available list.

Tip: Touch next to the field to access your contacts.

3. Touch the Type messagefield and type your

message.

▪To attach pictures or files, touch and select a

file.

▪To add a subject or insert a smiley, touch >

Add subject or Insert smiley, and then type a

subject or select a smiley.

4. When you are finished, touch or .

Access Messages

Touch the Messagingicon on the home screen. Touch a

message to open and read it.

If you have a new message notification, drag the status

bar down to open the Notifications panel. Touch a

message to open and read it.

Email Setup

Set Up a Gmail®Account®

1. Scroll to the right on the home screen, touch the

Google folder and then touch the Gmail icon.

2. Follow the instructions to set up or sign in to a Gmail

account.

Note: Although you need a Gmail account to use certain

features such as Google Play™, you do not have to

use Gmail as the default account for your phone.
