La Crosse Technology TX24U Manuale utente
TX24U
915MHz
WIRELESS RAIN GAUGE
INSTRUCTION MANUAL
2
SETTING UP
Hint: Use good quality Alkaline Batteries; avoid rechargeable
batteries.
1. Have the receiver and the rain gauge 3 to 5 feet apart.
2. Place the batteries into the rain gauge FIRST and next into
the receiver. Observing the correct polarization, insert 2 “AAA”
Alkaline Batteries into the compartment at the back of the rain
gauge and replace the cover. Follow the same guidelines for
the receiver.
Rain Gauge
Rain Gauge
Cove
r
Press tabs back to
unlock Rain Gauge cover
Lift Rain Gauge cover to
access battery compartment
Remove battery cover
and insert batteries
3
3. DO NOT PRESS ANY BUTTONS FOR 15 MINUTES.
4. Place the rain gauge in an appropriate location. The rain
gauge should be placed in a secure and flat location where it
can properly collect properly rain quantity without obstruction.
The rain gauge has a range of 330 feet. Keep in mind that the
330 feet is in open air with no obstructions and that radio
waves DO NOT curve to go around objects. Real-world
transmission range will vary depending on what is in the path
of the signal. Each obstruction (roof, walls, floors, ceilings,
thick trees, etc.) will effectively cut signal range in half.
Example: A wireless rain gauge receiver with a 330 feet
range is mounted on an interior wall, so that the signal has to
pass through one interior wall, one exterior wall, and across
the 10 feet width of the room between the 2 walls. The first
wall will reduce the range to 165 feet, and the second wall will
reduce the range to 87 feet. Factoring in the 10 foot room, this
leaves a maximum of 77 feet of remaining signal range.
This allowance is typically enough for a frame wall with non-
metallic siding; however certain materials can reduce range
even further. Metal siding, stucco, and some types of glass
can reduce signal range by as much as ¾ or more, compared
to the ½ reduction typical of most obstructions. It is possible to
receive a signal through these materials, however maximum
range will be much less due to their tendency to absorb or
reflect a much larger portion of the sensor’s signal.
Note:
When opening the battery cover make sure that the batteries do
not spring free from the contacts since this will cause start and
transmission problems.
Battery Change:
It is recommended to replace the batteries in the unit
approximately every 3 years to ensure optimum accuracy.
4
MOUNTING
Positioning the Rain Gauge
Position the connected rain gauge outdoor to collect rainfall data.
Ensure that the rain gauge is placed in a secure and flat location
where it can properly collect properly rain quantity without
obstruction. Ensure also that the rain gauge is securely mounted
at the appropriate location otherwise it may not transmit accurate
rainfall data.
The rain gauge must be level to transmit correct readings. It is
recommended to mount the rain gauge 3 feet or higher off of the
ground. Screw the rain gauge down snugly in the holes provided
(but not too tight as this will affect the accuracy of the gauge).
MAINTENANCE
•Avoid placing the units in locations prone to extreme
temperatures, vibration and shock since these may cause
damage and inaccurate readings.
•When cleaning the display and casing of the Wireless Rain
Gauge, use a soft damp cloth only. Do not use solvents or
scouring agents as they may mark the casing and LCD.
Holes
for screws
To
p
View
Side View
5
•Do not submerge the Wireless Rain Gauge in water.
•Immediately remove all low powered batteries to avoid leakage
and damage. Replace only with new batteries of the
recommended type.
•Please do not make any attempt to make any repairs to the
units. Return them to their original point of purchase for repair
by qualified personnel. Opening and tampering with the units
will invalidate the warranty.
LIABILITY DISCLAIMER
•The manufacturer and supplier cannot accept any
responsibility for any incorrect readings and any
consequences occurring should an inaccurate reading take
place.
•This product is not to be used for medical purposes or for
public information.
•This product is designed for strict home use as an indication of
rain quantities and is not 100% accurate. Readouts given by
this product should be taken only as an indication and not as
being totally accurate.
•The specifications of this product may change without prior
notice.
•This product is not a toy. Keep out of the reach of children.
•No part of this manual may be reproduced without written
consent of the manufacturer.
WARRANTY INFORMATION
La Crosse Technology, Ltd provides a 1-year limited warranty on this product against
manufacturing defects in materials and workmanship.
This limited warranty begins on the original date of purchase, is valid only on products purchased
and used in North America and only to the original purchaser of this product. To receive warranty
service, the purchaser must contact La Crosse Technology, Ltd for problem determination and
service procedures. Warranty service can only be performed by a La Crosse Technology, Ltd
authorized service center. The original dated bill of sale must be presented upon request as proof
of purchase to La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service
center.
La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as
stipulated herein, with new or reconditioned parts or products if found to be defective during the
limited warranty period specified above. All replaced parts and products become the property of La
Crosse Technology, Ltd and must be returned to La Crosse Technology, Ltd. Replacement parts
and products assume the remaining original warranty, or ninety (90) days, whichever is longer. La
Crosse Technology, Ltd will pay all expenses for labor and materials for all repairs covered by this
warranty. If necessary repairs are not covered by this warranty, or if a product is examined which is
6
not in need or repair, you will be charged for the repairs or examination. The owner must pay any
shipping charges incurred in getting your La Crosse Technology, Ltd product to a La Crosse
Technology, Ltd authorized service center. La Crosse Technology, Ltd will pay ground return
shipping charges to the owner of the product to a USA address only.
Your La Crosse Technology, Ltd warranty covers all defects in material and workmanship with the
following specified exceptions: (1) damage caused by accident, unreasonable use or neglect
(including the lack of reasonable and necessary maintenance); (2) damage occurring during
shipment (claims must be presented to the carrier); (3) damage to, or deterioration of, any
accessory or decorative surface; (4) damage resulting from failure to follow instructions contained in
your owner’s manual; (5) damage resulting from the performance of repairs or alterations by
someone other than an authorized La Crosse Technology, Ltd authorized service center; (6) units
used for other than home use (7) applications and uses that this product was not intended or (8) the
products inability to receive a signal due to any source of interference.. This warranty covers only
actual defects within the product itself, and does not cover the cost of installation or removal from a
fixed installation, normal set-up or adjustments, claims based on misrepresentation by the seller or
performance variations resulting from installation-related circumstances.
LA CROSSE TECHNOLOGY, LTD WILL NOT ASSUME LIABILITY FOR INCIDENTAL,
CONSEQUENTIAL, PUNITIVE, OR OTHER SIMILAR DAMAGES ASSOCIATED WITH
THE OPERATION OR MALFUNCTION OF THIS PRODUCT. THIS PRODUCT IS NOT
TO BE USED FOR MEDICAL PURPOSES OR FOR PUBLIC INFORMATION. THIS
PRODUCT IS NOT A TOY. KEEP OUT OF CHILDREN’S REACH.
This warranty gives you specific legal rights. You may also have other rights specific to
your State. Some States do no allow the exclusion of consequential or incidental
damages therefore the above exclusion of limitation may not apply to you.
For warranty work, technical support, or information contact:
La Crosse Technology, Ltd
190 Main Street
La Crescent, MN 55947
Phone: 507.895.7095
Fax: 507.895.2820
e-mail:
support@lacrossetechnology.com
(warranty work)
sales@lacrossetechnology.com
(information on other products)
web:
www.lacrossetechnology.com
Questions? Please see:
www.lacrossetechnology.com/9004
All rights reserved. This handbook must not be reproduced in any form, even in excerpts, or duplicated or
processed using electronic, mechanical or chemical procedures without written permission of the publisher.
This handbook may contain mistakes and printing errors. The information in this handbook is regularly checked
and corrections made in the next issue. We accept no liability for technical mistakes or printing errors, or their
consequences.
All trademarks and patents are acknowledged.
