La Crosse Technology 513-1419BL Manuale utente

Atomic Digital Ofce Clock

Model: 513-1419BL

D.C. 042618

For online video support:

http://bit.ly/LaxTechTalk

MONTH

DATE

Setup

Power up. 1. Insert the 5.0 volt power cord into the outlet then

into the clock.

2. (Optional) Insert 2 “AA” batteries (not included)into the clock

Congure basic settings. Hold the MODE button for 3 seconds

to enter settings menu. Use the + or- button to adjust and SET to

conrm.

Setting order:

Time set order:

1. Language (English or Spanish)

2. Beep ON/OFF

3. Atomic ON/OFF

4. Time Zone

5. DST ON/OFF

6. 12/24 Hour

7. Hour

8. Minutes

9. Year

10.Month

11.Date

12.Fahrenheit/Celsius

English | Español Beep ON | OFF

Atomic ON | OFF Time Zone

AST

EST

CST

MST

PST

AKT

HAT

Atlantic

Eastern

Central

Mountain

Pacific

Alaskan

Hawaiian

Time Zone

Page | 1 www.lacrossetechnology.com/support 513-1419BL

Note: When the Atomic setting is

set to OFF, the menu will skip to

item #6, your 12/24 hour setting

Note: The clock will search for

atomic time 2 hours after

batteries are installed.

Note: When Español is selected, the

sub menu instructions

will be in Spanish.

DST ON | OFF Hour

Minutes Year

Month Date

Fahrenheit | Celsius

Atomic Time

• The clock will automatically search at UTC 7:00, 8:00, 9:00, 10:00,

and 11:00.

• If there is no WWVB reception, the clock will search for the atomic

time signal every 2 hours until the WWVB time is received.

• After reception, this clock will only search for the atomic signal

after midnight.

• From normal time display hold the MINUS button for 3 seconds, to

search for the WWVB time signal.

• For information about WWVB visit: http://bit.ly/AtomicTime

513-1419BL www.lacrossetechnology.com/support Page | 2

Display icons

AM | PM

Low Battery

Alarm

Atomic Time

Fahrenheit | Celsius

Page | 3 www.lacrossetechnology.com/support 513-1419BL

MONTH

DATE

DAY MONTH DATE

Snooze

Display: Date | Indoor Temp | Seconds

• Press and release the MODE button to customize how the top and

right sections of the clock are displayed.

• The clock will stay in the mode selected.

MODE 1:

Weekday &

Month/Date

MODE 2:

Day/Month/Date

& Temperature

MODE 3:

Day/Month/Date

& Seconds

MONTH

DATE

DAY MONTH DATE MONTHDAY DATE

513-1419BL www.lacrossetechnology.com/support Page | 4

Set Time Alarm

Activate/Deactivate Alarm

1. Hold the ALARM button to enter alarm settings. “AL” will show.

2. Press and release ALARM to activate/deactivate the alarm.

3. The bell icon will show when active.

Snooze

1. When alarm sounds press the SNOOZE button to silence the alarm

for 10 minutes.

2. The alarm bell icon will show and Zz will ash.

3. Press any button except SNOOZE to stop the alarm for 1 day.

Note: Alarm is crescendo sound. When the alarm sounds, it

continues for 2 minutes and then shuts off completely.

Alarm ON Alarm OFF

• Hold the ALARM button for 3 seconds to enter alarm settings menu.

• Use the + or- button to adjust and ALARM to conrm.

Backlight: HI-LOW-OFF

• When operating with the AC adapter, the backlight is adjustable:

(HI-LOW-OFF).

• Press and release the SNOOZE/LIGHT HI-LOW-OFF button to

adjust backlight.

• When operating on batteries only, the backlight will come on

briey when the SNOOZE button is pressed.

Position Clock

The clock has a pullout stand to sit on a desk or table, or openings on

the back to mount on a wall.

• For best Atomic time reception orientate the clock with the front or

the back facing Ft. Collins, Colorado.

• Choose a location 6 feet or more from electronics such as cordless

phones, gaming systems, televisions, microwaves, routers etc.

For personalized interaction

http://bit.ly/LaxTech_Facebook

Join the conversation

http://bit.ly/LaxTech__Twitter

Latest video content

http://bit.ly/LaxTech_YouTube

Page | 5 www.lacrossetechnology.com/support 513-1419BL

Low Battery Icon

• The low battery icon will appear between the hour and minutes.

• This icon indicates it is time to replace the batteries.

Indoor

Power

Battery Life

Dimensions

32˚F to 99˚F | 0˚C to 37˚C

Clock: 5.0VAC # GPU280500150WA00

Optional: 2 AA (LR6, IEC) batteries not included

24 months with reputable batteries

Clock: 9.84” L x 1.13” W x 7.48” H

(25.02cm L x 2.9cm W x 19.0cm H)

Specications

513-1419BL www.lacrossetechnology.com/support Page | 6

Care and Maintenance

• Do not mix old and new batteries

• Do not mix Alkaline, Standard, Lithium or Rechargeable Batteries

• Always purchase the correct size and grade of battery most suitable

for intended use.

• Replace all batteries of a set at the same time.

• Clean the battery contacts and also those of the device prior to

battery installation.

• Ensure the batteries are installed with correct polarity (+ and -).

• Remove batteries from equipment which is not to be used for an

extended period of time.

• Promptly remove expired batteries.

Warranty and Support

La Crosse Technology, Ltd. provides a 1-year limited time warranty

(from date of purchase) on this product relating to manufacturing

defects in materials & workmanship.

Before returning a product, please contact our friendly customer sup-

port or visit our online help:

Phone: 1-608-782-1610

Online: www.lacrossetechnology.com/support

View full warranty details online at:

www.lacrossetechnology.com/warranty_info.pdf

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy, and if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device must not be co-located or operating in conjunction with any other

antenna or transmitter.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference

that may cause undesired operation.

Caution!

The manufacturer is not responsible for any radio or TV interference caused

by unauthorized changes or modications to this equipment. Such changes or

modications could void the user authority to operate the equipment.

part, or duplicated or processed using electronic, mechanical or chemical

process without the written permission of the publisher. This booklet may

contain errors or misprints. The information it contains is regularly checked

and corrections are included in subsequent editions. We disclaim any

responsibility for any technical error or printing error, or their consequences.

All trademarks and patents are recognized.

Canada Statement

This device complies with CNR Industry Canada license -exempt devices.

Operation is subject to the following two conditions:

(1) This device may not cause interference; and

(2) This device must accept any interference, including interference that may

cause undesired operation of the device.

FCC Statement

Page | 7 www.lacrossetechnology.com/support 513-1419BL
