La Crosse Technology WS-8011UM-TWC Manuale utente

WS-8011MTWC

433 MHz

Radio Controlled Temperature Clock

Instruction Manual

              

TABLE OF CONTENTS

Topic Page

Inventory of Contents/ Additional Equipment 3

About WWVB 3

Quick Set-Up Guide 4

Detailed Set-Up Guide

Battery Installation 5-6

Program Mode

Function Buttons 6

Time Zone Setting 6

DST (Daylight Saving Time) Setting 7

Language Selection 7

Time Setting 7-8

Calendar Setting 8

12/24-Hour Setting 8

Selecting °F or °C 9

Features & Operations

Changing Display Mode (seconds, temperature) 10

The Alarm 10-11

Indoor Temperature 11

Remote Temperature 11

Mounting 12-13

Maintenance & Care 14

Troubleshooting 15

Specifications 16

Warranty Information 17-18

INVENTORY OF CONTENTS

1) WS-8011UM

2) TX6U remote temperature transmitter

3) Instruction manual and warranty card.

ADDITIONAL EQUIPMENT (not included)

1) Two fresh 1.5V AA batteries (for the temperature clock).

2) Two fresh 1.5V AA batteries (for the remote temperature transmitter).

3) Three wall-hanging screws.

4) Appropriate screwdriver for screws.

ABOUT WWVB (Radio Controlled Time)

The NIST (National Institute of Standards and Technology—Time and Frequency

Division) WWVB radio station is located in Ft. Collins, Colorado, and transmits the exact

time signal continuously throughout the United States at 60 kHz. The signal can be

received up to 2, 000 miles away through the internal antenna in the temperature clock.

However, due to the nature of the Earth’s Ionosphere, reception is very limited during

daylight hours. The temperature clock will search for a signal every night when

reception is best. The WWVB radio station derives its signal from the NIST Atomic

clock in Boulder, Colorado. A team of atomic physicists is continually measuring every

second, of every day, to an accuracy of ten billionths of a second per day. These

physicists have created an international standard, measuring a second as 9,192,631,770

vibrations of a Cesium-133 atom in a vacuum. For more information about WWVB

please see the NIST website at http://www.boulder.nist.gov/timefreq/stations/wwvb.htm

QUICK SET-UP GUIDE

Hint: Use good quality Alkaline Batteries and avoid rechargeable batteries.

1. Have the indoor station and outdoor remote 3 to 5 apart.

2. Batteries should be out of both units for 10 minutes.

3. Place the batteries into the remote temperature sensor first then into the

temperature clock.

(All remote temperature sensors must be started before the temperature

clock)

4. DO NOT PRESS ANY BUTTONS FOR 10 MINUTES.

In this time the temperature clock and remote temperature sensor will start to talk to each

other and the temperature clock will show both the indoor temperature and an outdoor

temperature. If the temperature clock does not display both temperatures after the 10

minutes please retry the set up as stated above. After both indoor and outdoor

temperatures are displayed for 10 minutes you can place your remote temperature sensor

outdoors and set your time.

The remote temperature sensor should be placed in a dry, shaded area. The remote

temperature sensor has a range of 80 feet. Any walls that the signal will have to pass

through will reduce distance. An outdoor wall or window will have 20 to 30 feet of

resistance and an interior wall will have 10 to 20 feet of resistance. Your distance plus

resistance should not exceed 80 ft. in a straight line.

NOTE: Fog and mist will not harm your remote temperature sensor but direct rain must

be avoided.

To complete the set up of your temperature clock after the 10 minutes have passed please

follow the steps below.

DETAILED SET-UP GUIDE

I) BATTERY INSTALLATION

Note: To avoid start-up problems make sure that the batteries do not spring free.

A) REMOTE TEMPERATURE TRANSMITTER

1) Remove the battery cover. Place your thumb over

the two air-vent slots on the face of the remote

temperature sensor, push down gently, and slide

battery cover down and off.

attery

Cover

2) Observing the correct polarity, install 2 AA batteries.

The batteries will fit tightly (to avoid start-up

problems make sure that they do not spring free

during installation).

3) Replace the battery cover.

B) TEMPERATURE CLOCK

1) Remove the battery cover,

located on the backside of the

temperature clock and directly

below the function buttons.

2) Observe the correct polarity,

and install 2 AA batteries.

3) Replace the battery cover.

Note: After the batteries have been installed a tone will sound, and all the LCD’s

(Liquid Crystal Display) will briefly light up. The indoor temperature, the date as

“1/ 1”, the weekday as “MON”,

and the remote temperature will

be displayed (within three

minutes). Also, the time will

appear as “-:--” for

approximately 1 minute. The

WWVB search is automatically

initiated, and a tower icon

appears and flashes with the time colon (no tower icon will appear if the WWVB is

too weak to be detected, and the time display will remain on “-:--”). While the

WWVB search is being conducted various numbers will appear in the time display.

Within 10 minutes the temperature clock will either display the WWVB time, or

discontinue the search if the time is not found. If the search is cancelled “-:--” will

appear in the time LCD. The temperature clock will conduct a WWVB search every

hour until the first signal is found. Once the WWVB time is found, a search is

automatically conducted nightly at midnight. If the signal is found at midnight, the

tower icon will remain, if not, another search will take place every hour (until 6:00

Outdoor tem

erature

Dat

WWVB

larm

Radio rece

tion

Indoor temperature or

seconds display

Weekday or

seconds display

Battery Compartment

Battery Cover

am) until the signal is found successfully. If no signal is found during this period,

the tower icon will not appear and the clock will search again at 12:00 am the next

night.

II) PROGRAM MODE

To enter the Program Mode hold down the “SET” button for 2 seconds, until

“-5EST” flashes in the Date LCD. The Program Mode is laid out in a manner that

allows you to program each function separately, or you can follow the instructions

entirely to program the temperature clock. Complete programming is usually done

for the initial set-up, and will require you to skip step 1 of programming sections C

through H. Press and release the “SNOOZE” button at any time to exit the Program

Mode, or wait approximately 15 seconds for the temperature clock to automatically

return to normal operation.

A) FUNCTION BUTTONS

There are 4 function buttons located on the backside of the temperature clock.

The function buttons are labeled: “SET”, “+”, “ALARM”, and “SNOOZE”.

B) TIME ZONE SETTING

1) Hold down the “SET” button for 2 seconds, the default (factory) setting

“-5EST” will flash in the Date LCD.

2) Press and release the “+” button to select the appropriate time zone. There

are 13 time zones to choose from:

-4ATL Atlantic Time

-5EST Eastern Time (default setting)

-6CST Central Time

-7MST Mountain Time

-8PST Pacific Time

-9ALA Alaskan Time

-10HAW Hawaiian Time

-11, -12 Next two time zones West of HAW

GMT Greenwich Mean Time

-1, -2, -3GMT Three time zones West of GMT

3) Press and release the “SET” button to confirm the time zone setting, and to

advance to DST (Daylight saving time) setting.

C) DST (DAYLIGHT SAVING TIME) SETTING

Note: The DST default is “On”, meaning that the WWVB will automatically

change the time according to Daylight Saving Time in the spring and fall. For

areas that do not recognize DST changes (Arizona, Hawaii and parts of

Indiana) turn the DST “OFF”.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button once more until “On” flashes in the time

LCD and “DST” flashes where the Weekday normally appears.

3) Press and release the “+” button to turn the DST off, as will be indicated by

the display of “OFF” in the time LCD.

4) Press and release the “SET” button to confirm the DST setting, and to

advance to select the language for the weekday.

D) LANGUAGE SELECTION FOR THE WEEKDAY

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button 2 times until the default language “US”

flashes in the time LCD.

3) Press and release the “+” button to toggle through and to select the desired

language. There are 3 languages to select from:

US English

F French

E Spanish

4) Press and release the “SET” button to confirm the language setting, and to

advance to manually set the time.

E) TIME SETTING

Note: When the WWVB signal is found, that time will over-ride the manually set

time.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button 3 times until the hour “12” flashes in

the time LCD.

3) Press and release the “+” button to select the hour.

Note: when setting the hour, “PM” will appear to the left of the hour display, if

it is AM nothing will be displayed.

4) Press and release the “SET” button to confirm the hour setting, and to shift

to select the minutes.

5) Press and release the “+” button to select the minutes.

6) Press and release the “SET” button to confirm the time setting and to

advance to manually set the calendar.

F) CALENDAR SETTING

Note: When the WWVB signal is found, that date will over-ride the manually set

date.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button 5 times until the default year “00”

flashes in the date LCD.

3) Press and release the “+” button to select the year.

4) Press and release the “SET” button to confirm the year, and to set the

month.

5) The default month “1” will flash.

6) Press and release the “+” button to select the appropriate month.

7) Press and release the “SET” button to confirm the month and to set the date.

8) The default date “1” will flash.

9) Press and release the “+” button to select the appropriate date.

10) Press and release the “SET” button to confirm the date and to set the

weekday.

11) The default weekday “MON” (depends on selected language) will flash.

12) Press and release the “+” button to select the appropriate weekday.

13) Press and release the “SET” button to confirm the calendar settings and to

advance to select either 12 or 24-hour time display.

G) 12/24-HOUR SETTING

Note: 12-hour uses AM/PM, 24-hour is also known as “military” time.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button 9 times until the “12” hour time display

flashes in the time LCD.

3) Press and release the “+” button to toggle between 12 and 24 hour time.

4) Press and release the “SET” button to confirm the 12/24-hour time display

and to advance to select either °F or °C.

H) SELECTING °F OR °C

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button 10 times until the default “°F” flashes in

the time LCD.

3) Press and release the “+” button to toggle between °F and °C.

4) Press and release the “SET” button to confirm the °F or °C selection and

exit the program mode.

III) FEATURES & OPERATIONS

A) CHANGING DISPLAY MODE (DAY, SECONDS, AND

TEMPERATURE)

There are three possible display modes to view the day, seconds, and

temperature. The month&date/weekday /indoor temperature/remote temperature

is the default.

To change the display:

1) Press and release the “+” button.

2) The display should now show the month&date/weekday/seconds/remote

temperature

3) Press and release the “+” button.

4) The display will now show the month&date/seconds/indoor

temperature/remote temperature.

5) Press and release the “+” button.

6) The display will return to the normal display.

B) THE ALARM

1) SETTING THE ALARM

Note: The duration of the alarm is 85 seconds. After each of the first two 25

second periods, the rate of the alarm increases.

(a) Hold down the “ALARM” button for 5 seconds.

(b) The “TIME” icon to the right of the minutes (in the time LCD) shifts to

“ALARM” and the hour digit of the alarm flashes.

(d) Press and release the “ALARM” button to confirm the hour and to set

the alarm minutes.

(e) The alarm minutes flash.

(f) Press and release the “+” button to set the alarm minutes.

(g) Press and release the “ALARM” button to confirm and to exit the alarm

setting mode.

Note: The alarm will be automatically set to sound when exiting the alarm-

setting mode (indicated by the alarm “sound” icon to the right of the time).

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali La Crosse Technology Orologio

La Crosse Technology

La Crosse Technology 616-1410B Manuale utente

La Crosse Technology

La Crosse Technology 513-1417BS Manuale utente

La Crosse Technology

La Crosse Technology C86279v4 Manuale utente

La Crosse Technology

La Crosse Technology 433-3256 Dimensioni

La Crosse Technology

La Crosse Technology BBB86088v2 Manuale utente

La Crosse Technology

La Crosse Technology 404-3840FL Manuale utente

La Crosse Technology

La Crosse Technology WS-8157U-IT Manuale utente

La Crosse Technology

La Crosse Technology WS6158-IT Manuale utente

La Crosse Technology

La Crosse Technology 616-1410 Manuale utente

La Crosse Technology

La Crosse Technology Sagebrook 404-3015CC Manuale utente

La Crosse Technology

La Crosse Technology 513-1419BL-WA Manuale utente

La Crosse Technology

La Crosse Technology C86279 Manuale operativo e di manutenzione

La Crosse Technology

La Crosse Technology K86302 Manuale utente

La Crosse Technology

La Crosse Technology 513-1417CHv2 Manuale utente

La Crosse Technology

La Crosse Technology 515-1316 Manuale utente

La Crosse Technology

La Crosse Technology T73743 Manuale utente

La Crosse Technology

La Crosse Technology WT-8002U Manuale utente

La Crosse Technology

La Crosse Technology WT-3128 Manuale

La Crosse Technology

La Crosse Technology Radio Controlled Analog Clock WT-3181bz Manuale utente

La Crosse Technology

La Crosse Technology W86111V2 Manuale utente

La Crosse Technology

La Crosse Technology WT-8002Uv2 Manuale utente

La Crosse Technology

La Crosse Technology WS-8117U-AL Manuale utente

La Crosse Technology

La Crosse Technology 513-1311OT Manuale utente

La Crosse Technology

La Crosse Technology 404-1946 Manuale utente

Manuali Orologio popolari di altre marche

Silicon Laboratories

Silicon Laboratories SI5324 Manuale utente

Heathkit

Heathkit GC-1005 Manuale utente

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manuale utente

Andrew O'Malley

Andrew O'Malley DOTKLOK Manuale utente

ALGE-Timing

ALGE-Timing ASC3 Manuale utente

Bodet

Bodet Profil 960 Manuale utente

Nixie Clock

Nixie Clock Divergence Meter Manuale utente

Mini Gadgets

Mini Gadgets MCPro Manuale utente

Casio

Casio TMR-200 Manuale utente

Progetti

Progetti ILTEMPOSTRINGE Manuale

BVItech

BVItech BV-101 Manuale utente

Progetti

Progetti KALIMERO Manuale

Sharp

Sharp SPC900 Manuale utente

Datexx

Datexx DF0063 Manuale utente

LG LEC-005 Manuale utente

IKEA

IKEA ROTBLÖTA Manuale utente

U-Line

U-Line Н-2811 Manuale utente

Digiview

Digiview RC305EL Manuale utente
