LaCie Rugged XL Manuale utente

rugged XL

DESIGN BY NEIL POULTON

Quick Install Guide

Hi-Speed USB 2.0 & eSATA 3Gbits

QIG_Rugged-XL_090223.indd 1 2/23/09 11:11:52 AM

Protect your investment – register for free technical support at www.lacie.com/register

Box Content

LaCie Rugged XL Hard Disk

Hi-Speed USB 2.0 cable

eSATA cable

Power supply kit

Quick Install Guide

LaCie Storage Utilities and User Manual

are pre-loaded on the drive

All utilities and manuals are additionally

available for free download from the

LaCie website: www.lacie.com

QIG_Rugged-XL_090223.indd 2 2/23/09 11:11:52 AM

Power USB 2.0eSATA

Rear View Connections

QIG_Rugged-XL_090223.indd 3 2/23/09 11:11:52 AM

Setup Steps

1. Connect the power supply.

2. Connect the USB or eSATA cable to

your computer and to the drive.

3. Turn on the drive using the power

button on the back. After a few

seconds, a small LaCie partition will

mount on your computer and appear

in My Computer (Windows users) or

on your desktop (Mac users).

Before using your drive, LaCie Setup

Assistant software must be launched to

format your drive. It will:

• Optimize your drive according to

your needs

• Copy the manual and utilities onto

your computer

Power button

QIG_Rugged-XL_090223.indd 4 2/23/09 11:11:52 AM

To launch LaCie Setup Assistant:

Windows users: Double-click the LaCie drive icon in My Computer.

Mac users: Double-click the “LaCie Setup Assistant” icon on your desktop.

NOTE: If you do not launch LaCie Setup Assistant or if you quit LaCie Setup

Assistant after the formatting has begun, your drive will not be ready to use

and will require manual formatting. The user manual and utilities will not be

available on your drive and will have to be downloaded from the LaCie website:

www.lacie.com

NOTE: Using LaCie Setup Assistant does not prevent you from using your

computer’s native disk utility program to format or partition your LaCie drive.

Simply follow the Setup Assistant through completion, then use your computer’s

native disk utility (Disk Management for Windows or Disk Utility for Mac) to

reformat your drive.

QIG_Rugged-XL_090223.indd 5 2/23/09 11:11:52 AM

Manufacturer’s Declaration for CE Certiﬁcation

We, LaCie, solemnly declare that this product conforms to the follow-

ing European standards: Class B EN60950, EN55022, EN55024

With reference to the following conditions: 73/23/EEC Low Voltage

Directive; 89/336/EEC EMC Directive

LaCie Rugged XL

Tested to comply with

FCC standards for

home or ofﬁce use

Precautions

Do not stack multiple LaCie Rugged XL Hard Disks or expose the device to liquids.

Use only the power supply shipped with the device.

Warranty Information

LaCie warrants your product against any defect in material and workmanship, under

normal use, for the designated warranty period. The warranty becomes effective from the

date of shipment. In the event this product is found to be defective within the warranty

period, LaCie will, at its discretion, repair or replace the defective product.

This warranty is void if:

• Theproductwasoperated/storedinabnormaluseormaintenanceconditions;

• Theproductisrepaired,modiedoraltered,unlessLaCieexpresslyauthorizessuch

repair,modicationoralterationinwriting;

• Theproductwassubjectedtoabuse,neglect,electricalfault,improperpackaging,

accidentoractsofnature;

• Theproductwasinstalledimproperly;

• Theserialnumberoftheproductisdefacedormissing;

• Thebrokenpartisareplacementpartsuchasapickuptray,etc.

• Thetampersealonthecasingisbroken.

See the User Manual (pre-loaded on the drive) for more information.

QIG_Rugged-XL_090223.indd 6 2/23/09 11:11:52 AM

QIG_Rugged-XL_090223.indd 7 2/23/09 11:11:52 AM

QIG_Rugged-XL_090223.indd 8 2/23/09 11:11:52 AM

QIG_Rugged-XL_090223.indd 9 2/23/09 11:11:53 AM

QIG_Rugged-XL_090223.indd 10 2/23/09 11:11:53 AM
