LaPazz D-Note DNA500 Manuale utente

D-Note™ Series
Digital Note Recorder V1.03
User Manual
DNA500 DLA401
Federal Communications Commission (FCC) Radio Frequency Interference Statement
According to the Part 15 of FCC Rules, this equipment has been tested and found to comply with the rules
for a Class B digital device. These rules are designed to provide reasonable protections against harmful
interference when the equipment is operated in a residential installation. This equipment is able to generate,
use and create radiate radio frequency energy and if not installed and used in accordance with the
instruction manual that may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment causes harmful
interference to radio or television reception, which can be determined by turning the equipment off and on,
user is encouraged to correct the interference by one or more of the following tests:
•Locate and correct the receiving antenna.
• Keep a distance between the equipment and receiver.
• Connect the equipment into another socket which is different from the receiver’s one
• Contact the vendor or wireless or TV technician for assistance
Trademark Information
LaPazz and D-Note are registered trademarks of UC-Logic Technology Corporation.
TekiStore is a trademark of TekiStore LLC.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Pentium is a registered trademark of Intel Corporation.
Adobe and Acrobat are registered trademarks of Adobe Systems Inc.
All other trademarks are the property of their respective owners.
Copyright Notice
© 2005 UC-Logic Technology Corp. All rights reserved. No part of this publication may
be reproduced, stored in a retrieval system, or transmitted, in any form or by any means
(electronic, mechanical, photocopying, recording, or otherwise), without the prior written
permission of the publisher.
Note: Specifications mentioned in this manual are subject to change without notice.
Contact TekiStore for sales at james@tekistore.com and technical support at
support@tekistore.com or check updated information at www.tekistore.com

2
INDEX
1. Introduction..............................................................................................................3
1.1 Possible applications............................................................................................... 3
1.2 System Requirements ............................................................................................. 3
1.3 Package Content ..................................................................................................... 4
2. Knowledge about D-Note.........................................................................................5
2.1 Install the batteries into the digital recorder ........................................................... 7
2.2 Install the batteries for Digital Pen ..........................................................................8
2.3 Setup the NotePad and recorder...............................................................................9
2.4 Store Device .......................................................................................................... 10
3. D-Note Operation Guide.........................................................................................11
3.1 Front panel’s functions .......................................................................................... 11
3.2 Power Button.......................................................................................................... 12
3.3 Build up and store a new page................................................................................ 12
3.4 Modify notes........................................................................................................... 13
3.5 Delete pages............................................................................................................ 13
3.6 MENU functions..................................................................................................... 14
3.6.1 Change the paper orientation......................................................... ..15
3.6.2 Book Settings..................................................................................16
3.6.3 Auto Suspend-Timer ( 3 minutes--- 60 minutes) .......................... 19
3.6.4 Space/Power Display..................................................................... 19
3.7 Testing for Digital Ink Pen..................................................................................... 20
4. Introduction to Software Functions.......................................................................21
4.1 Install Digital Organizer ........................................................................................ 21
4.2 Transfer your data from D-Note to your computer................................................ 22
4.3 Importing digital pages........................................................................................... 23
4.4 Using the D-Note as Tablet.................................................................................... 24
4.5 Introduction to Digital Organizer.......................................................................... .25
4.6 The standard Toolbars............................................................................................ 25
4.7 The Digital Page Toolbar....................................................................................... 34
4.8 Drawing Toolbars – Support Tablet Function..................................................... 39
4.8.1 Modify the color and shape ................................................................................ 44
4.9 Insert Background Colors..................................................................................... .46
You can insert the pictures, colors, and line template into your files of handwriting
4.9.1 Normal model .......................................................................................... 46
4.9.1.2 Insert Background Colors ......................................................................49
4.9.2 Real Picture Model....................................................................................51
5. Recommend Software.............................................................................................. 54
6. Take Care of your D-Note .......................................................................................55
Q & A, Troubleshooting.............................................................................................. 56
Appendix...................................................................................................................... 58
Replacing the ink cartridge of the digital pen
D-Note Specifications.................................................................................................. 60

3
1. Introduction
The D-Note Series of digital note recorder has built-in memory that
allows you to instantly capture notes or diagrams written in ink on
normal paper without connecting into your computer, and then transfer
a digital data into a computer for viewing, editing, or sharing by email
on Windows platform. When the D-Note connects into a computer, it is
able to use like a tablet.
1.1 Possible applications
D-Note can be deployed in any situations where both a paper
hardcopy and a digitized soft copy are required, such as minutes
taking, lecture notes taking or business presentation. The artist and
writer are able to do their jobs any time when good idea coming out.
1.2 System Requirements
Operating System Windows 2000/XP/Vista
CPU Pentium III 500 MHz or Higher
Level of PC
RAM (Memory) 128 MB or Higher
Equipment One USB port, one CD/DVD ROM
Drive
Hard Disk space for Driver
installation
Minimum space 32 MB

4
1.3 Package contents
DNA500:
1. D-Note: digital note recorder
2. One A5 size of notepad
3. Digital ink pen (Black) x 1, digital pen (Red) x 1 (Become digital
pen after connecting to computer)
4. Two 1.4V button cell battery (for digital pen)
5. One leather slipcover
6. Three refills (Two are Black, One is Red) for digital pen
7. One USB connecting cable (39.4 inch)
8. Four 1.5V AAA size battery (for digital note recorder)
9. One CD (Includes Digital Organizer 1.03, My Script “Notes For
U” 30 days trial version and manual)
10. Quick Start Guide
11. Mini Screwdriver
DLA401:
1. D-Note: digital note recorder
2. One A4 size of paper notepad
3. Digital ink pen (Black) x 1, digital pen (Red) x 1 (Become digital
pen after connecting to computer)
4. Two 1.4V button cell battery (for digital pen)
5. One leather slipcover
6. Three refills (Two are Black, One is Red) for digital pen
7. USB connecting cable x 1 (39.4 inch)
8. Four 1.5V AAA size battery (for digital note recorder)
9. One CD (Includes Digital Organizer 1.03, My Script “Notes For
U” 30 days trial version and manual)
10. Quick Start Guide
11. Mini Screwdriver

5
2. Knowledge about D-Note
DNA401:
Hand writing area
One can write and record notes or drawings in the writing area of the
DNA401 digital recorder. The maximum area is 8.3" x 10.3" (210 x
263mm).
Thickness of the paper pad
The DLA401 supports standard A4 paper pads with a maximum
thickness of 0.2”~0.3” (5~7mm).

6
DNA500
Handwriting area
One can write and record notes or drawings in the writing area of
DNA500 digital recorder. The maximum area is 5.9" x 8.3" (150 x
210mm).
Thickness of the paper pad
The DNA500 supports standard A5 paper pads with a maximum
thickness of 0.6” (15mm).

7
2.1 Installation of the batteries
DNA500 DLA401
Turn off the power before changing the batteries or the memory
data could come out with errors.
WARNING! When the battery installed in a wrong way, will
leak out the liquid from the battery.
Do not mix together with different brands or used batteries.
Please take out the batteries if not using for more than 30 days.
Four AAA alkaline batteries can be used approximate 100 hours
continuously. Battery life varies based on different brand.

8
2.2 Installation of the ink pen battery
Open the bottom of digital pen’s lid and take out the mercury battery
from packing bag, then install a new one with the negative (-) pole
facing the pen tip. Screw both barrel parts up until tight.
Incorrect battery installation will result in the malfunction of the
digital ink pen.
Important:Remove cover label before inserting the pen battery.
In case to lose the digital pen, please put them into the D-Note’s
trough.
Recommendation of Mercury battery:

9
Pen’s refill:
1. MiniStar D1
2. Other brands:the standard of dimension:2.65 x 0.09 inch Φ
[ 67.16 (L) x Φ2.35mm ] (Nickel plated brass tip).
2.3 Setup the Notepad and recorder
Attach the paper notepad on D-Note pad standard and the maximum
size is:
DLA401 210mm x 263mm (A4/Letter)
DNA500 150mm x 210mm (A5)
Please do not exceed the size of Digital recorder and exert
great efforts to tear the papers.

10
Available working area:
DLA401:8.3” x 10.4” (210 x 263 mm)
DNA500:5.9” x 8.5” (150 x 210 mm)
2.4 Store Device
The built-in 32MB FLASH memory is able to save the handwritten
notepads as digital one (*.DNT).
Please do not save the files from computer into digital D-Note’s
memory, or the data in D-Note will be damaged or lost.
