December 08 PC
ThermoConfig
Software for the Configuration
of the 5739 18/19 Temperature Control Unit
User manual
3
ThermoConfig
Contents
1. General description.................................................................................................................................................... 4
2. Minimum system requirements....................................................................................................................... 4
3. Selection of functions .............................................................................................................................................. 5
4. Work area ........................................................................................................................................................................... 7
4.1 “Window” System 7
4.2 “Control unit”Window 10
4.3 “Library profiles”Window 11
5. Example of a project............................................................................................................................................... 16
5.1 System configuration 17
5.2 Configuration of Weekly programs 20
5.3 Scenario configuration 24
5.4 Configuration of Holiday program 25
6. Connecting to the Control Unit ..................................................................................................................... 26
7. Functions enabled while connecting........................................................................................................ 27
7.1 Upload 27
7.2 Download 28
7.3 Compare 30
7.4 Diagnosis 30
8. Firmware update....................................................................................................................................................... 31
4
ThermoConfig
1. General
description
The ThermoConfig software is a tool that allows the user to easily and intuitively determine or change
the configuration to be transferred to the Temperature control Unit 5739 18/19, thereby determining
the structure of the system and the profiles of the different programs and scenarios to be performed.
2. Minimum system
requirements
Hardware requirements
•Personal Computer with Pentium processor 400 MHz or higher
•CD-ROM drive
•SVGA graphics card with resolution 800 x 600
•RAM 128 Mb
Software requirements
•Windows XP or higher
•Internet Explorer ver. 6.0 or higher
5
ThermoConfig
3. Selection of functions The main functions that can be executed with ThermoConfig can be selected by using the icons in
the toolbar or by opening drop-down menus, thus selecting the various options. Some functions are
available only after making a connection between the PC and the Control Unit.
Creates a new project
Opens an existing project
Saves the current project
Disables connection to Control Unit
Loads the configuration present in the Control Unit (*)
Downloads the configuration created in the Control Unit (*)
Downloads the Firmware update in the Control Unit
Executes the diagnosis procedure of the Control Unit (*)
Toolbar
The followings functions are included in the toolbar:
Drop-down menu
Connection to the
Legrand website
Selection of
language
Selection of
PC serial port
Executes connection
to the Control Unit
Drop-down menu
The followings functions are included in the drop-down menus:
“File”menu
•New Creates a new project
•Open Opens an existing project
•Save Saves the current project
•Save as… Saves the project after requesting a file name
•Quit Exits the program
(*) Functions enabled only if a connection to the system has been enabled.
6
ThermoConfig
“Language”menu
•✔Selects the language of the application
“Help”menu
•About… (Information on) Displays information on the ThermoConfig program
•Supported versions Displays the Firmware versions of the 5739 18/19 Control Unit
managed by the ThermoConfig program
“Tools” menu
•Disconnect Enables/disables connection to Control Unit
•Upload Loads the configuration present in the device
•Download Downloads the configuration created in the device
•Update FW Downloads the firmware update
•Compare Loads the configuration present in the system in order to compare it with the
project opened
•Diagnosis Loads the diagnosis information of the Control Unit and probes
•Print on file Exports the configuration of the Control Unit in an Excel file (if Microsoft Excel
is installed on the PC) or csv file (if Microsoft Excel is not installed)
7
ThermoConfig
4. Work area The following windows are included in the ThermoConfig interface work area:
4.1 “Window”System
This window shows the tree structure of zones in the system.
“System”
Window
“Control unit”
Window
“Library profiles”
Window
Profiles
configuration
window
Main
window
•Add zone Adds a new address zone having the first available address
•Copy zone Adds a new address zone having the first available address, thus copying the
setup of the zone selected
•Cancel zone Cancels the zone selected
In the tree structure of the zones, if you click the right key of the mouse, the following operations will
be possible (this is also possible by using the buttons in the main window):
Tree structure
of zones
8
ThermoConfig
By selecting the single Zones, two options are displayed:
•Actuators
•Pumps
By clicking on each Actuator (e.g.: Actuator No. 1), it is possible to select the type of function required
(heating, cooling, heating + cooling or no function) and the Type of load (e.g.: heating) controlled by
the zone (ON/OFF, Open/Close, Fan Coil, DeLonghi).
When a zone is selected (e.g.: Zone 1), the Zone and Temperature setup section is displayed in the
main window:
•Description Name of the zone (e.g. Living room)
•Zone address Configurators (ZA,ZB) of the probe
•Heating temperature Setup for four levels of temperature
•Cooling temperature Setup for four levels of temperature
9
ThermoConfig
By clicking on each Pump (e.g.: Pump No. 1), it is possible to select the type of function required
(heating, cooling, heating + cooling or no function) and the activation Delays.
10
ThermoConfig
Programs
•Weekly programs Sets up the weekly heating/cooling programs
•Scenarios Sets up a scenario in which a certain temperature is associated with
each zone
•Holiday/weekend Sets up the heating/cooling programs for holidays
program
4.2 “Control unit”Window
This window shows the configuration parameters and the operating programs of the Control Unit.
Parameters
•Language Language on the display of the Control Unit
•Maintenance code Code to enter the Maintenance menu of the Control Unit (default
12345)
•User code enabled Enables/disables access to the menu of the Control Unit through the
user code. By selecting YES, the user code entry field will appear
•Contrast Adjusts the display contrast of the Control Unit
•Remote control enabled The Control Unit is controlled by other instruments (Touch screen,
Web File server)
