Lemon ART-4 Istruzioni per l'installazione

designs and all contents in this manual, may be made at any time

without prior notice.

Notice:

ART-4

ser Instruction

USER INSTRUCTION

P/N: 24-004-2564-00

Rev1.0

EU version

Physical Dimensions

Specification

Technical Specification

Power Supply ................................................

Housing .......................................................

DMX out ........................................................

PWM out .......................................................

Operation Temperature ..................................

Storage Temperature .....................................

Dimension .........................................

Weight ..........................................................

DC 12-24V

Polycarbonate

4-pin green terminal

6-pin green terminal

0 degC to +40 degC

-20 degC to + 70 degC

EU 100g

EU 86(L) x86(W) x15.5(H)mm

SPECIFICATION

ART-4 User Instruction

Setting Shortcuts

To delete power shortcut, touch "P" key and "Power" key simultaneously and

hold on for about 10 seconds until all keys flash once.

Directly touch any key on the panel. ART-4 starts up.

Touch "Power" key. ART-4 changes to standby condition.

To set power shortcut, touch "P" key and "Power" key at the same time and

hold on for about 10 seconds until all keys flash momentarily once to confirm

the setting.

Setup

2. "P"+"S"key (Press "S" & "P" key simultaneously)

To delete the above setting, touch "P" key and "S" key and hold on for about

10 seconds until all keys flash once.

At this time, the "S" key is out of effect, that is to say, Speed Adjustment

Menu is not valid. Besides, the figure keys(1, 2, 3 and 4) can only play back

saved scenes and colors, but can not record scenes or colors.

Touch "S" key and "P" key simultaneously and hold on for about 10s until all

keys flash once to confirm the setting.

1. "P" + "Power"( ) key

(Press "P" key and "Power" key simultaneously)

To delete the above two shortcuts at the same time, touch "P" key and "B"

key simultaneously and hold on for about 10s till all indicators flash once.

Then release the keys.

ART-4 User Instruction

Setting Color Exchange Fadetime

Touch "C" key and hold on for 5 seconds till all LED indicators flash once to

indicate the Color Fadetime Setting is engaged. Then release the key and

the "C" key flash repeatedly.

Different keys represent different fadetime. The following table details the

fadetime information.

Keys

Fadetime

12 34

1s 2s 3s 4s

P/C/B/S

0s (no fade time)

The existing mode ends and changes to normal mode automatically.

All indicators flash momentarily once to confirm the setting.

Touch any one of these keys--1, 2, 3, 4, P, C, B or S.

To set the fadetime for color exchange, you take the following procedures: CONTENT

INTRODUCTION

Product Description

Unpacking

Touch Interface View

Rear Panel View

SETUP

Setting Power On/Off Fadetime

Setting Color Exchange Fadetime

Setting Shortcut

Setting Key Tone

OPERATION

Four Function Menus

Built-in program menu

Color menu

Speed adjustment menu

Brightness adjustment menu

Two Modes

Auto mode

Manual mode

SPECIFICATION

Technical Specification

Physical Dimension

Powering ART-4 3

ART-4

ser Instruction

Product Description

Thank you for purchasing our digital product ART-4.You now hold a premiere

LED controller with DMX 512/PWM output. Its compact and portable design

is convenient to mount and easy to operate for users. It's key features consist

of as the following:

Touch interface

DMX 512/PWM output

LED indicator to display the current output

Four function menus

To record and play back upto 4 scenes and 4 colors

To set fadetime for Power on/off and color exchange

To set fadetime for Power on/off and color exchange in the range of 0 to 4s

To assign key tone ON/OFF

To select input voltage in DC12-24V according to the output loading voltage

Function memory and power failure protection

ntro

uct

Unpacking

Check for transport damage.

You should be in possession of the following items:

1ART-4

1 User manual

Every ART-4 has been tested at the factory before shipping to you. Please

spend a few minutes inspecting the package. Should you discover any

transport damage after unpacking the equipment, inform the hauler

immediately. Never connect a damaged device. You may also contact your

supplier.

INTRODUCTION

ART-4 User Instruction

SETUP

Setting Power on/off Fadetime

Different keys represent different fadetime. The following table details the

fadetime information.

Keys

Fadetime

12 34

1s 2s 3s 4s

P/C/B/S

0s (no fade time)

Touch "Power" key( ) and hold on for 5 seconds till all LED indicators flash

once to indicate the Power on/off Fadetime Setting is engaged. Then release

the Power key and the key flashes repeatedly.

The existing mode ends and changes to normal mode automatically.

All indicators flash momentarily once to confirm the setting.

Touch any one of these keys--1, 2, 3, 4, P, C, B or S.

To set power on/off fadetime, follow the procedures below:

Color Playback

Touch "C" key to enable Manual Mode, the key clicks and the indicator is lit.

In Manual mode, you play back the recorded colors as you wish. To play back

the recorded color, simply follow the procedures below:

Setup

ART-4 User Instruction

To select the recorded color which you wish to play back, touch any of the

figure keys to which you've saved colors. The key clicks and it's LED

indicator is lit. Then it starts to display the recorded colors.

Setting Key Tone

To turn on or turn off key tone, keep the four figure keys--"1", "2" , "3" and "4"

touched simultaneously until all keys flash momentarily once to confirm the

setting, then release them.

With key tone ON, when you rotate the touch toggle to the maximum or

minimum value, the key click disappears.

With key tone OFF, when you rotate the touch toggle to the maximum or

minimum value, all keys flash repeatedly 3 times.

Touch enable Auto Mode, the key clicks and the LED indicator

is lit.

"P"or"S"keyto

Repeat step a~d to save more scenes to the other 3 figure keys.

All indicators flash momentarily once to indicate the current parameters

(including the built-in program and the value of speed and brightness) have

been recorded and saved into the key.

Touch any of the figure keys to which you wish to record the scene, and hold

on for more than 2 seconds.

Scene Playback

In Auto mode, you play back the recorded scenes as you wish. To play back

the recorded scene, simply follow the procedures below:

Manual Mode

In Manual Mode, the RGB value and brightness can be adjusted. Up to 4

colors can be recorded and played back in this mode. Each figure key

corresponds to one color.

Touch "C" key to enable Manual Mode, the key clicks and the indicator is lit.

Color Record

Repeat step a~d to save more colors to the other 3 figure keys.

All indicators flash momentarily once to indicate the current parameters,

including the value of color and brightness, have been saved into the key.

Touch any of the figure keys to which you wish to record the color, and hold

on for more than 2 seconds.

Touch "P" or "S" key to enable Auto Mode, the key clicks and the LED indicator

is lit.

To select the recorded scene which you wish to play back, touch any of the

figure keys to which you have saved scenes. The key clicks and it's LED

indicator is lit. Then it starts to display the recorded scene.

In Manual mode, you can record a color to the desired figure key. The

procedure to record a color is described below:

Operation

Rotate the touch toggle to adjust RGB value until you get desired color.

ART-4 User Instruction

Rotate the touch toggle to select the built-in program or adjust the speed.

Scene Record

In Auto mode, you record a scene to the desired figure key as you wish. The

procedure to record a scene is described below:

Touch Interface View

ART-4 (EU)

1. Power key

7. Touch toggle

Menu keys:

5. "B" key

To select Brightness adjustment menu.

2. "C" key

To select Color menu.

3. "P' key

To select Built-in program menu.

4. "S" key

To select Speed adjustment menu.

6. Output Indicator

To display the current output.

To adjust color, brightness and speed, and select built-in programs.

8. figure keys (1~4)

To record scene and color, as well as set fadetime.

ntro

uct

To power on/off ART-4.

ART-4 User Instruction Pa

Operation

Four Function Menus

Built-in Program Menu

ART-4 contains 4 function menus, available in Built-in program selection,

Color selection, Brightness adjustment and Speed adjustment.

In Built-in Program Menu, there are 10 built-in programs and Auto Program

("Auto Program" is the sequential running of these 10 built-in programs). To

select desired built-in program in this mode, you proceed as the following:

Touch "P" key to enable Built-in Program Menu, the key clicks and the indicator

is lit.

Rotate the touch toggle to select a desired built-in pattern.

Powering ART-4

The process of selecting the built-in programs produces clicks and each

click will activate one program. When reaching Auto program or the 1st

program, the click disappears.

ART-4 can be connected to a DC power at any voltage from 12V to 24V.

Once the unit is connected to a main power, all the LED indicators flash

momentarily and the unit is powered on.

In normal mode, to touch power key ( ) and hold on for 2s, ART-4 switches

to the state of standby. At this time, the output is shut down. Touch the power

key once again and hold on for 2s, the unit is powered on.

OPERATION

ART-4 User Instruction

DMX OUT

PWM OUT

Made in P.R.C.

GND

RoHS

Data -

Data +

GND

+12-24V

Blue

Green

Red

POWER IN

1. DMX out: 4-pin male terminal

2. PWM out & Power in: 6-pin terminal

Rear Panel View

Color Menu

Brightness Adjustment Menu

In Color Menu, you adjust RGB value to get a desired color by rotating touch

toggle. T ou take the following procedure:o adjust RGB value, y

Touch "C" key to enable Color Menu, the key clicks and the indicator is lit.

Rotate the touch toggle to adjust RGB value.

In Brightness Adjustment Menu, it allows you to adjust the brightness by

rotating the touch toggle. You change the brightness as the following:

Two Modes

ART-4 has the following two modes: Auto Mode and Manual Mode.

Touch "B" key to enable Brightness Adjustment Menu, the key clicks and the

indicator is lit.

Rotate the touch toggle to adjust brightness as you wish. In clockwise, the

brightness increases; In anti-clockwise, the brightness decreases.

Each figure key can have a scene, or a color, or both elements recorded.

Operation

The value of color and brightness can be adjusted in the range of 0 to 255.

In the process of adjusting brightness and speed, the toggle produces clicks.

However, the click disappears when the toggle reaches the maximum

/minimum value.

Speed Adjustment Menu

In Speed Adjustment Menu, you adjust the speed of running built-in programs

in the range of 0.2s~10min. You set the speed as the following:

Touch "S" key to enable Speed Adjustment Menu, the key clicks and the

indicator is lit.

Rotate the touch toggle to adjust the speed. In clockwise, the speed will

increase; In anti-clockwise, the speed will decrease.

When you rotate the toggle to reach 10min, the click disappears and all the

four figure keys flash repeatedly. Then you select the speed which you wish

by touch any of the figure keys. Different figure keys stand for different

speed -- "1" for 10min, "2" for 20min, '3" for 30min and "4" for 40min.

ART-4 User Instruction

In Auto Mode, ART-4 runs built-in programs automatically. The speed and

brightness can be adjusted. Up to 4 scenes can be recorded and played

back in this mode. Each figure key corresponds to one scene.

Auto Mode

Indice

Altri manuali Lemon Controllori

Lemon

Lemon Stabilizer Plus Manuale utente

Manuali Controllori popolari di altre marche

Digiplex

Digiplex DGP-848 Istruzioni operative

YASKAWA

YASKAWA SGM series Manuale utente

Sinope

Sinope Calypso RM3500ZB Manuale utente

Isimet

Isimet DLA Series Style 2 Manuale di installazione

LSIS

LSIS sv-ip5a Manuale utente

Rockwell Automation

Rockwell Automation 1769-L31 Manuale utente

Airflow

Airflow Uno hab Manuale utente

ABB

ABB ACS580-01 drives Manuale utente

Panasonic

Panasonic GM1 Series Manuale utente

Emerson

Emerson SW93 Manuale utente

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuale utente

Panasonic

Panasonic FP? Positioning Unit RTEX Manuale utente

Samson

Samson Type 5824 Manuale di servizio

Alpha IP

Alpha IP MIOB 21001 Manuale utente

Siemens

Siemens OpenAir GMA 1 Series Manuale utente

Surecom

Surecom SR-629 Manuale utente

Fishman

Fishman TriplePlay Manuale utente

Regulus

Regulus SRS1 T Manuale utente
