LENCO DVD-305 Manuale utente

OWNER’S MANUAL

CAR-DVD

• Multi-subtitle Languages Function

• Multi-audio Languages Function

• Multi-angle Function

• Parental Control

• Remote Control

• USB Interface

• Memory Card Interface

DVD-305

Compatible with PAL DVD (Video

CD) and NTSC DVD (Video CD)

This player can play discs recorded in

either PAL or NTSC format.

• A single LSI chip now integrates all

major DVD playback circuit functions

including MPEG2 decoder, video D/A

converter, and audio decoders.

• L/R stereo analog audio outputs for

connection to existing head unit aux

inputs. Video output is composite

video.

• Supplied remote handles

multi-function software (multi-language

audio-track/subtitle, multi-angle, multi-

story, etc.), plus all basic functions.

USE THIS PRODUCT SAFELY

Use the Proper Power Supply

This product is designed to operate with

a 12 volt DC, negative ground battery

system.

Protect the Disc Mechanism

Avoid inserting any foreign objects into

the disc drive of this player. Failure to

observe this may cause malfunction due

to the precise mechanism of this unit.

Use Authorized Service Centres

Do not attempt to disassemble or adjust

this precision product. Please refer to

the Service Centre list included with this

product for service assistance.

FEATURES

CONTENTS

Safety Information......................................................................................................5

Disc Notes...................................................................................................................6

The Player ...................................................................................................................7

Front View...............................................................................................................7

Back View ...............................................................................................................8

Remote Control ..........................................................................................................9

Location and Function of Keys...............................................................................9

Preparing the Remote Control..............................................................................11

General Operation ....................................................................................................12

Turn the unit On/Off ..............................................................................................12

Basic Play .............................................................................................................12

DVD Video Menu Play...........................................................................................12

Mode Selection.....................................................................................................12

Menu function.......................................................................................................12

Advanced Operation ................................................................................................13

Repeat Play/Paragraph Repeat Play ....................................................................13

On-screen Display Function .................................................................................13

PAL/NTSC system selection.................................................................................14

Random Playing....................................................................................................14

Goto Function.......................................................................................................14

Zoom Function......................................................................................................14

Special Function for DVD .....................................................................................14

Special Function for VCD and CD ........................................................................15

Data Disc Play Operation......................................................................................15

Memory Card Operation.......................................................................................16

USB Play Operation..............................................................................................16

Setup..........................................................................................................................17

System Setup .......................................................................................................17

Language Setup ...................................................................................................17

Audio Setup ..........................................................................................................17

Trouble Shooting ......................................................................................................18

Specifications ...........................................................................................................19

PACK

Examine the contents of the box that you DV player was packed in. There should be

the following:

• DVD Player

• Remote Control with a button cell lithium battery (CR2025 3V)

• Cigarette Lighter Plug

• 9 - Pin AV Lead for Connection to DVD AV output

• AC/DC Adaptor for home use (OPTIONAL)

• Instruction Book

• Warranty Card

CAUTION:

MOBILE DVD PLAYER IS A CLASS I

LASER PRODUCT. HOWEVER THIS

MOBILE DVD PLAYER USES A

VISIBLE/INVISIBLE LASER BEAM

WHICH COULD CAUSE HAZARDOUS

RADIATION EXPOSURE IF DIRECTED.

BE SURE TO OPERATE THE MOBILE

DVD PLAYER CORRECTLY AS

INSTRUCTED.

USE OF CONTROLS OR

ADJUSTMENTS OR PERFORMANCE OF

PROCEDURES OTHER THAN THOSE

SPECIFIED HEREIN MAY RESULT IN

HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND - DO NOT

REPAIR YOURSELF. REFER SERVICING

TO QUALIFIED PERSONNEL.

WARNING:

• TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, DO NOT EXPOSE

THIS EQUIPMENT TO RAIN OR

MOISTURE.

• TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, AND ANNOYING

INTERFERENCE, USE ONLY THE

RECOMMENDED ACCESSORIES.

• THIS DEVICE IS INTENDED FOR

CONTINUOUS OPERATION.

This product incorporates copyright

protection technology that is protected

by method claims of certain U.S. patents

and other intellectual property rights

owned by Macrovision Corporation and

other rights owners. Use of this

authorized by Macrovision Corporation,

and is intended for home and other

limited viewing uses only unless

otherwise authorized by Macrovision

Corporation. Reverse engineering or

disassembly is prohibited.

SAFETY INFORMATION

Region Management Information

Region Management Information:

This Mobile DVD Player is designed and

manufactured to respond to the Region

Management Information that is recorded

on a DVD disc. If the Region number

described on the DVD disc does not

correspond to the Region number of this

Mobile DVD Player, this Mobile DVD

Player cannot play this disc.

DISC NOTES

Disc formats supported by this player

DVD

12 cm disc

Video CD

12 cm disc

MP3

12 cm disc

MPEG4

12 cm disc

Handling and Cleaning

• Dirt, dust, scratches and warping disc

will cause misoperation.

• Do not place stickers or make

scratches on discs.

• Do not warp discs.

• A disc should always be kept in its

case when not in use to prevent

damage.

• Do not place discs in the following

places:

1. Direct sunlight

2. Dirty, dusty and damp areas

3. Near car heaters

4. On the seats or dashboard

Disc Cleaning

Use a dry soft cloth to wipe the surface.

If the disc is quite dirty, use a soft cloth

slightly moistured with isopropyl (rubbing)

alcohol. Never use solvents such as

benzine, thinner or conventional record

cleaners as they may mar the surface of

the disc.

Note:

A disc may become somewhat scratched

(although not enough to make it

unusable) depending on your handle it

and conditions in the usage environment.

Note that these scratches are not an

indication of any problem with the player.

Rough spots

on inside edge

Ball point pen

or pencil

Rough spots on

outside edge

Label side up

Do not touch

the underside

of the disc

Do not bend

Wipe the disc from center

toward the outside edge

Preparing New Discs with Rough

Spots

A new disc may have rough edges on its

inside and outside edges. If a disc with

rough edges is used, the player may not

be able to play the disc. Therefore,

remove the rough edges in advance by

using a ball point pen or pencil as shown

on the right. To remove the rough edges,

press the side of the pen or pencil

against the inside and outside edges of

the disc.

THE PLAYER

FRONT VIEW

1. (POWER)

2. (Eject Button)

3. Reset Button

4. Disc Slot

5. /(PLAY/PAUSE)

6. IR (REMOTE SENSOR)

7. USB Interface

8. SD/MMC/MS Card interface

9. AUX IN

10. VIDEO IN 1

11. AUDIO IN 1L

12. AUDIO IN 1R

4 5 2

1211

10183679

13 14 15 1716 18 19 20

THE PLAYER

BACK VIEW

13. DC 12V INPUT Socket

14. DC 12V OUTPUT Socket

15. AV OUTPUT TYPE Switch

16. WAVE BAND Switch

17. REMOTE Socket

18. AUDIO/VIDEO OUTPUT 1

19. AUDIO/VIDEO OUTPUT 2

20. AUDIO/VIDEO INPUT 2

87.7 88.3 88.9

303132

Location and Function of Keys

REMOTE CONTROL

1. ZOOM Allows the picture to be increased in size.

2. MUTE Press to mute the sound.

3. RESUME When in stop mode, press the button, the play can be resumed

from the stop point.

4. SHUFFLE Allows the track played in random order.

5. A-B A-B repeat allows a passage to be repeated continuously.

6. REPEAT Switch the Repeat mode of discs.

7. GOTO Disc search button, cooperatively used with numeric buttons.

8. PROGRAM Allows the track played in the order you programmed.

9. Press to play the disc.

10. Press it for the first time to pre-stop the unit playback, press it

for the second time to stop the playback.

11. Press to pause playback.

12. 0-10 Numeric buttons

13. -/-- DigitAL select button, cooperatively used with numeric buttons.

14. CLEAR When you input a number in error, press the button to clear it.

15. SLOW / Changing for slow forward/reverse playback motion.

16. / Press to search forward rapidly & to search reverse rapidly.

17.

Press to skip to the next track & press to skip back one

track.

CH+/CH- In TV mode, press CH+/- to increase/decrease the channel.

18. VOLUME+/- Press VOLUME+/- button to increase or decrease the volume

level.

19. MENU Display the root menu that is stored on the DVD disc.

20. OK Confirm the Track/Chapter selected with the numeric buttons or

selected with the cursor buttons on screen display.

21. / , / In case of menu mode, / , / buttons served as cursor

buttons to select item left/right, ahead/back.

22. SETUP Display the SETUP menu.

23. TITLE Display the TITLE menu that is stored in DVD disc.

24. ANGLE Changing of the view angle on multi-angle DVD disc.

25. AUDIO Change of the AUDIO soundtrack on multi-audio soundtrack

DVD disc.

26. MODE Press it to change the mode among: Radio, AV-IN and DVD

mode.

27. P/N Switch between PAL mode and NTSC mode.

28. EJECT Press to eject the disc.

29. PBC Changing between PBC ON and PBC OFF on the VCD disc.

30. DISPLAY Display statistical disc information during playback.

31. SUB-T Changing of the SUBTITLE language on multi-subtitle language

DVD disc.

32. POWER Press POWER to turn the unit ON or OFF.
