LENCO XEMIO-200 Manuale utente

XEMIO-200USER MANUAL

Special Features

Elegantappearance and easyto use.

Multi-Code Player - Supporting MP1, MP2, MP3, WMA, formats.

Driver Free U Disk - You may manage your files directly through “Portable

Device” in “My Computer” on Windows 2000 Operating System or above

without driver.

Brief View of Player

A. About player’s battery

Player has an internal, non–user-replaceable rechargeable lithium battery.

For best results, the first time you use the player, let it charging for about 1 - 2

hours or until the charging LED lights go Offbefore you use it.

Charging the Battery

You can charge the Player’s battery in two ways:

1. Connect player to your computer. Or,

2. Use the USB power charger. (availableseparately)

B. Insert Micro SD Memory Card

This device is design without an internal memory; put a Micro SD memory card

insert into thememorycard slot before use the player.

Plug in the Micro SD memory card into player card slot at side, now you can

use the player.

You can upload your desired media files to the player, or, you can upload your

desired media files to the Micro SD memory Card direct with your computer

before insert it to the player.

When you want to insert / remove the Micro SD memory card from memory

card slot. Make sure the player is in Off status. Otherwise, the player functional

XEMIO-200USER MANUAL

maydead halt or the internal data / files will be lost / damaged.

Note: The status indicator light will be flashing fast and then will go Off, when you

want to turn On the player. However, the player will turn Off automatically If no

memorycard has inserted to player’s cardslot.

C. Key function of buttons

Appearance

Power ON –OFF switch: Main Power On and Off

button: To Play / Pause or StandbyOn / Off.

button:To previous song or fast-backward.

button: To the next song or fast-forward.

button:To increase volume level.

Button:To decrease volume level.

USB: For PC connection and charge function

XEMIO-200USER MANUAL

D. Getting start player

1 Turn On / Off

1.1 Plug in earphone set into player’s jack

1.2 Slide the Power ON–OFF to “ON”position, the player will turn On and

play music directly. (make sure the Micro SD memory card has

plugged

1.3 Press and hold button, for about 2 - 3 second, the player will turn

Off and On in standbymode.

2 Play / Pause Music

2.1 Press button to pause the playingmusic, press it again to play.

2.2 If player is in pause state for 3 minutes, it will be turned to Off

automatically.

3 Adjust Volume

3.1 Pressing / button to increase or decrease volume level.

3.2 Press and hold / button to increase or decrease volume level

faster.

4 Play Next / Previous Music

4.1 In playing mode, press button to select next music.

4.2 Press button to select previous music.

5 Play Fast-Forward / Fast-Backward

5.1 In playing mode, press and hold button to enter fast-forward

mode.

5.2 Press and hold button to enter fast-backwardmode.

E. USB mode

XEMIO-200USER MANUAL

1 Connect player to computer

1.1 Connect player to computer with the USB cable, then a “USB Mass

Storage Device” is detected and related driver is installed by you

computer. (Windows 2000 / XP System or about)

1.2 Aremovable disk drive will be shown in “My computer” folder, now you

can start Read / Write operation. And the battery is charging in

background.

1.3 In connection mode, the player can be play music if you press or

pressing the playbutton. However, the player maystop orstart playing

if removing the PC connection.

2 Remove player from computer:

Pleasesafetyto removes the player in computer, otherwise, the datastored in

the Player might loss.

2.1 If you’re using a Windows PC, you can disconnect the player in My

Computer or by clicking the “Safely Remove Hardware”icon in the

Windows system tray.

2.2 If you’re using a Mac, you can also disconnect player bydragging the

player icon on the desktop to the Trash.

2.3 And now, is safe to disconnect the player with your computer, unplug

the USB connector from player and then your computer.

2.4 If you’re accidentally disconnect player without disconnect it,

reconnect itto your computer.

2.5 At power ON mode, after remove the PC connection, the player will

auto-playthe music directly.

F. Indicator light function

Playing Mode: LED lightflashing once per second.

XEMIO-200USER MANUAL

Pause Mode:LED lightbright.

PC Connecting Mode:LED lightbright. (Charging in background)

Recharging Mode:LED light bright.

Recharge complete:LED light will go OFF

G. Troubleshooting

Playcannot turn ON

Check whether batteryhave enough energy.

Check whether the main power ON-OFF to slide to

ON position or not.

No sound is heard

Check whether Volume is set to “minimum” and

connect the headphone plugs firmly.

Check whether the headphone plug is dirty.

Corrupted WMA / MP3 maymake a static noise and

the soundmaycut off. Make sure that the music files

are not corrupted.

Check whethermusic files format are support.

Download of music

files fails.

Check whether player’s USB connector is connected

with computer properly.

Check whether driver is installed correctly.

Check whether the player’s memory is in full.

Check whether the Micro SD memory card is

inserted.

H. Specification

Dimension

43 mm (H) x29.8 mm (W) x15 mm (D)

Weight

14.5 g

PC Connection

USB 2.0 (High Speed)

XEMIO-200USER MANUAL

Earphone Impedance

32 Ohm

Internal Memory

Nil

External Memory

Micro SD MemoryCard (up to 8GB)

Battery

Built-in Rechargeable Lithium battery(3.7V110mA)

Playing Time: about 4-5 Hours

Supports Music Format

MP3

32kbps - 320kbps

WMA

32kbps –384kbps

Audio

Earphone Output Power

L: 275mV(32 Ohm)

R: 275mV(32 Ohm)

FrequencyResponse

20Hz–20,000Hz

SNR

80dB

Operation Temperature

-0℃- 40℃

Operation Systems

Windows 98/SE/ME2000/XP/Vista/Win7, MAC9.2 or

above

Note:Product design and specification aresubject to change without prior notice.

I. Recycling

If at any time in the future you should need to dispose of this

product, please note that: Waste electrical products should not be

disposed of with household waste. Please recycle where facilities

exist. Check with your LocalAuthorityor Retailer for recycling advice.

(Waste Electrical and Electronic Equipment Directive)

For information andsupport, www.lenco.eu
