Lenovo A536 Manuale utente
Read this guide carefully before using your smartphone.
Quick Start Guide v1.0
Lenovo A536
Type: CMOS
Pixels: 5 megapixels Auto focus (Rear)
2 megapixels Fix focus (Front)
CPU: MTK MT6582m
,
Quad Core
,
1.3 GHz
Size: 5.0 inches Screen: 2-touch
Resolution: 854 × 480 pixels LCD type: TN
Model: Lenovo A536 System: Android
Bluetooth 4.0; WLAN 802.11 b/g/n; WCDMA, GSM; GPS
Battery: 2000 mAh
Height: 139.6 mm (5.50 inches) Width: 72 mm (2.83 inches)
Depth: 9.95 mm (0.39 inch) Weight: Circa 148 g
Model and system
① Depending on the measuring method, the dimensions and weight
might vary slightly.
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless Communication
Technical specifications
Front-facing
camera
Flashlight Speaker
1
4
7
2
5
8
3
6
9
2
4
65
7
8
10
11
Indicator
Micro USB
connector
9
Microphone
1
On/Off button
10
Rear-facing
camera
Headset
connector
3
11 Volume buttons
Receiver
First glance
Step 1. Open the back cover.
Step 2. Insert the SIM cards and
the memory card.
Tip: Insert the (U)SIM card into
SIM1 slot and SIM card
into SIM2 slot.
Step 3. Install the battery.
a. Align the battery
connectors on the battery
with the pins in the
battery compartment.
b. Push the battery down
into place.
Step 4. Install the back cover.
You must insert the SIM card provided by your carrier to use cellular
services. Set up your smartphone as shown.
Always turn off your smartphone first before you insert or remove a
SIM card. Insert or remove a SIM card with your smartphone on may
damage your SIM card or smartphone permanently.
a
b
SIM1
SIM2
SIM1
SIM2
Preparing your smartphone
Radio and Telecommunications Terminal Equipment
Directive
This product is in compliance with the essential requirements
and other relevant provisions of the Radio and Telecommuni-
cations Terminal Equipment Directive, 1999/5/EC.
European Union conformity
11219325-00 GP
Printed in China
First Edition (July 2014) © Copyright Lenovo 2014.
Learning more
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the
United States, other countries, or both.
Other company, product, or service names may be
trademarks or service marks of others.
To learn more information about your Lenovo smartphone and
obtain the latest smartphone manuals, go to:
http://support.lenovo.com/.
Getting support
For support on network service and billing, contact your
wireless network operator. For instructions on how to use your
device, go to: http://support.lenovo.com/.
