Lenovo IDEAPHONE S720 Manuale utente
1
User’sManual
Model: Lenovo S720
Read this manual carefully
before operating the handset
Lenovo Mobile Phone
English
2
Technical Parameters
Product: WCDMA digital mobile phone
Model: Lenovo S720
System: Android 4.0.4
Size: Approximately 132.4*68.5*10.2mm
Weight: Approximately146g (including battery)
Standby time: Max 387 hours *
Battery capacity：2000 mAh
*may vary depending on local signal strength
SAR Information
0.469W/Kg@1g(HEAD) 0.376W/kg@1g(BODY)
Body-worn Operation
This device was tested for typical body-worn operations. To comply
with RF exposure requirements, a minimum separation distance of
1.0 cm must be maintained between the user’s body and the handset,
including the antenna. Third-party belt-clips, holsters, and similar
accessories used by this device should not contain any metallic
components. Body-worn accessories that do not meet these
requirements may not comply with RF exposure requirements and
should be avoided.
Use only the supplied or an approved antenna. Unauthorized
antennas, modifications, or attachments could impair call quality,
damage the phone, or result in violation of regulations. Do not use
the phone with a damaged antenna. If a damaged antenna comes
into contact with the skin, a minor burn may result. Please contact
your local dealer for replacement antenna.
Manufactured under license from Dolby Laboratories. Dolby
and the double-D symbol are trademarks of Dolby
Laboratories。
3
Procedure Initial Setup Procedure
Charging the phone
Inserting the SIM card
Inserting the memory
card
4
Port Assignment and Button Layout
Camera ke
y
Power ke
y
Volume key
5
Applications Overview
Browser
Browses websites. The web browser in this
unit can access the Internet via the WIFI
network for business and personal use.
Email Receives/Sends and views mails by linking
directly to your mailbox.
Gallery
Browses and edits images. In an image
full-screen page it supports slideshow
functions and such operations as, Share,
Set as, and Details.
Contacts Allows you to add or delete contacts and
edit or delete particulars of a contact.
LeCalendar
Creates new events, toggles the day view,
the week view and the month view, and
enables the event reminder function.
6
Gravity sensor and multi-touch
Auto rotate screen according to the rotation of the device. You can
lock the S720 screen in the current direction screen rotation lock
downward. To unlock the screen direction: Menu - System settings -
Display - Auto-rotate screen.
Use the S720 in the landscape or portrait mode
After launching one application, you can rotate the screen to your
preferred direction.
7
Use the multi-touch function
The multi-touch function enables you to perform various operations
on the screen.
Open an application
Open an application: Tap the icon of this application
on the screen. By clicking home key, you can return
to the home screen.
Scroll
Scroll the screen by
dragging up or down on the
content.
Zoom in or out
You can zoom in or out a map or web page while
viewing it. To do so, just move your two fingers
apart or together.
8
Precautions and Tips for S720
Never drop, strike, scratch, twist, knock, vibrate or push the S720 or
place any heavy objects on it.
Gently touch the S720.
Keep the S720 away from any magnetic substances, mobile phones
in conversation, electrical appliances or speakers.
Avoid exposing the S720 to extreme temperatures (lower than -10°C
or higher than 45°C).
Do not place the S720 in a damp environment.
Do not use corrosive detergents or solvents to clean your S720. Just
wipe the S720 screen with a damp, soft, lint-free cloth to clear
fingerprints off it.
9
Panduan Penggunaan
Model: Lenovo S720
Baca panduan ini dengan baik sebelum
menggunakan ponsel
Ponsel Lenovo
Bahasa
Indonesia
10
Parameter Teknis
Produk: Ponsel digital WCDMA
Model: Lenovo S720
Sistem: Android 4.0.4
Ukuran: Sekitar 132.4*68.5*10.2mm
Berat: Sekitar 146gr (termasuk baterai)
Waktu siaga: Maks. 465 jam *
Kapasitas baterai:2000 mAh
*bervariasi tergantung kekuatan sinyal lokal
Diproduksi berdasarkan lisensi dari Dolby Laboratories. Dolby dan
lambang D ganda adalah merek dagang Dolby Laboratories.
