Lenovo P70 Manuale utente
English/Bahasa Indonesia
Quick Start Guide v1.0
Lenovo P70
English
Learning more
Getting support
Read this guide carefully before using your smartphone.
To learn more information about your
Lenovo smartphone and obtain the latest
smartphone manuals, go to:
http://support.lenovo.com/.
For support on network service and billing,
contact your wireless network operator.
For instructions on how to use your
device, go to:
http://support.lenovo.com/.
Legal notices Lenovo and the Lenovo logo are
trademarks of Lenovo in the United States,
other countries, or both.
Other company, product, or service names
may be trademarks or service marks of
others.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
Type: CMOS
Pixels: 13.0 megapixels (back) + 5.0 megapixels (front)
Processor: MTK MT6752
,
Octa Core
,
1.7 GHz
Size: 5.0 inches
Resolution: 1280 × 720 pixels
Model: Lenovo P70-A
Battery: 3900 mAh
Height: 142 mm (5.59 inches)
Depth: 8.9 mm (0.35 inch)
Model and system
① Depending on the measuring method, the dimensions and weight
might vary slightly.
② In some countries, LTE is not supported. To know if your
smartphone works with LTE networks in your country, contact
your carrier.
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless Communication
Width: 71.8 mm (2.83 inches)
Weight: 149 g (0.328 lb)
System: Android
Screen: multi-touch
LCD type: IPS
Bluetooth 4.0; WLAN 802.11 b/g/n; ②LTE, WCDMA, GSM; GPS
Technical specifications
2
Microphone
Flashlight
Micro USB
connector
Speaker
On/Off button
Volumebuttons
Receiver
1
4
7
10
5
8
3
6
9
2
1
4
3
5
Front-facing
camera
Rear-facing
camera
Headset
connector
6 7
8
6
10
9
First glance
You must insert the SIM card provided by your carrier to use cellular
services. Set up your smartphone as shown.
Step 1. Open the back cover.
Tip: The battery is unremovable,
Please do not pull the
battery, otherwise it will
damage the phone.
Step 2. Insert the (U)SIM cards.
Tip: Insert the (U)SIM card into
SIM1 slot and SIM card into
SIM2 slot.
Step 3. Insert the memory card.
Step 4. Install the back cover.
SIM card. Insert or remove a SIM card with your smartphone on may
damage your SIM card or smartphone permanently.
microSD
microSD
Preparing your smartphone
Turning on or turning off your smartphone
Turn on: Press and hold the On/Off button until
the Lenovo logo appears.
Turn off:
Press and hold the On/Off button for a
few seconds, then tap Power off.
Your smartphone has a rechargeable battery. For more information
about battery safety, see the “Rechargeable battery notice” in the
Important Product Information Guide shipped with your smartphone.
Low battery power Fully charged Charging
2
1
Charge the battery as shown.
Method 1.
Method 2.
Connect your smartphone to a power outlet using the
cable and USB power adapter that come with your
smartphone.
Connect your smartphone to a computer using the cable
that comes with your smartphone.
Charging the battery
Pelajari lebih lanjut Untuk mengetahui informasi
selengkapnya tentang ponsel cerdas
Lenovo dan mendapatkan panduan
ponsel cerdas terbaru, kunjungi:
http://support.lenovo.com/.
Untuk dukungan penagihan dan
layanan jaringan, hubungi operator
jaringan nirkabel Anda. Untuk petunjuk
cara menggunakan perangkat Anda,
kunjungi: http://support.lenovo.com/.
Lenovo dan logo Lenovo adalah merek
dagang dari Lenovo di Amerika Serikat,
negara lain, atau keduanya.
Perusahaan, produk, atau nama layanan
lainnya mungkin merek dagang atau
merek layanan dari pihak lain.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
Bahasa Indonesia
Baca panduan ini dengan saksama sebelum menggunakan
ponsel cerdas.
Mendapatkan
dukungan
Pemberitahuan
hukum
Jenis: CMOS
Piksel: 13,0 megapiksel (belakang) + 5,0 megapiksel (depan)
Prosesor: MTK MT6752, Octa Core, 1,7 GHz
Ukuran: 5,0 inci Layar: multisentuh
Resolusi: 1280 × 720 piksel Tipe LCD: IPS
Model: Lenovo P70-A Sistem: Android
Bluetooth 4.0; WLAN 802.11 b/g/n; LTE, WCDMA, GSM;
GPS
Baterai: 3900 mAh
Tinggi: 142 mm (5,59 inci) Lebar: 71,8 mm (2,83 inci)
Tebal: 8,9 mm (0,35 inci) Bobot: 149 g (0,328 lb)
Model dan sistem
Tergantung pada metode pengukuran, ukuran dan berat mungkin
sedikit berbeda.
Di beberapa negara, LTE tidak didukung.Untuk mengetahui apakah
ponsel cerdas Anda dapat digunakan dengan jaringan LTE di negara
Anda, hubungi operator Anda.
Display
Baterai
Prosesor
Ukuran dan berat
Kamera
Komunikasi Nirkabel
Spesifikasi teknis
②
②
Tampilan sekilas
Konektor USB
Mikro
Mikrofon
Tombol
Nyala/Mati
Konektor
headset
Tombol
Volume
Kamera depan
1
4
7
10
2
5
8
3
6
9
Senter
Unit penerima
Speaker
Kamera belakang
2
1
4
3
56 7
8
6
10
9
Langkah 1. Buka penutup belakang.
Langkah 2. Masukkan kartu (U)SIM.
Saran:
Baterainya tidak dapat
dilepas, dan terpasang
permanen pada ponsel.
Harap jangan tarik
baterai, jika tidak
ponselnya akan rusak.
Saran:
Masukkan kartu (U)SIM
ke slot SIM1 dan kartu
SIM ke slot SIM2.
Langkah 3. Masukkan kartu memori.
Langkah 4. Pasang penutup
belakang.
Untuk menggunakan layanan seluler, pasang kartu SIM yang
disediakan oleh operator seluler Anda. Siapkan ponsel cerdas Anda
seperti yang ditunjukkan.
Selalu matikan ponsel cerdas Anda lebih dulu sebelum Anda
memasukkan atau melepaskan kartu SIM. Memasukkan atau
melepaskan kartu SIM dengan ponsel cerdas masih menyala dapat
merusak kartu SIM atau ponsel cerdas Anda secara permanen.
Menyiapkan ponsel cerdas
microSD
microSD
