Lenovo AIO 7 Gen3 Manuale utente

User Guide

Yoga AIO 7 Gen3

Read this first

Before using this documentation and the product it supports, ensure that you read and understand the

following:

Safety and Warranty Guide

Generic Safety and Compliance Notices

Setup Guide

First Edition (May 2022)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services

Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-

35F-05925.

Contents

About this do umentation . . . . . . . . iii

Chapter 1. Meet your omputer . . . . . 1

Front . . . . . . . . . . . . . . . . . . . . 1

Rear . . . . . . . . . . . . . . . . . . . . 2

Features and specifications . . . . . . . . . . . 3

USB specifications . . . . . . . . . . . . . . 3

Operating environment . . . . . . . . . . . . . 5

Chapter 2. Get started with your

omputer . . . . . . . . . . . . . . . . . 7

Work with Windows . . . . . . . . . . . . . . 7

Windows help information . . . . . . . . . . 7

Connect an external display . . . . . . . . . . . 8

Chapter 3. Explore your omputer . . . 9

Adjust the computer stand . . . . . . . . . . . 9

Lenovo Vantage. . . . . . . . . . . . . . . . 9

Set the power plan . . . . . . . . . . . . . 10

Transfer data . . . . . . . . . . . . . . . . 10

Connect to a Bluetooth-enabled device (for

selected models) . . . . . . . . . . . . 10

Connect to the wired Ethernet . . . . . . . 10

Purchase accessories . . . . . . . . . . . . 11

Chapter 4. CRU repla ement . . . . . 13

CRU list . . . . . . . . . . . . . . . . . . 13

Remove or replace a CRU. . . . . . . . . . . 13

Power cord and ac power adapter. . . . . . 13

Camera (for selected models) . . . . . . . 14

Chapter 5. Help and support . . . . . 15

Frequently asked questions . . . . . . . . . . 15

Self-help resources . . . . . . . . . . . . . 15

Call Lenovo . . . . . . . . . . . . . . . . 17

Before you contact Lenovo . . . . . . . . 17

Lenovo Customer Support Center . . . . . . 17

Purchase additional services. . . . . . . . . . 18

Appendix A. Noti es and

trademarks . . . . . . . . . . . . . . . 19

ii User Guide

About this do umentation

This guide applies to the Lenovo product models listed below. Illustrations in this guide may look slightly

different from your product model.

Model name Ma hine types (MT)

Yoga AIO 7 27ARH7 F0GS

For further compliance information, refer to the Generic Safety and Compliance Notices at

https://pcsupport.lenovo.com/docs/generic_notices.

Depending on the model, some optional accessories, features, and software programs might not be

available on your computer.

Depending on the version of the operating systems and programs, some user interface instructions might

not be applicable to your computer.

Documentation content is subject to change without notice. Lenovo makes constant improvements to the

documentation of your computer, including this User Guide. To get the latest documentation, go to

https://pcsupport.lenovo.com.

Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update.

As a result, some information in this documentation might become outdated. Refer to Microsoft resources

for the latest information.

iv User Guide

Chapter 1. Meet your omputer

Front

1. Microphones (2) 2. Camera connector

3. Air vents (2) 4. On-Screen-Display (OSD) adjustment joystick

5. Power button 6. Reset button*

7. Switch button 8. Combo audio jack

9. USB 3.2 connector Gen 2 10. USB-C® (3.2 Gen 2) connector

* for selected models

Power indi ator

Show the system status of your computer.

On: The computer is on, or in sleep or hibernation mode.

Off: The computer is off.

Related topi s

“USB specifications” on page 3.

Rear

1. Power connector 2. DisplayPort™ out connector

3. Always On USB 3.2 connector Gen 2 4. Ethernet connector

5. USB 2.0 connectors (2) 6. USB-C (3.2 Gen 2) connector

Always On USB 3.2 onne tor Gen 2

With the Always On USB feature enabled, the Always On USB 3.2 connector Gen 2 can charge a USB-

compatible device when the computer is on, off, in sleep mode, or in hibernation mode.

Related topi s

“USB specifications” on page 3.

“Connect an external display” on page 8

“Connect to the wired Ethernet” on page 10.

2User Guide

Features and spe ifi ations

For detailed specifications of your computer, go to https://psref.lenovo.com.

Hardware To view the hardware information of your computer, type device manager in the

Windows search box and then press Enter.

Power supply 170-watt automatic voltage-sensing power supply

300-watt automatic voltage-sensing power supply

Ele tri al input Input voltage: From 100 V ac to 240 V ac

Input frequency: 50–60 Hz

Mi ropro essor To view the microprocessor information of your computer, type system

information in the Windows search box and then press Enter.

Memory Low power double data rate 5 (LPDDR5)

Storage devi e

M.2 solid-state drive

To view the storage drive capacity of your computer, type disk management in the

Windows search box and then press Enter.

Note: The storage drive capacity indicated by the system is less than the nominal

capacity.

Expansion 3 M.2 slots (1 for Wi-Fi and BT, 2 for PCIE SSD)

Network features

Bluetooth*

Ethernet LAN

Wireless LAN*

* for selected models

USB spe ifi ations

Note: Depending on the model, some USB connectors might not be available on your computer.

Chapter 1.Meet your computer 3

Conne tor name Des ription

USB 2.0 connector

USB 3.2 connector Gen 1 or USB 3.2 connector

Gen 2

USB 3.2 connector Gen 2

Connect USB-compatible devices, such as a USB

keyboard, USB mouse, USB storage device, or USB

printer.

USB-C (3.2 Gen 1) connector or USB-C (3.2 Gen

2) connector

USB-C (3.2 Gen 2) connector

Thunderbolt 3 connector (USB-C)

Thunderbolt 4 connector (USB-C)

Charge USB-C compatible devices with the output

voltage and current of 5 V and 3 A.

Connect to an external display:

– USB-C to VGA: 1920 x 1200 pixels, 60 Hz

– USB-C to DP: 3840 x 2160 pixels, 60 Hz

Connect to USB-C accessories to help expand your

computer functionality. To purchase USB-C

accessories, go to https://www.lenovo.com/accessories.

Statement on USB transfer rate

Depending on many factors such as the processing capability of the host and peripheral devices, file

attributes, and other factors related to system configuration and operating environments, the actual transfer

rate using the various USB connectors on this device will vary and will be slower than the data rate listed

below for each corresponding device.

USB devi e Data rate (Gbit/s)

3.2 Gen 1 / 3.1 Gen 1 5

3.2 Gen 2 / 3.1 Gen 2 10

3.2 Gen 2 × 2 20

Thunderbolt 3 (USB-C) 40

Thunderbolt 4 (USB-C) 40

4User Guide
