Lenovo C100 - IdeaCentre - Desktop PC Manuale utente

Version 2.0 2009.8

User Guide

3000 C100 Series

3000 C100

31039393

31039393_3000 C100_UG_FM_EN_V2.01 1 2009.7.23 10:59:36 AM

Important Safety Information

Before using this manual, it is important that you read and understand all of the

related safety information for this product. Refer to the Safety and Warranty Guide

that you received with this product for the latest safety information. Reading and

understanding this safety information reduces the risk of personal injury or damage

to your product.

Danger: Be aware of extremely hazardous or lethal situations.

Attention: Be aware of possible damage to programs, devices, or data.

Note: Pay attention to this important information.

31039393_3000 C100_UG_EN_V2.0.in1 1 2009.8.21 2:12:27 PM

31039393_3000 C100_UG_EN_V2.0.in2 2 2009.8.21 2:12:27 PM

Contents

Important Safety Information

Chapter 1 Using the Computer Hardware.............................. 1

1.1 Front view................................................................................2

1.2 Rear view ................................................................................2

1.3 Computer stand .....................................................................3

1.4 Connecting your computer ......................................................4

1.5 Computer instruction ...............................................................8

1.6 Keyboard and Mouse (wired) .................................................10

Chapter 2 Using the Rescue System .................................... 11

2.1 OneKey Recovery..................................................................12

2.2 Driver and Application Installation ..........................................12

2.3 System Setup ........................................................................13

2.4 System Backup .....................................................................14

2.5 System Recovery ..................................................................14

2.6 Create Recovery Disc ............................................................14

Chapter 3 Using the Computer Software ............................. 15

3.1 Power2Go — Burning Discs .................................................16

3.2 WinDVD.................................................................................17

3.3 McAfee Security Center.........................................................18

Chapter 4 System Maintenance and Recovery.................... 19

4.1 Restoring the System ............................................................20

4.2 Backup and Restore..............................................................20

4.3 Cleaning Up the Disk .............................................................20

4.4 Checking For, and Correcting Disk Errors ..............................21

4.5 Defragmenting the Disk(s)......................................................21

31039393_3000 C100_UG_EN_V2.0.in1 1 2009.8.21 2:12:27 PM

2Contents

4.6 Performing Daily Maintenance Tasks......................................21

Chapter 5 Troubleshooting and Conﬁrming Setup.............. 23

5.1 Troubleshooting Display Problems .........................................24

5.2 Troubleshooting Audio Problems ...........................................25

5.3 Troubleshooting Software Problems.......................................25

5.4 Troubleshooting Problems with Optical Drives and

Hard Disks.............................................................................26

5.5 Special considerations for troubleshooting Windows .............27

31039393_3000 C100_UG_EN_V2.0.in2 2 2009.8.21 2:12:27 PM

Chapter

This chapter contains the following

topics:

ÿComputer hardware introduction

ÿInformation on computer connections

Note: The descriptions in this chapter might

vary from your computer, depending on

computer models and conﬁgurations.

User Guide 1

Using the Computer Hardware

31039393_3000 C100_UG_EN_V2.0.in1 1 2009.8.21 2:12:29 PM

2User Guide

1.1 Front view

1 2 3

Brightness up button Camera

Brightness down button Optical drive slot

LCD On/Off USB ports (2)

Power button Built-in microphone

1.2 Rear view

10 11

31039393_3000 C100_UG_EN_V2.0.in2 2 2009.8.21 2:13:15 PM

User Guide

Power connector Ethernet connector

PS/2 Keyboard connector Microphone connector

USB ports (2) Headphone connector

1.3 Computer stand

54˚

35˚

Use the stand to position the display to your preference. It can be rotated

between 35º and 54º from the chassis.

The stand provides stability to the computer; it is not a removable part.

Attention:

1. The computer stand must remain installed at all times to ensure maximum

system stability.

2. Make sure the angle of the stand is at least 35 degrees from the chassis.

otherwise the computer will be unstable and could fall over.

31039393_3000 C100_UG_EN_V2.0.in3 3 2009.8.21 2:13:16 PM

4User Guide

To open the computer stand, do the following:

1.4 Connecting your computer

Use the following information to connect your computer:

• Look for the small connector icons on the back of your computer. Match the

connectors to the icons.

Note: Your computer might not have all of the connectors that are

described in this section.

1.4.1 Check the voltage rating before you connect the

equipment to an electrical outlet to ensure that the

required voltage and frequency match the available

power source.

If your computer uses an AC adapter:

Note: Use only the Lenovo provided AC adapter approved for use with this

device. Use of another AC adapter may cause a ﬁre or explosion.

1.4.2 Connect the keyboard cable to the appropriate keyboard

connector (PS2 connector or USB connector).

31039393_3000 C100_UG_EN_V2.0.in4 4 2009.8.21 2:13:18 PM

User Guide

1.4.3 Connect the mouse cable to the appropriate mouse

connector (USB connector).

1.4.4 If you have audio devices, attach them using the

following instructions:

1 2

Microphone Use this connector to attach a microphone (purchased separately)

to your computer when you want to record sound or if you use

speech-recognition software.

Headphone Use this connector to attach headphones (purchased separately)

to your computer when you want to listen to music or other

sounds without disturbing anyone.

1.4.5 If you have powered speakers with an adapter:

(This picture is only a sketch print, it does not show the actual ﬁgure of the speaker)

31039393_3000 C100_UG_EN_V2.0.in5 5 2009.8.21 2:13:19 PM
