Lenovo C205 Manuale utente

Version 2.0

Machine type: 10063/7729

2010.11

Lenovo

C2 Series

User Guide

31046784

Important Safety Information

Before using this manual, it is important that you read and understand all of the

related safety information for this product. Refer to the Safety and Warranty Guide

that you received with this product for the latest safety information. Reading and

understanding this safety information reduces the risk of personal injury or damage

to your product.

Danger: Be aware of extremely hazardous or lethal situations.

Attention: Be aware of possible damage to programs, devices, or data.

Note: Pay attention to this important information.

Contents

Important Safety Information

Chapter 1 Using the Computer Hardware.............................. 1

1.1 Front view of the computer......................................................2

1.2 Left and right view of the computer .........................................3

1.3 Rear view of the computer.......................................................4

1.4 Computer stand ......................................................................5

1.5 Connecting your computer ......................................................6

1.6 Important information about using the computer ...................10

1.7 Keyboard and Mouse (wired) .................................................11

Chapter 2 Touch Screen Instructions ................................... 13

2.1 Method of touch screen calibration........................................14

2.2 Normal operation...................................................................15

Chapter 3 Using the Rescue System .................................... 17

3.1 OneKey Recovery..................................................................18

3.2 Driver and Application Installation ..........................................18

3.3 System Setup........................................................................19

3.4 System Backup .....................................................................20

3.5 System Recovery ..................................................................20

3.6 Create Recovery Disc ............................................................20

Chapter 4 Using the Computer Software ............................. 21

4.1 Lenovo Dynamic Brightness system ......................................22

4.2 Lenovo Eye Distance System ................................................23

2Contents

Chapter 5 Troubleshooting and Conﬁrming Setup.............. 25

5.1 Troubleshooting Display Problems .........................................26

5.2 Troubleshooting Audio Problems ...........................................27

5.3 Troubleshooting Software Problems.......................................27

5.4 Troubleshooting Problems with Optical Drives and

Hard Disks.............................................................................28

5.5 Special considerations for troubleshooting Windows .............29

5.6 Performing Daily Maintenance Tasks......................................30

Chapter

This chapter contains the following

topics:

Computer hardware introduction

Information on computer connections

Note: The descriptions in this chapter might

vary from your computer, depending on

computer models and conﬁgurations.

User Guide 1

Using the Computer Hardware

2User Guide

1.1 Front view of the computer

6 7 8 93 4 5

Built-in microphone

Camera

Hard disk drive indicator

Wireless LAN card indicator

LCD ON/OFF indicator (When turning on the LCD, the indicator light will be

off; when turning off the LCD, the indicator light will be solid on.)

Brightness down

Brightness up

LCD ON/OFF

Power button

User Guide

1.2 Left and right view of the computer

Attention: Be sure not to block any air vents on the computer. Blocked

air vents may cause thermal problems.

Memory card reader Microphone connector

USB ports (2) Optical drive slot

Headphone connector

4User Guide

1.3 Rear view of the computer

USB ports (3) PS/2 keyboard connector

Ethernet connector Power connector

TV tuner port (selected models)

User Guide

1.4 Computer stand

20°

5°

Use the stand to position the display to your preference.It can be adjusted from 5˚

forward to 20˚ backward.

The stand provides stability to the computer; it is not a removable part.

Attention: The computer stand must remain installed at all times to

ensure maximum system stability.
