Lenovo IdeaCentre B500 Manuale utente

Version 1.0

Machine type: 10026

10039

2009.10

Lenovo

IdeaCentre B5 Series

User Guide

31040007

31040007_IC B5_UG_FM_EN_V1.0.ind1 1 2009.10.22 10:44:10 AM

Important Safety Information

Before using this manual, it is important that you read and understand all of the

related safety information for this product. Refer to the Safety and Warranty Guide

that you received with this product for the latest safety information. Reading and

understanding this safety information reduces the risk of personal injury or damage

to your product.

Danger: Be aware of extremely hazardous or lethal situations.

Attention: Be aware of possible damage to programs, devices, or data.

Note: Pay attention to this important information.

31040007_IC B5_UG_EN_V1.0.indd 1 2009.10.21 4:49:45 PM

31040007_IC B5_UG_EN_V1.0.indd 2 2009.10.21 4:49:45 PM

Contents

Important Safety Information

Chapter 1 Using the Computer Hardware.............................. 1

1.1 Front view................................................................................2

1.2 Left and right view of the computer..........................................3

1.3 Rear view of the computer.......................................................4

1.4 Computer stand ......................................................................5

1.5 Connecting your computer ......................................................6

1.6 Important information about using the computer .....................9

1.7 Keyboard...............................................................................11

1.8 Using the Infra-red (IR) Remote Control ................................12

1.9 Using the Bluetooth remote control .......................................15

Chapter 2 Using the Rescue System .................................... 27

2.1 OneKey Recovery..................................................................28

2.2 Driver and Application Installation ..........................................28

2.3 System Setup ........................................................................29

2.4 System Backup .....................................................................30

2.5 System Recovery ..................................................................30

2.6 Create Recovery Disc ............................................................30

Chapter 3 Using the Computer Software ............................. 31

3.1 Power2Go - Burning Discs ....................................................32

3.2 WinDVD.................................................................................33

3.3 McAfee Security Center.........................................................34

3.4 Media Show ..........................................................................35

3.5 Lenovo CamSuite ..................................................................36

31040007_IC B5_UG_EN_V1.0.indd 1 2009.10.21 4:49:46 PM

2Contents

Chapter 4 System Maintenance and Recovery.................... 37

4.1 Restoring the System ............................................................38

4.2 Backup and Restore..............................................................38

4.3 Cleaning Up the Disk .............................................................38

4.4 Checking For, and Correcting Disk Errors ..............................39

4.5 Defragmenting the Disk(s)......................................................39

4.6 Performing Daily Maintenance Tasks......................................39

Chapter 5 Troubleshooting and Conﬁrming Setup.............. 41

5.1 Troubleshooting Display Problems .........................................42

5.2 Troubleshooting Audio Problems ...........................................43

5.3 Troubleshooting Software Problems.......................................43

5.4 Troubleshooting Problems with Optical Drives and

Hard Disks.............................................................................44

5.5 Special considerations for troubleshooting Windows .............45

5.6 Wireless keyboard and mouse instructions ............................46

31040007_IC B5_UG_EN_V1.0.indd 2 2009.10.21 4:49:46 PM

Chapter

This chapter contains the following

topics:

ÿComputer hardware introduction

ÿInformation on computer connections

Note: The descriptions in this chapter might

vary from your computer, depending on

computer models and conﬁgurations.

User Guide 1

Using the Computer Hardware

31040007_IC B5_UG_EN_V1.0.indd 1 2009.10.21 4:49:47 PM

2User Guide

1.1 Front view

Volume down

Volume up

Brightness down

Brightness up

LCD On/Off

Camera

Built-in microphone

Wireless reset button (or Indicator lights ON/OFF button)

31040007_IC B5_UG_EN_V1.0.indd 2 2009.10.21 4:49:49 PM

User Guide

1.2 Left and right view of the computer

Attention: Be sure not to block any air vents on the computer. Blocked

air vents may cause thermal problems.

Optical drive USB ports (2)

Power button Headphone connector

Card reader Microphone connector

31040007_IC B5_UG_EN_V1.0.indd 3 2009.10.21 4:49:50 PM

4User Guide

1.3 Rear view of the computer

AV-IN connector

(Selected models only)

USB ports (2)

PS/2 Keyboard connector TV-Tuner connector

(Selected models only)

Ethernet connector Power connector

31040007_IC B5_UG_EN_V1.0.indd 4 2009.10.21 4:49:51 PM

User Guide

1.4 Computer stand

15° min.

35° max.

Use the stand to position the display to your preference. It can be rotated between

15º and 35º from the vertical.

The stand provides stability to the computer; it is not a removable part.

Attention:

1. The computer stand must remain installed at all times to ensure

maximum system stability.

2. Make sure the angle of the computer is at least 15 degrees from the

vertical; otherwise the computer will be unstable and could fall over.

To open the computer stand, do the following:

31040007_IC B5_UG_EN_V1.0.indd 5 2009.10.21 4:49:54 PM
