Lenovo IdeaCentre B510 Manuale utente

Version 2.0

Machine type: 10057/7712

2010.07

Lenovo

IdeaCentre B5 Series

User Guide

31044787

Important Safety Information

Before using this manual, it is important that you read and understand all of the

related safety information for this product. Refer to the Safety and Warranty Guide

that you received with this product for the latest safety information. Reading and

understanding this safety information reduces the risk of personal injury or damage

to your product.

Danger: Be aware of extremely hazardous or lethal situations.

Attention: Be aware of possible damage to programs, devices, or data.

Note: Pay attention to this important information.

Contents

Important Safety Information

Chapter 1 Using the Computer Hardware.............................. 1

1.1 Front view................................................................................2

1.2 Left and right view of the computer .........................................3

1.3 Rear view of the computer.......................................................4

1.4 Computer stand ......................................................................5

1.5 Connecting your computer ......................................................6

1.6 Important information about using the computer .....................9

1.7 Keyboard...............................................................................11

1.8 Using the Infra-red (IR) Remote Control .................................12

1.9 Using the Bluetooth remote control .......................................19

Chapter 2 Using the Rescue System .................................... 31

2.1 OneKey Recovery..................................................................32

2.2 Driver and Application Installation ..........................................32

2.3 System Setup........................................................................33

2.4 System Backup .....................................................................34

2.5 System Recovery ..................................................................34

2.6 Create Recovery Disc ............................................................34

Chapter 3 Using the Computer Software ............................. 35

3.1 Lenovo Dynamic Brightness system ......................................36

3.2 Lenovo Eye Distance System ................................................37

Chapter 4 System Maintenance and Recovery.................... 39

4.1 Restoring the System ............................................................40

4.2 Backup and Restore..............................................................40

2Contents

4.3 Cleaning Up the Disk .............................................................40

4.4 Checking For, and Correcting Disk Errors ..............................41

4.5 Defragmenting the Disk(s)......................................................41

4.6 Performing Daily Maintenance Tasks......................................41

Chapter 5 Troubleshooting and Conﬁrming Setup.............. 43

5.1 Troubleshooting Display Problems .........................................44

5.2 Troubleshooting Audio Problems ...........................................45

5.3 Troubleshooting Software Problems.......................................45

5.4 Troubleshooting Problems with Optical Drives and

Hard Disks.............................................................................46

5.5 Special considerations for troubleshooting Windows .............47

5.6 Wireless keyboard and mouse instructions ............................48

Chapter

This chapter contains the following

topics:

Computer hardware introduction

Information on computer connections

Note: The descriptions in this chapter might

vary from your computer, depending on

computer models and conﬁgurations.

User Guide 1

Using the Computer Hardware

2User Guide

1.1 Front view

Volume down

Volume up

Brightness down

Brightness up

LCD On/Off

Camera

Built-in microphone

Indicator lights ON/OFF button

User Guide

1.2 Left and right view of the computer

Attention: Be sure not to block any air vents on the computer. Blocked

air vents may cause thermal problems.

Optical drive USB ports (2)

Power button Headphone connector

Card reader Microphone connector

4User Guide

1.3 Rear view of the computer

AV-IN connector

(Selected models only)

TV-Tuner connector

(Selected models only)

PS/2 Keyboard connector eSATA port

Ethernet connector Wireless reset button

USB ports (2) Power connector

User Guide

1.4 Computer stand

15° min.

35° max.

Use the stand to position the display to your preference. It can be rotated between

15º and 35º from the vertical.

The stand provides stability to the computer; it is not a removable part.

Attention:

1. The computer stand must remain installed at all times to ensure

maximum system stability.

2. Make sure the angle of the computer is at least 15 degrees from the

vertical; otherwise the computer will be unstable and could fall over.

To open the computer stand, do the following:
