Lenovo IdeaCentre Q700 Manuale utente

Version 1.1 2009.7

User Guide

Lenovo

IdeaCentre Q700 Series

31039306

31039306_Q700_UG_FM_EN_V1.1.indd1 1 2009.7.3 3:05:02 PM

Important Safety Information

Before using this manual, it is important that you read and understand all of

the related safety information for this product. Refer to the Safety and Warranty

Guide you received with this product for the latest safety information. Reading

and understanding this safety information reduces the risk of personal injury and

damage to your product.

Danger: Beware of extremely hazardous or lethal situations.

Attention: Beware of possible damage to programs, devices, or data.

Note: Pay attention to this important information.

31039306_Q700_UG_EN_V1.1.indd 1 2009.7.3 3:09:40 PM

31039306_Q700_UG_EN_V1.1.indd 2 2009.7.3 3:09:40 PM

Contents

Important Safety Information

Chapter 1 Using the Computer Hardware .............................. 1

1.1 Front view of the computer chassis .........................................2

1.2 Rear view of the computer chassis ..........................................3

1.3 Computer stand instruction .....................................................4

1.4 Connecting your computer .....................................................5

1.5 Using the Remote Control .....................................................11

Chapter 2 Using the Rescue System .................................... 15

2.1 Installing Drivers and Software Shipped with Your Computer ...16

2.2 OneKey Recovery..................................................................17

2.3 File Management ...................................................................18

2.4 OneKey Antivirus ...................................................................20

Chapter 3 Using the Computer Software ............................. 23

3.1 Power2Go — Burning Discs .................................................24

3.2 WinDVD ................................................................................25

3.3 Trend Micro Internet Security .................................................26

3.4 Media Show ..........................................................................28

Chapter 4 System Maintenance and Recovery.................... 29

4.1 Restoring the System ............................................................30

4.2 Backup status and conﬁguration ...........................................30

4.3 Cleaning Up the Disk .............................................................30

4.4 Checking For and Correcting Disk Errors ...............................31

4.5 Defragmenting the Disk(s)......................................................31

4.6 Performing Daily Maintenance Tasks......................................31

31039306_Q700_UG_EN_V1.1.indd 1 2009.7.3 3:09:40 PM

2Contents

Chapter 5 Troubleshooting and Conﬁrming Setup.............. 33

5.1 Troubleshooting Display Problems .........................................34

5.2 Troubleshooting Audio Problems ...........................................35

5.3 Troubleshooting Software Problems.......................................35

5.4 Troubleshooting Problems with Optical Drives and

Hard Disks.............................................................................36

5.5 Special considerations for troubleshooting Windows .............37

31039306_Q700_UG_EN_V1.1.indd 2 2009.7.3 3:09:40 PM

Chapter

This chapter contains the following

topics:

ÿComputer hardware introduction

ÿInformation on computer connections

Note: The descriptions in this chapter may

vary from your computer setup, depending

on computer models and conﬁgurations.

User Guide 1

Using the Computer Hardware

31039306_Q700_UG_EN_V1.1.indd 1 2009.7.3 3:09:41 PM

2User Guide

1.1 Front view of the computer chassis

Attention: Ensure that none of the air vents on the computer are blocked.

Blocked air vents can lead to overheating problems.

Power button IEEE 1394 port

Optical drive slot USB ports (4)

LED indicators (3) and IR receiver Microphone socket

Memory card reader Headphone socket

31039306_Q700_UG_EN_V1.1.indd 2 2009.7.3 3:09:43 PM

User Guide

1.2 Rear view of the computer chassis

HDMI port Audio line-out sockets (2)

VGA port TV-tuner port (selected models only)

eSATA port Audio line-in socket

USB ports (4) Microphone port

S-Video port (selected models only) Audio line-out port

Ethernet port Power socket

SPDIF port

31039306_Q700_UG_EN_V1.1.indd 3 2009.7.3 3:09:45 PM

4User Guide

1.3 Computer stand instruction

The computer chassis can be placed in a vertical position.

PRO

MMC

PRO

MMC

Note: Make sure to install the base stand before placing the chassis in a

vertical position.

The computer chassis can also be placed in a horizontal position.

• Attach the four sticky pieces as in the diagram below.

• Lay the chassis down on its side as in the diagram below.

PRO

MMC

PRO

MMC

31039306_Q700_UG_EN_V1.1.indd 4 2009.7.3 3:09:48 PM

User Guide

1.4 Connecting your computer

Use the following information when connecting your computer.

• Look for the small port/socket icons on the back of your computer. Match the

cable ends to the icons.

• If your computer cables and ports/sockets panels have color-coded ports or

sockets, match the color of the cable end with the color of the port or socket.

Note: Your computer might not have all of the ports and sockets that are

described in this section.

1.4.1 Connect the keyboard cable to the appropriate keyboard

port (USB port). (Not all models are equipped with a

keyboard.)

1.4.2 Connect the mouse cable to the appropriate mouse port

(USB port). (Not all models are equipped with a mouse.)

1.4.3 Connect the monitor cable to the monitor port on the

computer.

• If you have a Video Graphics Array (VGA) Standard monitor, connect the

cable to the port as shown.

31039306_Q700_UG_EN_V1.1.indd 5 2009.7.3 3:09:48 PM
