Lenovo ThinkPad OneLink Pro Manuale utente

ThinkPadOneLinkProDockUserGuide

http://www.lenovo.com/safety

Note:Beforeinstallintheproduct,besuretoreadthewarrantyinformationinAppendixB“LenovoLimited

Warranty”onpae19.

SecondEdition(February2014)

©CopyrightLenovo20132014.

LIMITEDANDRESTRICTEDRIGHTSNOTICE:IfdataorsoftwareisdeliveredpursuantaGeneralServicesAdministration

“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionssetforthinContractNo.GS-35F-05925.

Contents

Chapter1.Aboutthedock.......1

Productdescription..............1

Locatinconnectorsandcontrolsonthedock...2

Systemrequirements.............4

Chapter2.Installingthedock......5

Connectinthedocktoyournotebookcomputer..5

InstallinthedevicedriveronWindowsoperatin

systems..................6

Chapter3.Usingthedock.......7

Usintheheadset/microphonecomboconnector..7

UsintheUSB3.0connectorwithbatterycharin

function..................7

UsintheUSBconnectors...........8

UsintheGiabitEthernetconnector.......8

UsintheDisplayPortandDVI-Iconnectors....8

Chapter4.Workingwiththedock...9

Understandinthevideooutputmodes......9

Enterinavideooutputmode..........9

Enterinextendmode...........9

Enterinmirrormode..........10

Enterinsinle-displaymode.......10

Manuallyenablintheheadset/microphonecombo

connector................11

Rotatintheexternalmonitordisplay......11

Settinthecolorqualityoftheexternalmonitor..12

Settintheresolutionoftheexternalmonitor...12

Supportedresolutions............13

Chapter5.Troubleshooting......15

AppendixA.ServiceandSupport...17

Onlinetechnicalsupport...........17

Telephonetechnicalsupport.........17

AppendixB.LenovoLimited

Warranty................19

Part1-GeneralTerms...........19

Part2-Country-speciﬁcTerms........21

Part3-WarrantyServiceInformation......24

AppendixC.Electronicemission

notices................27

FederalCommunicationsCommissionDeclaration

ofConformity...............27

AppendixD.Notices..........31

Recyclininformation............31

RecyclininformationforBrazil........31

ExportClassiﬁcationNotice.........32

Trademarks................32

AppendixE.RestrictionofHazardous

SubstancesDirective(RoHS).....33

EuropeanUnionRoHS...........33

ChinaRoHS................33

TurkishRoHS...............33

UkraineRoHS...............33

IndiaRoHS................33

©CopyrihtLenovo2013,2014i

iiThinkPadOneLinkProDockUserGuide

Chapter1.Aboutthedock

Thischaptercontainsproductdescription,connectorandcontrollocations,andsystemrequirementsforthe

ThinkPad®OneLinkProDock(hereaftercalledthedock).

Productdescription

Thedockisaportableexpansionmodulethatenablesyoutoeasilyconnectyournotebookcomputertothe

Ethernetandmultipledevices,suchasaDisplayPort®,DiitalVideoInterface(DVI),orVideoGraphicsArray

(VGA)monitor;aheadset/microphonecomboconnector;andUniversalSerialBus(USB)devices.Thedock

providesfourUSB3.0connectorsforhiherbandwidthandbetterperformance,andtwoUSB2.0connectors

forcommonUSBdevices.ThedockalsosupportsGiabitEthernetspeedwhenyouconnectittonetworks.

YoucansetupyourworkareabyconnectinyournotebookcomputertothedockwiththeOneLinkcable,

connectinmultipledevicestothedock,andsettinthedockonyournotebookcomputer;then,youare

readytousethemultipledeviceseachtimeyouconnectyournotebookcomputertothedock.

Youroptionpackaeincludesthefollowin:

•ThinkPadOneLinkProDock

•Poweradapter

•Powercord

•Cablemanaementstand

•Warrantyposter

•DVI-ItoVGAadapter

Contactyourplaceofpurchaseifanyitemismissinordamaed.Besuretoretainyourproofofpurchase

andpackinmaterial.Theymihtberequiredtoreceivewarrantyservice.

©CopyrihtLenovo2013,20141

Locatingconnectorsandcontrolsonthedock

Thefollowinillustrationhelpsyoulocatetheconnectorsandcontrolsonthedock.

Figure1.Overviewofthedock

1Powerindicator8Powerconnector

2Headset/microphonecomboconnector9GiabitEthernetconnector

3USB3.0connectorwithbatterycharinfunction10USB3.0connectors

4USB3.0connector11Powerbutton

5Security-lockslot12USB2.0connectors

6OneLinkcable13DisplayPortconnector

7Cablemanaementstand14DVI-Iconnector

1Powerindicator

Thepowerindicatorisusedtoindicatethepowerstatusofthenotebookcomputerthatconnectswiththe

dock.

•Ifthepowerindicatorislitinred,itindicatesthatthenotebookcomputeristurnedon.

•Ifthepowerindicatorisoff,itindicatesthatyournotebookcomputeristurnedoff,insleepmode,orin

hibernationmode;orthedockisdisconnectedfromyournotebookcomputer.

2Headset/microphonecomboconnector

Theheadset/microphonecomboconnectorisusedtoconnectaheadset,amicrophone,oraspeaker.

2ThinkPadOneLinkProDockUserGuide

3USB3.0connectorwithbatterychargingfunction

TheUSB3.0connectorwithbatterycharinfunctionisusedtodothefollowin:

•ConnectinUSBdevices(USB1.0,USB1.1,USB2.0,andUSB3.0compatible)

•Charindevicesevenwhenyournotebookcomputeristurnedoff,insleepmode,orinhibernation

mode;orwhenthedockisdisconnectedfromyournotebookcomputer

4USB3.0connector

TheUSB3.0connectorisusedtoconnectUSBdevices(USB1.0,USB1.1,USB2.0,andUSB3.0

compatible).

5Security-lockslot

Thesecurity-lockslotisusedtosecurethedockwithasecuritycablelock.

Note:Thesecuritycablelockisnotincludedinyouroptionpackae.Ifnecessary,purchaseasecurity

cablelock.

6OneLinkcable

TheOneLinkcableisusedtoconnectthedocktoyournotebookcomputer.

Note:Toavoidanyﬁredamae,ensurethatthenotebookcomputerconnectintheOneLinkcablemeets

eitherofthefollowinrequirements:

•TheﬂammabilityofthenotebookcomputerenclosureisnotlowerthanClassV-1.

•Thenotebookcomputerenclosureismetallic.

7Cablemanagementstand

ThecablemanaementstandisusedtomanaetheOneLinkcabletooptimizedeskspace.

8Powerconnector

Thepowerconnectorisusedtoconnectthepoweradapter.

Note:Thepowerinputratinofthedockis20Vand4.5A.

9GigabitEthernetconnector

TheGiabitEthernetconnectorisusedtoconnectthedocktoanetworkusinanEthernetcable.

10USB3.0connectors

ThetwoUSB3.0connectorsareusedtoconnectUSBdevices(USB1.0,USB1.1,USB2.0,andUSB

3.0compatible).

11Powerbutton

Thepowerbuttonisusedtoturnonorturnoffyournotebookcomputer,ortoputthenotebookcomputer

intosleeporhibernationmode.Toachievethis,youneedtochanethepowerplansettinsofyour

notebookcomputer.Formoreinformation,refertotheuseruidethatcomeswithyournotebookcomputer.

Chapter1.Aboutthedock3

12USB2.0connectors

ThetwoUSB2.0connectorsareusedtoconnectUSBdevices(USB1.0,USB1.1,andUSB2.0compatible).

13DisplayPortconnector

TheDisplayPortconnectorisusedtoconnectanexternalmonitortothedockusinaDisplayPortcable.

14DVI-Iconnector

TheDVI-IconnectorisusedtoconnectaDVI-Imonitor.YoualsocanconnectaVGAmonitortothis

connectorthrouhaDVI-ItoVGAadapter.

Systemrequirements

Beforeusinthedock,ensurethatyournotebookcomputerhasoneofthefollowinoperatinsystems

installed:

•Microsoft®Windows®7

•MicrosoftWindows8

•MicrosoftWindows8.1

4ThinkPadOneLinkProDockUserGuide

Chapter2.Installingthedock

Thischapterprovidesinstructionsonhowtoconnectthedocktoyournotebookcomputer,andmanually

installthedevicedriver.

Connectingthedocktoyournotebookcomputer

ThistopicprovidesinstructionsonhowtoconnectthedocktoyournotebookcomputerusintheOneLink

cablealonwiththepoweradapterandpowercord.

Notes:

•Ensurethatyoucorrectlyconnectthedocktoanacpowersource.

•YoucanpresstheOneLinkcableintothecablemanaementstandtooptimizedeskspace.

Toconnectthedocktoyournotebookcomputer,dothefollowin:

1.Removethepoweradapterfromyournotebookcomputer.

2.RemovetheLenovo®OneLinkconnectorcoverfromyournotebookcomputer.

Figure2.RemovingtheLenovoOneLinkconnectorcover

©CopyrihtLenovo2013,20145

3.Connectthedocktoanacpowersourceandyournotebookcomputerbydointhefollowin:

a.Connectthepoweradaptertothepowercord1.

b.Connectthedc-inconnectorofthepoweradaptertothepowerconnectoronthedock2.

Note:Thepoweradapterthatcomeswiththedockisa90Wpoweradapter.

c.ConnecttheOneLinkcabletotheLenovoOneLinkconnectoronyournotebookcomputer3.

d.Connectthepowerpluofthepowercordtoanelectricaloutlet4.Thedockisreadyforuse.

Figure3.Connectingthedocktothepowersupplyandyournotebookcomputer

InstallingthedevicedriveronWindowsoperatingsystems

Dependinonthenotebookcomputermodelandoperatinsystem,thedockdevicedrivermihtbe

preinstalledonyournotebookcomputer.Inthissituation,thedockisreadyforuseafteryousuccessfully

connectittoanacpowersourceandyournotebookcomputer.Thefollowinnotebookcomputermodels

havethedockdevicedriverpreinstalled:

•ForWindows7:ThinkPadE440,E540,S1Yoa,andX1Carbonnotebookcomputers

•ForWindows8.1:ThinkPadB5400,M5400,E440,E540,S440,S540,S1Yoa,andX1Carbonnotebook

computers

Note:AllthenotebookcomputermodelswiththeWindows8operatinsystemdonotincludethedock

devicedriver.

Ifthedockdevicedriverisnotpreinstalledonyournotebookcomputer,youalsocanobtainthelatest

devicedriverathttp://www.lenovo.com/onelinkdrivers.Thenfollowtheinstructionsonthescreentoinstall

thedevicedriver.

6ThinkPadOneLinkProDockUserGuide
