Lenovo 3000 Y100 Manuale utente
Lenovo Portable Computer User Manual
1
Preface
This manual is only used to describe the guide for using the
requirements for conditions of use and environment about the Lenovo
notebook computer it is attached to. Lenovo does not guarantee that this
manual can be used for Lenovo notebook computers of other models or
products from other vendors.
The correctness of the materials in this manual has been reviewed
carefully, but Lenovo will not guarantee the rightness of its content.
© Copyright Lenovo 2006. All rights Reserved.
This manual is only to guide you to use the Lenovo notebook
computers. Without explicit written approval from Lenovo, it is prohibited
for anybody, with any objective, and in any form or measure to use,
replicate or spread any part of this manual.
Trademarks, logos and icons used in this manual belong to Lenovo or
its authorized parts and are under the protection of the People’s Republic of
China’s laws and international treaties.
Pentium, Dothan, Centrino and Celeron are registered trademarks of
Intel Corporation.
MS-DOS, Windows, Windows XP and Windows 2000 are registered
trademarks of Microsoft Corporation.
Lenovo Portable Computer User Manual
2
Read First
Welcome to use Lenovo PCs
Windows XP Operating System
If the preinstalled operating system on your computer is Windows XP,
when you start it up for the first time, the system will perform the tasks of
user information collection and final configuration. You need to read the
following carefully in order to ensure you operation can go on smoothly.
When the system is booted, read the words on the screen carefully.
To use Windows XP, you must get licensed at first. You should read
End User License Agreement carefully, only after you have accepted this
agreement, the installation will continue.
The system will ask you to set up the name and description of this
notebook computer, set up the Internet access, register your computer to
Microsoft (You can decide to register or not by yourself) and set up the
usernames for the computer.
When you type in all the necessary user information, the system will
complete the final configuration. By simply following the instructions, you
can easily complete the entire setup process step by step and the notebook
computer will be ready for use.
NOTE: On the basis of the operating system authorization contract
with Microsoft, the preinstalled Microsoft operating systems
on this computer have been authorized by the copyright
owner.
Lenovo Portable Computer User Manual
3
Safety Warnings
Care during Use:
Do not place the computer in an overheated environment, to prevent the
computer from being damaged by heat.
Do not place any objects on the computer.
Do not impact or let the computer fall, to prevent the computer being
damaged.
Care for AC Adapter:
Do not disassemble it.
Do not use it outdoors to prevent it from being heated, burned or getting
electric shock.
Do not touch it with wet hands or immerge it into water.
Do not use this adapter with any other computers, in order to avoid electric
shock, burning and component damages.
In China, please use the AC power cord in the box; in other countries,
please use power cords in compliance with local requirements.
Care for Battery Pack:
Do not make the battery short circuit
Do not place the battery in an environment above 60℃
Do not place the battery in fire
Do not fall or vibrate the battery
Do not wipe the metal component on the battery with a wet cloth.
Do not touch the battery with a wet hand or immerge it into water.
Do not disassemble the battery.
When you use the computer under sunshine or near high temperature
object or fire, do not use the battery as the power supply.
Lenovo Portable Computer User Manual
Chapter 1 Welcome
This user manual provides the hardware and software information of the
LENOVO® Portable Computer which you will use.
The computer is complicated equipment, please read over the whole
manual before your first use. Especially if you are a new user of computers
or you’re new to portable computing. Please do not worry if you are still
confused about some part of the manual, keep this manual as a reference
when you are using your computer or call our agent for help.
Please pay your attention to the caution and safety messages in this
manual and the safety messages in the preface.
Note: 1、Plug-in and/or remove any computer component is
strictly forbidden during the computer is using (except the
USB, PCMCIA and/or CD-ROM devices which support
PnP-Plug and play Technology).
2、As many new hardware are adopted in this computer,
user must install the drivers by following the manual’s
instruction to get the best computer performance.
1.1QuickTourforyourportablecomputer
Congratulations on your purchase of the Lenovo 3000 Y100 series portable
computer. This powerful, lightweight portable computer is designed to
provide years of reliable, high-performance computing.
Lenovo 3000 Y100 series Model contains Intel® 915GM Express
Chipset and integrated graphics card.
1.1.1 Front view with the display open
4
Lenovo Portable Computer User Manual
1 LCD Display Latch
2 TFT Color LCD
3 Power Button
4 Quick Buttons
5 Keyboard Status Indicators
6 Keyboard
7 Touch Pad
1. LCD Display Latch
This latch secures the LCD display panel in its closed position. Slide the
latch to open the display.
2. TFT Color LCD
The computer adopts 15.4" wide screen 16:10 Thin-Film Transistor (TFT)
full-color display which supports the highest as 1280 horizontal * 800
vertical pixels, 32-bit color.
3. Power Button
Press this button to turn on the computer or turn it off.
5
Lenovo Portable Computer User Manual
Hint: If the system cannot shut down normally, press the power
button for 4~5 seconds to shut it down manually.
4. Quick Buttons
1. Novo Key Onekey Recovery
2. Mute Key Turn on/off mute function
The Novo Key is the Onekey Recovery key by default setting and used to
activate the “Onekey Recovery” application.
When the computer is powered off, press the Novo Key to enter into the
system recovery application. You can recover, backup or uninstall the
system through the application. Please see <Onekey Recovery User
Manual> for details.
CAUTION: Make sure you have already backup the data in the
hard drive. The system recovery will reformat the hard
drive and restore it to the factory setting.
5. Keyboard Status Indicators
1. CapsLock Indicator The Indicator glows when CapsLock
is active.
2. NumLock Indicator The Indicator glows when NumLock
is active
3. ScrLock Indicator The Indicator glows when ScrLock is
active
6
Lenovo Portable Computer User Manual
6. Keyboard
Standard 86-key keyboard (Embedded numeric keypad and function keys.
They can combine with [Fn] key to achieve some shortcut functional
applications). Please see “Using Keyboard” for details.
7. Touch Pad
Moves the pointer and selects or activates items on the screen. There are
two buttons perform as mouse buttons. After install the driver, touch pad
can be set to perform other mouse functions. Please see “Using Touch Pad”
for details.
1.1.2 Front view with display closed
1 Build-in Stereo Speakers
2 Audio Jack
3 Software AudioDJ
4 System Status Indicators
5 Wireless Communication Switch
1. Build-in Stereo Speakers
The stereo speakers can output clear stereo sound.
2. Audio Jack
1. Headphone Jack
Enables connection of a headphone
or external speaker for audio output.
When you connect the headphone or
other device, internal speakers are
automatically disabled.
7
Lenovo Portable Computer User Manual
2. Microphone Jack Enables connection of a microphone
for audio input.
3. SoftwareAudioDJ
Play Audio-CD without turn on Windows and direct link Windows
application to play mp3 and DVD.
- CD mode -
Press MODE button over 3 seconds, CD mode LED will be turned on.
Insert Audio-CD, then press PLAY/PAUSE, Next/Previous Chapter, STOP,
Audio Volume Up/Down button to enjoy audio-CD playing.
Insert DVD, then press PLAY button to direct into Windows to play. You
can press PLAY/PAUSE, Next/Previous Chapter, STOP, Audio Volume
Up/Down button to enjoy DVD playing.
- MP3 mode -
Press MODE button over 3 seconds, CD mode LED will be turned on.
Press MODE button less than 1 second, MP3 mode LED will be turn
on. Press PLAY button, system will link to Windows Application to play
MP3 files. Press PLAY/PAUSE, Next/Previous Chapter, STOP, Audio
Volume Up/Down button to enjoy MP3 playing.
4. System Status Indicators
1. Power Indicator
The indicator glows yellow when the
computer is on;
The indicator fades in/out when the
computer is in STR (Suspend To Ram)
status;
The indicator is off when the computer is
8
Lenovo Portable Computer User Manual
powered off or in STD (Suspend To
Disk) status.
2. Hard Disk/CD-ROM
Indicator
The indicator flashes yellow when the
computer is accessing a disk drive.
3. Battery Indicator
When you use battery:
The indicator is off means the battery is
in normal use;
The indicator flashes amber means the
battery is low power.
When you use external power source:
The indicator glows amber means the
battery is being charged;
The indicator glows yellow means the
battery is fully charged.
5. Wireless Communication Switch
Use the switch to enable and disable the wireless communication function.
It will extend the operating time of battery if the wireless function is
disabled.
CAUTION: Do not use the wireless communication function in
the hospital or nearby any electronic medical equipment!
The radio waves of the wireless card may cause the
electronic medical equipments malfunction and result in
serious accident.
CAUTION: Do not use the wireless communication function on
the plane! The radio waves of the wireless card may cause
the electronic equipments of the plane malfunction and
result in serious accident.
CAUTION: Please avoid interfering with other electronic
9
Lenovo Portable Computer User Manual
equipment when you enable the wireless communication
function! The radio waves of the wireless card may cause
other electronic equipments malfunction and result in
serious accident.
Hint: After connected to wireless AP, the wireless communication
indicator glows yellow. Otherwise the indicator blinks.
1.1.3 Left View
1 SecurityLockSlot
2 DCIN
3 USB (Universal Serial Bus) Ports
4 Optical Media Drive
1. Security L k Sl
cable that can attach to the slot. Use it to anchor
oc ot
You can buy a security
you computer to your desk or other large object to defer theft. The security
cable’s instruction will tell you how to use it.
Hint: Before you buy the security cable, make sure it fits your
2. DC IN
aptor connects to this socket. The AC adaptor can support the
computer’s security lock slot.
The AC ad
10
power for your computer and/or charge the battery when it is connected to
a power source.
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Lenovo Computer portatile
Lenovo
Lenovo ThinkPad X40 2371 Manuale utente
Lenovo
Lenovo ThinkPad X1 Hybrid Manuale di istruzioni
Lenovo
Lenovo ThinkPad Edge E420 Manuale
Lenovo
Lenovo ThinkPad T61 Manuale
Lenovo
Lenovo ThinkPad R61e Manuale utente
Lenovo
Lenovo ThinkPad X230 Tablet Guida di riferimento
Lenovo
Lenovo IdeaPad Slim 1 Manuale utente
Lenovo
Lenovo Yoga Slim 7 14 05 Manuale utente
Lenovo
Lenovo ThinkPad L430 Manuale del proprietario
Lenovo
Lenovo ThinkPad T420 Manuale utente
Lenovo
Lenovo B490 Manuale utente
Lenovo
Lenovo ThinkPad Twist S230u Manuale di servizio
Lenovo
Lenovo ThinkPad Edge E330 Manuale utente
Lenovo
Lenovo 35082AU Manuale del proprietario
Lenovo
Lenovo ThinkPad X30 2672 Manuale del proprietario
Lenovo
Lenovo ZhaoYang Series Manuale utente
Lenovo
Lenovo ThinkPad Edge E420 Manuale di istruzioni
Lenovo
Lenovo B460e Manuale d'uso e manutenzione
Lenovo
Lenovo ThinkPad X201 Tablet Manuale del proprietario
Lenovo
Lenovo G585 Manuale utente
