Lenovo ThinkPad E14 Gen2 Manuale utente

Printed in China

PN: SPXXXXXXXX

E14/R14/S3 Gen 2

Setup Guide

Initial Setup

Overview

32 1

*For selected models

1. Microphones

2. Camera

*3. ThinkShutter

4. Power button with or without

fingerprint reader

5. Security-lock slot

6. Ethernet connector

7. USB 2.0 connector

8. Trackpad

9. TrackPoint® buttons

10. TrackPoint pointing stick

11. Audio connector

12. HDMITM connector

13. USB 3.1 connector Gen 1

14. Always On USB 3.1 connector

Gen 1

15. USB-CTM connector (USB 3.1 Gen

Read the statement on USB transfer rate in the User Guide. Refer to the Safety and

Warranty Guide for accessing the User Guide.

Customer Replacement Units (CRUs)

• ac power adapter

• Power cord

• Base cover assembly

• Memory module

*• Hard disk drive

*• Hard disk driver bracket

*• Hard disk driver cable

*• M.2 solid-state drive

*• M.2 solid-state drive bracket

• Speaker assembly

*For selected models

Refer to the User Guide for CRU definition.

Additional information

Specific absorption rate for European

Union

YOUR DEVICE MEETS INTERNATIONAL

GUIDELINES FOR EXPOSURE TO RADIO WAVES.

The Europe 10g Specific Absorption Rate (SAR)

limit for mobile devices is 2.0 W/kg. To view your

product specific SAR value, go to

https://support.lenovo.com/us/en/solutions/sar.

If you are interested in further reducing your RF

exposure then you can easily do so by limiting your

usage or simply keeping the device away from the

body.

European Union — compliance with the

Radio Equipment Directive

Hereby, Lenovo (Singapore) Pte. Ltd., declares that

the radio equipment type ThinkPad E14/R14/S3

Gen 2 is in compliance with Directive 2014/53/EU.

The full text of the system EU declaration of

conformity is available at the following Internet

address:

https://www.lenovo.com/us/en/compliance/eu-

doc

This radio equipment operates with the following

frequency bands and maximum radio-frequency

power:

Technology

Frequency

band [MHz]

Maximu

transmit

power

WLAN

802.11b/g/n/ax

2400 -

2483.5

< 20 dBm

WLAN

802.11a/n/ac/ax

5150 - 5725 < 23 dBm

WLAN

802.11a/n/ac/ax

5725 - 5875

< 13.98

dBm

Bluetooth

BR/EDR/LE

2400 -

2483.5

< 20 dBm

E-manual

Third Edition (December 2019)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a

General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to

restrictions set forth in Contract No. GS-35F-05925.

Reduce I Reuse I Recycle
