Lenovo USB Laser Mouse Manuale utente

Combined Mouse User’s Guide

Second Edition (January 2007)

©Copyright Lenovo 2005, 2007.

Portions ©Copyright International Business Machines Corporation 2005.

U.S. GOVERNMENT USERS –RESTRICTED RIGHTS: Our products and/or services are provided with

RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to the GSA ADP Schedule

contract with Lenovo Group Limited, if any, or the standard terms of this commercial license, or if the agency is

unable to accept this Program under these terms, then we provide this Program under the provisions set forth in

Commercial Computer Software–Restricted Rights at FAR 52.227-19, when applicable, or under Rights in

Data-General, FAR 52.227.14 (Alternate III).

Contents

About this book ...........v

Chapter 1. Lenovo Laser Mouse ... 1-1

Product Description ........... 1-1

Installing the Mouse Suite Software ...... 1-1

Installing the Mouse ........... 1-1

Using the Mouse ............ 1-2

Solving USB problems .......... 1-3

Caring for the mouse ........... 1-4

Chapter 2. 800 DPI Optical 3-Button

ScrollPoint PS/2 and USB Mouse ... 2-1

Product Description ........... 2-1

Installing the Mouse Suite Software ...... 2-1

Installing the Mouse ........... 2-1

Using the Mouse ............ 2-2

Solving USB problems .......... 2-3

Caring for the mouse ........... 2-3

Chapter 3. 800 DPI Optical 3-Button

ScrollPoint Pro Mouse PS/2 and USB . 3-1

Product Description ........... 3-1

Installing the Mouse Suite software ..... 3-1

Using the mouse ............ 3-2

Solving problems with USB connectivity ... 3-3

Caring for the mouse ........... 3-3

Chapter 4. Optical 3-Button Travel

Wheel Mouse with 800 DPI for PS/2

and USB.............. 4-1

Product Description ........... 4-1

Installing the Mouse Suite Software ..... 4-1

Installing the Mouse ........... 4-1

Using the mouse ............ 4-2

Solving USB problems ......... 4-3

Chapter 5. USB Optical Wheel Mouse 5-1

Introduction .............. 5-1

Installing the Mouse Suite Software ..... 5-1

Installing the Mouse ........... 5-1

Using the mouse ........... 5-2

Appendix A. Service and Support... A-1

Registering your option ..........A-1

Online technical support .........A-1

Telephone technical support ........A-1

Appendix B. Lenovo Statement of

Limited Warranty .......... B-1

Warranty information........... B-4

Guarantee supplement for Mexico ...... B-5

Appendix C. Notices ........ C-1

Recycling information .......... C-2

Electronic emission notices ......... C-2

Federal Communications Commission (FCC)

Declaration of Conformity ........ C-2

Trademarks .............. C-4

©Lenovo 2005, 2007. Portions ©IBM Corp. 2005. iii

iv Combined Mouse User’s Guide

About this book

This combination manual contains instructions for installing and using the Laser Mouse, 800 DPI Optical

3-Button ScrollPoint

PS/2 and USB Mouse, 800 DPI Optical 3-Button ScrollPoint Pro Mouse PS/2 and

USB, Optical 3-Button Travel Wheel Mouse with 800 DPI for PS/2 and USB, and the USB Optical Wheel

Mouse.

©Lenovo 2005, 2007. Portions ©IBM Corp. 2005. v

vi Combined Mouse User’s Guide

Chapter 1. Lenovo Laser Mouse

This Chapter contains installation, usage, and maintenance information for the Lenovo Laser Mouse.

Product Description

The Lenovo Laser Mouse includes aTiltWheel to control vertical and horizontal scrolling and other

functions. The mouse includes aPS/2 and USB connector and can be connected to any enabled USB port.

The mouse works with computers that use the following operating systems:

vMicrosoft

Windows

2000 Professional with Service Pack 4

vMicrosoft Windows XP with Service Pack 2

vMicrosoft Windows Vista

™

vOperating systems that support USB connectivity

This package contains:

vOne Lenovo Laser Mouse.

vOne CD-ROM containing installation software and an online User’s Manual

vOne USB to PS/2 adapter

Installing the Mouse Suite Software

Included in your package is aCD-ROM containing installation software for the mouse. To install the

Mouse Suite Software:

1. Turn on the computer and start the operating system.

2. Insert the Device Driver CD into your CD-ROM drive. Click the Driver arrow. Follow the on-screen

instructions on your screen. If the setup program does not open, go to steps 3-6. If the setup program

opens, go to step 6.

3. Click Start.

4. Click Run.

5. In the command line, type X:/setup where Xis the drive letter for your CD-ROM drive.

6. Click OK.

7. Follow the on-screen instructions to complete the Mouse Suite software installation.

Note: When you are prompted, click PS/2 if you will be connecting the mouse to the standard mouse

connector or click USB you will be using the mouse with aUSB connector.

Installing the Mouse

This section contains information for installing the mouse in PS/2 mode and in USB mode.

If aPS/2 mouse is plugged into your computer, you must first turn off your computer prior to removing

this mouse. Plug in your mouse and restart your computer. If amessage displays indicating that you do

not have aPS/2 mouse connected, ignore the message and continue.

Installing the mouse in PS/2 mode

To install the mouse using the Windows 2000, Windows XP, or Windows Vista operating system, do the

following:

1. Turn off your computer.

©Lenovo 2005, 2007. Portions ©IBM Corp. 2005. 1-1

2. Remove any mouse that is connected to the PS/2 connector.

3. Insert the mouse with the PS/2 adapter into the mouse connector on the computer.

4. Restart the computer.

Installing the mouse in USB mode

To install the mouse using the USB connector in Microsoft Windows 2000 Professional, do the

following:

1. Insert the USB (rectangular) connector from the mouse into the USB connector on the computer.

2. In the Add New Hardware Wizard window, press the Enter key.

3. In the What do you want Windows to do? window, select Search for the best driver for your device.

4. Press the Enter key.

5. In the Windows will search for new drivers window, press the Enter key. Your computer will display

the location of the driver.

6. Press the Enter key. The Windows has finished installing the software that your new hardware device

requires window opens.

7. Press the Enter key to complete the installation.

See “Using the mouse” for further information.

USB Installation (Windows XP)

To install the mouse in USB mode in acomputer using Windows XP do the following:

Note: Do not connect the mouse to aUSB connector on aThinkPad

or other notebook computer until

you see the Windows XP desktop.

1. Connect the mouse USB connector to the computer USB connector.

2. The New Hardware Found window will open stating, Windows is installing the software for your

new hardware. Windows XP will automatically install the proper device drivers to operate your new

mouse.

Using the Mouse

The Lenovo Laser Mouse has multiple functions and features such as Zoom and Auto-scrolling, which

help you to increase your productivity. You can also change the mouse resolution or assign frequently

used functions or shortcuts to the mouse buttons by using the tabs in the Mouse Suite Software.

To start the Mouse Suite Software:

1. Click Start-->Settings-->Control Panel.

2. The Control Panel window opens. Double-click the Mouse icon. (If you have already enabled Show

Mouse Icon in the system tray option in the Mouse Suite properties of the Control Panel, double-click

the Mouse icon in the Windows System Tray located in the lower right-hand corner of your screen.)

By default the mouse buttons are assigned various functions, such as primary Mouse Button, Context

Menu, and Quick/Auto scroll. You can customize or change these button functions. To customize the

function of each button, do the following:

1. Open the Mouse Suite Control Panel.

2. Click the Buttons tab.

3. On the Mouse Image, click the button you want to assign anew function, or select abutton from the

Button list. The selected button will be displayed in the Button list and highlighted on the mouse

image.

4. Select afunction from the Function list (at least one mouse button must be designated as the Primary

Mouse Button)

5. To reset your mouse buttons to the default setting, click Use Default.

1-2 Combined Mouse User’s Guide
