Lenovo TAB 2 A7-10F Manuale utente

Lenovo TAB 2 A7

Lenovo TAB 2 A7-10F

Lenovo TAB 2 A7-20F

User Guide V1.0

Please read the safety precautions and important notes

in the supplied manual before use.

Chapter 01

Lenovo TAB 2 A7 Overview

1-1 Appearance

1-2 Buttons

1-3 Activating/Deactivating the display

1-4 Screen lock/unlock

1-5 Navigation tips

1-6 Home screen

1-7 Status bar

1-8 Recent apps

1-9 Application management

1-10 Entering text

Tips

Model & Version

Model Version

Lenovo TAB 2 A7-10F WLAN

Lenovo TAB 2 A7-20F WLAN

1-1 Appearance

Images are for reference purposes only, and may differ from your Lenovo TAB 2 A7.

NOTE: Only Lenovo TAB 2 A7-20F has a rear camera.

1-2 Buttons

On/Off button

To turn on your tablet, press and hold this button for about 3 seconds, then release it.

If your tablet is turned on, press this button to deactivate the display. If the display is

deactivated, press this button to activate the display.

To turn off your tablet, press and hold this button for about 1 second, then select OK

in the Power off pop-up window to shut down your tablet.

To restart your tablet, press and hold this button until the Lenovo logo appears.

NOTE: When connecting to a computer with a USB cable, make sure that the battery power

is sufficient for normal operation; otherwise, charge with the AC power adaptor before

making the USB connection.

Volume controls

Press the Volume up or Volume down button to adjust the volume.

1-3 Activating/Deactivating the display

Activating the display

With the display deactivated, press the On/Off button on the tablet to activate the display.

The tablet's display will then illuminate, indicating that it has been activated.

Deactivating the display

If you do not need to use your tablet temporarily, you can press the On/Off button to

deactivate the display. Your tablet will then enter standby mode to save power.

1-4 Screen lock/unlock

Screen lock

Auto-lock

You can set screen timeout by tapping Settings >Display > Sleep. If there is no

operation within the pre-set standby time, the display will automatically deactivate and your

tablet will be locked automatically.

Manual lock

If you do not need to use your tablet temporarily, you can press the On/Off button for

about 1 second to deactivate the display. Your tablet will then be locked, and will enter

standby mode.

Screen unlock

When in standby mode, press the On/Off button on your tablet to activate the display.

Then, tap and hold the lock icon and drag the slider over the unlock icon, as shown in the

illustration below.

Screen lock pattern setting

You can set the screen lock pattern by tapping Settings >Security > Screen lock

> Pattern. After this function has been enabled, you will be required to trace a personalised

unlock pattern to unlock the screen before you can use your tablet.

1-5 Navigation tips

1 - Back 2 - Home

3 - Recent apps 4 - Advanced menu

Back : Return to the previous screen.

Home : Return to the Home screen.

Recent apps : Display recently used apps.

Advanced menu : Display shortcuts such as Add, Theme, Wallpaper, Screen

manager, Desktop settings and Settings.

1-6 Home screen

This desktop enables you to quickly view and open all your applications.

In the Home screen, you can add widgets and change your wallpaper.

To add a shortcut to the Home screen, tap and hold the icon of the other screen until it

is added to the Home screen.

To change your wallpaper, tap > Wallpaper to choose a wallpaper from Local

wallpaper.

To delete something from the Home screen, tap and hold the selected item for about 2

seconds until appears beside the item, then tap area to remove it.

Switching Home screens

Your tablet has multiple desktops.

Move through screens by sliding your finger across the display. Icons can be moved from

one panel to another.

1-7 Status bar

System messages, if any, will be displayed in the status bar.

Information about WLAN connections and reception, power levels, charging status and other

notifications are displayed in the status bar.

Drop down the status bar to display the notification panel, which contains the Airplane mode

switch, WLAN setting shortcut, Auto-rotate screen switch, Brightness adjustment toolbar,

Settings shortcut etc.

1-8 Recent apps

Your tablet remembers apps you have used recently.

Tap to display a list of your recently used apps. Tap an app from the list to open it.

Tap the app left or right to end it.

1-9 Application management

Slide your finger on the Home screen to open the applications list.

Tap

Settings

Apps

to manage all your apps.

Uninstall

1. Tap the app you want to uninstall under the Downloaded tab.

2. Tap Uninstall at the top.

3. Tap OK.

Stop a running app

1. Tap Running tab.

2. Tap the running app you want to stop.

3. Tap Stop.

4. Tap OK.

1-10 Entering text
