Lenovo TAB A8-50 Manuale utente

Lenovo TAB A8-50

Quick Start Guide v1.0

Read this guide carefully before using your tablet.

All information labeled with * in this guide refers only to the WLAN

+ 3G model (Lenovo A5500-H, Lenovo A5500-HV).

Technical speciﬁcations

①Actual product may differ.

Type: CMOS Pixels: 5.0 MP (back) + 2.0 MP (front)

*Version: WLAN + 3G

Bluetooth 4.0 WLAN 802.11 b/g/n GPS

*WCDMA, GSM

4200 mAh

Wireless

communication

Display

Battery

CPU

Camera

Lenovo TAB A8-50

Model and version

Version: WLAN

Height: 217 mm Width: 136 mm Depth: 8.9 mm

Weight: 360 g

MTK 8121 Quad Core 1.3 GHz

*MTK 8382 Quad Core 1.3 GHz

*Version: WLAN + 3G

(Data only)

(Voice)

*Model: Lenovo A5500-HV;

*Model: Lenovo A5500-H;

Model: Lenovo A5500-F;

①Size and weight

Size: 8 inches (diagonal) Screen: Multi-touch display

Resolution: 1280 × 800 LCD type: IPS

First glance

Back camera

Micro USB

Front camera On/Off button

Earphone jack

*Receiver / Speaker

Volume key

microSD card slot

*Micro SIM card slot Microphone

The WLAN model ( Lenovo A5500-F ) does not have a Micro SIM card

slot.

Speaker

Installing the *Micro SIM card & microSD card

1 2 3

SIM

microSD

SIM

Step 1. Open the microSD card slot cover as shown.

Step 2. Place the micro SIM card into the micro SIM card slot and the

microSD card into the microSD card slot.

Step 3. Carefully replace the slot cover.

You can use cellular services with the WLAN + 3G model (Lenovo

A5500-H, Lenovo A5500-HV) by inserting the Micro SIM card provided by

your carrier services. Install the Micro SIM card as shown.

Only Micro SIM cards work with your tablet and Micro SIM cards are for

mobile data only.

Do not insert or remove the Micro SIM card while your tablet is turned on.

Doing so may permanently damage your Micro SIM card or tablet.

SIM

Reset

For more information about battery safety, see the Important

Product Information Guide.

Charging and turning on/off your tablet

Method Connect your tablet to a power outlet using the included

cable and USB power adapter.

Low battery Fully charged Charging

Before using your tablet, you might need to charge the battery.

Charge the battery as shown.

8306LVP502W

Printed in China

Learn more

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States,

other countries, or both.

Other company, product, or service names may be trademarks or service

marks of others.

*Manufactured under license from Dolby Laboratories. Dolby and the

double-D symbol are trademarks of Dolby Laboratories.

First Edition (January 2014) © Copyright Lenovo 2014.

For other useful manuals, please access “User Guide” from the Browser

favorites in your tablet.

For “Regulatory Notices” , please go to http://support.lenovo.com/.

Getting support

For support on network service and billing, please contact your wireless

network operator. For instructions on how to use your tablet, go to

http://support.lenovo.com/.

Radio and Telecommunications Terminal Equipment Directive

This product is in compliance with the essential requirements and other

relevant provisions of the Radio and Telecommunications Terminal

Equipment Directive, 1999/5/EC.

European Union conformity
