Lenovo Tab P11 2nd Gen Come usare
Lenovo
Tab P11 (2nd Gen)
Safety, Warranty &
Quick Start Guide
TB350FU
TB350XU
Read this guide carefully before using your device.
All information labeled with * in this guide only refers to the
WLAN + LTE model.
Reading before using your device
Reading first - regulatory information
Device models equipped with wireless communications comply with the radio
frequency and safety standards of any country or region in which it has been
approved for wireless use. In addition, if your product contains a telecom modem,
it complies with the requirements for connection to the telephone network in your
country.
Be sure to read the Regulatory Notice for your country or region before using
the wireless devices contained in your device. To obtain a PDF version of the
Regulatory Notice, go to https://support.lenovo.com.
Getting support
To get support on network services and billing, contact your wireless network
operator. To learn how to use your device and view its technical specifications, go
to https://support.lenovo.com.
Accessing your User Guide
Your User Guide contains detailed information about your device. To download
the publications for your device, go to https://support.lenovo.com and follow the
instructions on the screen.
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other
countries, or both.
Other company, product, or service names may be trademarks or service marks of
others.
Dolby, Dolby Atmos, and the double-D symbol are registered trademarks of Dolby
Laboratories Licensing Corporation. Manufactured under license from Dolby
Laboratories. Confidential unpublished works. Copyright © 2012-2022 Dolby
Laboratories. All rights reserved.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered
pursuant a General Services Administration “GSA” contract, use, reproduction, or
disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
1
Device overview
Model Version
TB350FU WLAN
TB350XU WLAN + LTE
1
109
4 2 532
12 13
6
7
7
8
11
7
7
1Volume buttons 2Microphone 3Light/Proximity sensor
4Front-facing
camera 5Card tray 6Headset connector
7Speaker 8USB-C connector 9Touch screen
10 4-point pogo-pin smart connector (for the compatible keyboard and Smart
Charging Station)
11 Power button 12 Flashlight 13 Rear camera
All pictures and illustrations in this document are for your reference only and
may differ from the final product.
2
Preparing your device
Installing cards
Install the cards as shown in the figure.
*
microSD
SIM
microSD
• Power o the device before inserting or removing a card.
• The WLAN version does not have a Nano-SIM card slot.
Charging your device
Connect your device to a power
outlet using the USB cable and
power adapter provided.
Turning on
Press and hold the Power button until the
Lenovo logo appears.
3
Accessories (optional)
The accessories do not come with all models, and are sold separately.
Keyboard pack
Name Model
Lenovo Keyboard Pack for Tab P11 (2nd Gen) KB565U
1
2
3
4
5
1Keyboard connector 2Trackpad 3Pen case
4Hinge 5Kickstand
The keyboard layout may vary by country or region, please refer to the actual
product.
Attaching the Keyboard Pack
Make sure that the camera hole is aligned with the Tablet’s rear camera when
attaching the Stand Cover to the Tablet.
4
Opening and adjusting the Kickstand
You can adjust the Tablet angle by using the Stand Cover. Grasp either side of the
Kickstand and gently open it until you reach the desired angle.
1 2
To prevent damage, do not apply excessive pressure to the Stand Cover or
force the Kickstand beyond its natural range of motion.
Using the device
You can use your device in these two modes:
With the keyboard via a pogo pin Without the keyboard
5
Storing the pen
Push up to open the pen case and then store the pen in the pen case.
1 2
• Do not overtilt or apply excessive pressure to the Stand Cover, doing so may
damage the hinges.
• The Tablet, Keyboard and Stand Cover all contain magnetic materials. To avoid
loss of magnetism, avoid exposing the Tablet, Keyboard and Stand Cover to
high temperatures or direct sunlight.
• To prevent demagnetization of credit cards and other items with magnetic data,
keep them away from the Tablet, Keyboard and Stand Cover.
• Don’t use your device in temperatures below 0°C or above 40°C.
• Don’t store or transport your device in temperatures below -20°C or above
60°C.
6
Charging the pen
1. Remove the pen cap in the
direction shown in the figure.
2. Connect the pen to a charger
with a USB-C cable.
3. Replace the pen cap on the
pen. You can start to use the
pen after charging.
1 2 3
Lenovo Precision Pen 2 (2023)
You can use Lenovo Precision Pen 2 (2023) in place of your fingers for a better
experience, such as working with specific applications to write or draw on the screen.
Name Model
Lenovo Precision Pen 2 (2023) Lenovo LP-151
Overview
1Pen cap
2
3
4
5
Indicator LED
Upper button
Lower button
Tip
2
1
3
4
5
• The indicator light will have an amber glow while charging the pen and a
white glow after it is fully charged.
• Please be cautious when using the pen. The pen contains sensitive electronic
components. Dropping it may cause damage.
7
Replacing the tip
1. Pinch the tip with tweezers or another suitable tool.
2. Remove the tip.
3. Install the stand-by tip (supplied).
1
13
2
Using the Pen
1. Hold the pen close to the tablet until a white dot appears on the screen.
2. Use the upper and lower button functions of the pen.
Using the pen on a coated screen may interfere with the pen-writing experience.
If your pen is not responsive, please try switching pen protocols. Hold both buttons
consecutively for 25 seconds to switch between pen protocols (WGP& AES).
8
Smart Charging Station
Name Model
Lenovo Smart Charging Station 2 Lenovo CR-421
12
3
1Removable back
support 2Smart connector 3USB-C connector
As shown in the picture, you can charge the battery through the Smart Charging
Station.
• Frequent insertion and removal of back support may result in looseness or
damage.
• This product is designed to work only with bundled adaptor and charging
cable, please use them in order to make the product work correctly.
