Lenovo TB-8704V Manuale utente
Cover
file:///F|/说明书/进行中说明书项目/P3592/UG/A123119-00_Lenovo TAB4 8 Plus_UG_EN/assets/en/en_0.htm[2017/6/26 15:01:39]
Lenovo TAB4 8 Plus
User Guide
TB-8704V
Basics
file:///F|/说明书/进行中说明书项目/P3592/UG/A123119-00_Lenovo TAB4 8 Plus_UG_EN/assets/en/en_1.htm[2017/6/26 15:01:40]
Basics
Before using this information and the product it supports, be sure to read the following:
Safety, Warranty & Quick Start Guide
Regulatory Notice
“Important safety and handling information” in "Appendix".
The Safety, Warranty & Quick Start Guide and the Regulatory Notice are available on the website at
http://support.lenovo.com.
Note：All pictures and illustrations in this document are for your reference only and may differ
from the final product.
Lenovo Help
Looking for help? The Lenovo Help app can offer you support for getting direct access to Lenovo's web
assistance and forums*, frequent Q&A*, system upgrades*, hardware function tests, warranty status
checks*, service requests**, and repair status**.
Note:
* requires data network access.
** is not available in all countries.
You have two ways to get this app:
Search for and download the app from Google Play.
Scan the following QR code with a Lenovo Android device.
Technical specifications
Model TB-8704V
CPU Qualcomm®Snapdragon™625
Battery 4850mAh
Wireless
communication
Bluetooth 4.2;
Wi-Fi 802.11 a/b/g/n/ac;
GPS/A-GPS/GLONASS;
LTE/LTE Global/UMTS/CA
Note: TB-8704V supports LTE Band 2,3,4,5,7,12,13,4+13,2+13,2+4,2+2,4+4,4+5,2+5, but in some
Basics
file:///F|/说明书/进行中说明书项目/P3592/UG/A123119-00_Lenovo TAB4 8 Plus_UG_EN/assets/en/en_1.htm[2017/6/26 15:01:40]
countries LTE is not supported. To know if your device works with LTE networks in your country,
contact your carrier.
Home screen
The home screen is the starting point for using your device. For your convenience, the home screen is
already set up with some useful apps and widgets.
Note: Your device's features and the home screen may be different depending on your
location, language, carrier, and device model.
You can customize your home screen at any time.
Home screen
On the first home screen, there is a Google Search bar and some useful apps.
Preview screen
Press and hold anywhere on the home screen except the icons.
At the bottom of the screen are WALLPAPERS and WIDGETS.
Add a widget to a home screen
Tap at the bottom of the preview screen, press and hold the widget you want to add, then drag it
to where you want to place it, and release.
Change the wallpapers
Press and hold anywhere on the home screen except the icons, select WALLPAPERS at the bottom
of the screen, and then choose your preferred wallpaper.
Go to > Settings > Display > Wallpaper and choose your preferred wallpaper.
Move an app to another screen
Press and hold an app that you want to move, drag it to where you want to place it, then release.
Uninstall an app
1. Tap , press and hold the app that you want to uninstall.
2. Drag to , and then release and tap OK.
Note: Some of the system apps cannot be uninstalled.
Basics
file:///F|/说明书/进行中说明书项目/P3592/UG/A123119-00_Lenovo TAB4 8 Plus_UG_EN/assets/en/en_1.htm[2017/6/26 15:01:40]
Screen buttons
There are three buttons at the bottom of the screen.
Back button: Tap to return to the previous page.
Home button: Tap to return to the default home screen.
Recent button: Tap to view recent apps. Then you can do the following:
Tap an app to open it.
Tap to lock the app or tap to unlock it.
Swipe an app window right or left to close it.
Tap to stop running the app.
Tap to stop running all the apps.
Notifications and Quick Settings
The Notifications panel informs you of new messages, USB connection, and activities in progress such
as file downloading. The Quick Settings panel allows you to access frequently-used settings such as the
Wi-Fi switch.
You can do any of the following:
To see notifications, swipe down from the top of the screen.
To close the Notifications panel, swipe up from the bottom of the screen.
To dismiss a notification, swipe left or right across the notification.
To dismiss all notifications, tap CLEAR ALL at the bottom of the Notifications panel.
To open the Quick Settings panel, swipe down from the top of the screen twice.
To close the Quick Settings panel, swipe up from the bottom of the screen.
Force shutdown/reboot
Press and hold the Power button for about 8 seconds until the device turns off, press and hold the
Power button for about 10 seconds to reboot.
Split screen mode
file:///F|/说明书/进行中说明书项目/P3592/UG/A123119-00_Lenovo TAB4 8 Plus_UG_EN/assets/en/en_2.htm[2017/6/26 15:01:42]
Split screen mode
Using split screen mode
Method 1
1. Open an app then tap .
2. Press and hold the first app, drag it to “Drag here to use split screen”, then release. This app
will be locked into position.
3. Tap > , choose the second app you want to open, the two apps will then be displayed in
split screen mode.
Method 2
1. Open an app then press and hold . This app will be locked into position.
2. Tap > , choose the second app you want to open. The two apps will then be displayed in
split screen mode.
Note: Not all applications support split screen mode.
Split screen settings
In split screen mode you can do the following:
Replace the second app
Tap to choose another app.
Adjust the split screen size
Slide the " " in the middle of the two screens to adjust the split sreen size.
Exiting split screen mode
You can exit split screen mode by:
Choosing an app that doesn't support split screen mode.
Pressing and holding to enter full screen mode.
Multi-User
file:///F|/说明书/进行中说明书项目/P3592/UG/A123119-00_Lenovo TAB4 8 Plus_UG_EN/assets/en/en_3.htm[2017/6/26 15:01:42]
Multi-User
Multi-User
There are three user types:
Owner: An owner has full control over all user permissions and manages all user accounts.
Guest: There is only one Guest account. A Guest has restricted access to the device. For instance, a
Guest can't open Unknown sources.
New User:There can be multiple user accounts, including accounts for standard users and child
user. A standard user can manage child user accounts. In child user accounts, there are many child-
friendly apps available including videos, games, music and more content can be managed in Parental
Control.
Creating new user accounts
Tap > Settings > Users > ADD USER to create user accounts.
Tap > CONTINUE to create a standard user account.
Tap > CONTINUE to create a child user. Or tap on the first home screen to create a child
user.
Note：Before you add a child user account，you need to set up screen lock to protect your
apps and personal data.
Switching between user accounts
On the home screen, swipe down from the top of the screen, and then tap user photos to switch
between different user accounts.
Multi-User
file:///F|/说明书/进行中说明书项目/P3592/UG/A123119-00_Lenovo TAB4 8 Plus_UG_EN/assets/en/en_3.htm[2017/6/26 15:01:42]
On the lock screen interface, select the user photos you want to switch, then tap and swipe
up to switch to the user account.
Deleting a user account
Tap > Settings > Users, and tap the icon located beside the account you would like to delete,
then tap DELETE USER > DELETE.
Fingerprint
file:///F|/说明书/进行中说明书项目/P3592/UG/A123119-00_Lenovo TAB4 8 Plus_UG_EN/assets/en/en_4.htm[2017/6/26 15:01:43]
Fingerprint
Different users can set fingerprints to unlock the tablet or switch to their own user interface quickly.
Adding a fingerprint
You can add more than one fingerprint.
Go to > Settings > Security > Fingerprint, follow the instructions on the screen.
Note: A lock screen pattern, PIN, or password is required to use fingerprint-related functions.
Other users can also set individual fingerprints following the above operations. To set screen
lock, go to Settings > Security > Screen lock.
Adding a fingerprint for kid
Switch to child user account. On the home screen, swipe down from the top of the screen.
Fingerprint
file:///F|/说明书/进行中说明书项目/P3592/UG/A123119-00_Lenovo TAB4 8 Plus_UG_EN/assets/en/en_4.htm[2017/6/26 15:01:43]
Tap > Security > Fingerprint，then add the fingerprint following the instructions on the screen.
Delete a fingerprint
Go to > Settings > Security > Fingerprint.
Confirm your screen lock pattern or enter your PIN or password.
Tap the fingerprint you want to delete, tap DELETE, and then tap YES, REMOVE.
Note:Other users can delete the fingerprints following the above operations.
Camera
file:///F|/说明书/进行中说明书项目/P3592/UG/A123119-00_Lenovo TAB4 8 Plus_UG_EN/assets/en/en_5.htm[2017/6/26 15:01:44]
Camera
To open the Camera app, go to Camera.
Taking photos and videos
You can take photos and record videos with your device's built-in camera.
Tap to take a photo.
Tap to record a video.
Tap to convert to panorama mode.
Tap / to switch between the front and the rear camera.
Tap / to open or close HDR.
Tap to switch between flash modes.
