Lenovo Robotic Vacuum Cleaner X1
User Manual
Please read the User Manual before using---Warranty card included, pictures are for reference only.
Contents
English.......................................................................................................................................................................................................................................
German ....................................................................................................................................................................................................................................
De
P01
P28
Thank you for choosing the artificially intelligent (AI) Lenovo Robot vacuum cleaner! Please read all the operating
instructions carefully before using your Robot and keep the operating instructions for future reference. We know you
will love this vacuum! Lenovo Robot is a highly intelligent sweeping robot that utilizes high-precision radar and an
array of other sensors, all working together through navigation algorithms to create and follow sophisticated,
accurate maps and plans. Sweeping, vacuuming, and mopping, all in one, with the end result being regular, efficient
full indoor cleaning that can be performed without the need of any human assistance.
Region
ipcsupport@lenovo.com
Global
E-mail
Lenovo Robotic Vacuum Cleaner Contact List
1
Dear Customers
Mopping cloth x 1Water tank x 1
Universal plug x 4 Water tank filter
elements x 6
Main machine x1
Power adapter x 1 Cleaning tools x 1User manual x 1
Charging dock x 1
2
Packing List
Damp proofing pad x 1
o Recharge/Spot cleaning button
o Cleaning/Power button
• Short press to recharge/pause
•Long press and hold to start Spot cleaning
• Short press to start sweeping/pause
• Press and hold for 3 seconds to turn on/off
• If abnormal condition, please press and hold
for 15 seconds to force poweroff
Note:
•Press any key while cleaning, recharging or spot cleaning to pause the current task.
•After power on, press both buttons and hold for 3 seconds to reset Wi-Fi
3
Main machine
Product Overview
Main brush
cover and buckle
Main brush
Main wheel
(driving wheel)
Dust brush
Universal wheel
Main machine
Product Overview
4
Cover
Protection strip
Power button
Recharge button
LDS laser
distance sensor
Water tank
Water inlet
Installation switch
Radar cover/
collision sensor
TOF Wall sensors
Recharging sensors
Main machine
Product Overview
5
Wi-Fi indicator light
Reset hole
Dust bin bracket
HEPA Filter
Dust bin bracket Dust bin cover
Dust bin
Product Overview
6
Power indicator light
Charging
electrode strips
Signal emission area
Wire slot exit
Bottom
cover
Power port
Charging dock
Product Overview
7
