LevelOne WUA-0614 Manuale utente

150Mbps Wireless

Nano USB Adapter WUA-0614

H/W Version: 2

The LevelOne WUA-0614 is an IEEE 802.11b/g/n N

Wireless USB Adapter which is designed to be both

aordable, and oer fast speeds of up to 150Mbps.

It is designed for the Home and SOHO user who needs

enhanced range and performance, while the WPA2

wireless encryption ensures that the data transmitted

is secured.

The detachable antenna also gives users the exibility

to add a higher gain antenna which allows for a

customizable boost in performance.

Key Features

- Upgrades your wireless network up to 150Mbps

- Provides 2dBi detachable antenna

- Eortless wireless security with a simple push of the

WPS button

- Quick and easy installation

- Compatible with IEEE 802.11b/g/n wireless

standards

- Supports WEP, WPA and WPA2 encryption with

IEEE 802.1X for high level security

- USB 2.0 interface

- Supports Windows XP/Vista/7

WBR-6804

150Mbps Wireless Dual-WAN

3G Router

Works Well With

1. Power/Link LED

2. USB Port

3. Wi-Fi Protected Setup (WPS) Button

4. Detachable Antenna (2dBi)

*Theoretical throughput, actual performance depends on equipment and network conditions.

WBR-6603

150Mbps Wireless ADSL2+ Modem

Router

Network Adapters

www.level1.com

one world_one brand_one level_

Technical Specication

Product Diagram

WUA-0614

Internet

Wireless Router

Cable/DSL Modem

NAS

Notebook

Standard Compliance

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Hardware Specication

USB Port Type: USB 2.0

Radio Operation

Data Transfer Rate

IEEE 802.11n: Up to 150Mbps (40Mhz)

IEEE 802.11n: Up to 75Mbps (20Mhz)

IEEE 802.11g: 54, 48, 36, 24, 18, 12, 9 and 6Mbps

IEEE 802.11b: 11, 5.5, 2 and 1Mbps

Modulation

IEEE 802.11n: BPSK, QPSK, 16-QAM, 64-QAM

IEEE 802.11g: OFDM

IEEE 802.11b: CCK, QPSK, BPSK

Frequency Band

2.412GHz ~ 2.462GHz (FCC)

2.412GHz ~ 2.472GHz (ETSI)

Number of Channels

Channel 1 ~ 11 North America (FCC)

Channel 1 ~ 13 Europe (ETSI)

Transmitter Output Power (Typical)

IEEE 802.11n: 14 ± 2dBm

IEEE 802.11g: 14 ± 2dBm

IEEE 802.11b: 17 ± 2dBm

Antenna Type

2dBi External Detachable Antenna

Network Security

WEP-64/128 bit

WPA (TKIP/AES)

WPA2 (TKIP/AES)

IEEE 802.1X RADIUS

WPS

Device Management

Windows Utility Software

OS Supported: Windows XP / Vista / 7

Physical Specication

Dimensions: (L x W x H)

45mm x 20mm x 11mm

Weight

17.8g

Environment Specication

Temperature

Operating Temperature: 0°C~40°C

Storage Temperature: -20°C~70°C

Humidity

Operating Humidity: 10% ~ 90% RH (Non-condensing)

Storage Humidity: 5% ~ 95% RH (Non-condensing)

Certications

CE, FCC

Computer

Order Information WUA-0614: 150Mbps Wireless Nano USB Adapter

Package Contents WUA-0614

2dBi Antenna x 1

Quick Installation Guide

CD Manual / QIG / Utility

All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.

V2.0
