LevelOne PLI-2030 Manuale utente

LevelOne

PLI-2030

200Mbps HomePlug AV Ethernet Bridge

User Manual

V1.0.0-0611

HomePlug Powerline

HomePlug powerline is an excellent solution that can be used to extend your network. In the home or small office

building, use HomePlug Ethernet Bridge Adapters to link multiple locations without the need to run Ethernet cable.

Combined with a broadband DSL/Cable connection, every room with electrical power outlets will have easy access

to high-speed Internet connection.

Introduction

200Mbps HomePlug AV Ethernet Bridge allows you to connect any device which has an Ethernet port to a Power-

line network. In operation, the 200Mbps HomePlug AV Ethernet Bridge is completely transparent, and simply

passes data between the Ethernet port and the Powerline network. The Powerline data transfer rate can be

reached up to 200Mbps. Any device may be connected to the 200Mbps HomePlug Ethernet Bridge’s Ethernet port,

but a Windows PC must be used for configuration.

* Strongly recommend Windows 2000/XP for utility configuration

Physical Details

Figure 1: 200Mbps HomePlug AV Ethernet Bridge

Front Panel LEDs

Power On - Normal operation.

Off - No power

HomePlug On - The Powerline network is active. This means that at least one other HomePlug de-

vice was detected.

Off - Powerline network is not available - no other HomePlug devices were detected.

Flashing - Data is being transmitted or received via the Powerline network.

Ethernet On - Ethernet connection is active.

Off - No Ethernet connection.

Flashing - Data is being transmitted or received via the Ethernet Port.

Rear Panel

The rear panel contains only the AC plug and a sticker containing the 200Mbps HomePlug AV Ethernet Bridge’s

Password. (Each HomePlug device contains a unique Password.)

Setup

Configuration requires the use of Windows PC. Once configured, any device may be connected to the 200Mbps

HomePlug AV Ethernet Bridge's Ethernet port. To perform configuration, follow the procedures list below.

1. Connect a standard LAN cable from the 200Mbps HomePlug AV Ethernet Bridge's Ethernet port to your PC.

2. Plug the 200Mbps HomePlug AV Ethernet Bridge into a power outlet.

3. Wait a few seconds for startup to be completed, and then check the LEDs

•The Power LED should be ON.

•The HomePlug LED will be ON if other HomePlug devices are detected, otherwise it will be OFF.

•The Ethernet LED should be ON.

4. Insert the supplied CD-ROM into your Windows PC, and wait for it to start, select “Utility” from the autorun

screen. If it does not start automatically, locate and run SETUP.EXE.

5. Follow the prompts to install the PLI-2030 utility.

6. Microsoft .NET Framework 1.1 is needed for installing PLI-2030 utility. The wizard will check automatically

whether the Microsoft .NET Framework 1.1 was installed on your PC or not. If not, the wizard will pop up a

message box. Click OK to install Microsoft .NET Framework 1.1 first.

Figure 2: Microsoft .NET Framework 1.1 Screen

7. Once installation is completed, run the PLI-2030 utility program. The first screen (Network Tab) will display in-

formation of the compatible devices found, such as their MAC Addresses and current transfer speeds.

Choose the desired device from the Device Selection, and the information of the selected device will be dis-

played in the table.

Figure 3: PLI-2030 Utility - Network Tab

8. The status bar (bottom part of the window) indicates the connection status of the HomePlug device. Click the

Encryption tab. You will see a screen like the example below.

Figure 4: PLI-2030 Utility - Encryption Tab

9. Enter both the Remote Device password in the DAK Password field and the desired Network Key in the field

provided. Click “Set” to save this value to the remote HomePlug device.

If the DAK Password is left blank, the Network Key will be saved to the local HomePlug device only.

•All HomePlug devices must use the same Network Key, or they will not be able to communicate with each

other.

•On this screen, you can also click Use default to use the 200Mbps HomePlug AV Ethernet Bridge's default

Network Key.

10.Click Close to exit the PLI-2030 utility.

Setup is now complete.

If your PC is not the device you wish to use with the 200Mbps HomePlug AV Ethernet Bridge, connect the

Ethernet cable from the 200Mbps HomePlug AV Ethernet Bridge to the desired device.

The 200Mbps HomePlug AV Ethernet Bridge is now ready for use.

Operation

Operation is completely automatic, and no user intervention is required.

If your HomePlug devices have difficulty communicating with each other, check the following:

•Each HomePlug device must use the same Network Key.

You can use the Encryption tab of the PLI-2030 utility to assign a Network Key to other HomePlug devices.

•200Mbps HomePlug AV Ethernet Bridge works better when plugged into the wall socket. Connect the

200Mbps HomePlug AV Ethernet Bridge into the power strip or surge protectors may degrade the network

performance.

Specification

Powerline Standards HomePlug AV

Transfer Rate Up to 200 Mbps

Modulation 1024/256/64/16/8 QAM, QPSK, BPSK

Forward Error Correction Turbo Codes

Protocol TDMA, CSMA/CA

Security 128-bit AES Encryption

LEDs 1 * Power

1 * HomePlug

1 * Ethernet

Ethernet Interface 1 * RJ45 LAN Port

Auto-negotiation, Auto MDI/MDIX

Ethernet Standards Ethernet specification IEEE802.3, IEEE802.3u, IEEE802.3x

Power 100 - 240VAC, 50/60 Hz

Power Consumption 100mA (max.)

Operating Temperature 0°C to 45°C

Storage Temperature -25°C to 70°C

Operating Humidity 10-90%RH (max)

Certifications FCC Part 15 Class B

CE Mark, 89/336/EEC

Safety Approvals UL Listed (UL60950-1)/cUL CSA No.22-60950-01-03

CB, IEC/EN 60950-1;2001

Operating Systems Windows 98SE, Windows ME, Windows 2000, Windows XP or any other operating

system with network support
