LevelOne CamCon WCS-2030 Manuale utente



11g Wireless

IP Network Camera WCS-2030

H/W Version: 3

Compact Sized Digital IP Network Camera

Have your home surveillance in your hand with

the LevelOne WCS-2030 compact-sized IP network

camera. It is able to broadcast live images to your

handheld mobile phone or PDA which supports

3GPP/ISMA RSTP format. This is the perfect network

camera for home and oce surveillance systems. This

device is able to transmit optimal synchronized video

and audio over the Internet thus provides the remote

monitoring capabilities.

Wireless Digital Surveillance

In order to provide exible connection possibilities,

the WCS-2030 can transmit video streaming either

through a 54Mbps wireless network or an Ethernet

connection.

With a built-in web server, WCS-2030 provides an

easy user interface for remote access to receive video

signals from anywhere anytime over the Internet.

DDNS is also congured to allow this camera to use an

easier naming format to remember rather than an IP

address.

Free bundled Surveillance Software

The WCS-2030 bundles with free software that allows

the administrator to monitor up to 32 channels

simultaneously.

This software supports even more features such

as recording of streaming video directly to hard

disk, enable motion detection and several video

enhancement features, making this network camera

an ideal solution.

Key Features

- Live video and audio monitoring via 3G Mobile

phone

- Installs easily on a 802.11b/g Wireless LAN or wired

Ethernet

- Up to 30 frames per second in VGA resolution

- Supports UPnP for Easy set-up and installation

- Motion detection

- Event-notication via E-mail

- Free software included (Industry-leading 32-channel

IP CamSecure Lite™ software)

FCS-7011

1-Port PoE Video Server

Works Well With

1. Status LED

2. Built-in Microphone

3. Power In

4. LAN Port

FCS-9464

IP CamSecure Pro64 Mega

41 2

Network Camera

www.level1.com

one world_one brand_one level_



Network

Standards Compliance

IEEE 802.3u

IEEE 802.11b/g

Ports

1 x RJ-45 10/100 Mbps port

Antenna

Gain Value: 2dBi

RF Output Power: 64QAM: 14dBm; 16QAM: 15dBm;

QPSK: 16dBm BPSK: 17dBm DBPSK, DQPSK,CCK: 17dBm

Video

Compression Mode

Stream Video (MPEG4)

Still Photos (JPEG)

Max. Resolution

640 x 480

Frame Rate

Up to 30/25 frames at 160 x 120

Up to 30/25 frames at 176 x 144

Up to 30/25 frames at 320 x 240

Up to 30/25 frames at 640 x 480

Still Picture

JPEG

Video Record

AVI

Camera

Sensor

¼” Color CMOS Sensor

Lens

4.0mm, F=2.0

View Angle

Vertical 37°

Horizontal 49°

Minimum Illumination

1.5Lux / F2.0

Electronic Shutter (Sec)

1/60 ~ 1/15,000 sec

AGC/AWB/AES

Audio

Microphone

Omni-directional

Frequency

50 ~ 16000Hz

Audio Codec

Algorithm GSM-AMR/MPEG4 AAC

Supports audio mute

S/N Ratio

More than 60dB

Zoom

Digital Zoom

Hardware & Environment

Flash ROM

4MB Flash ROM

SDRAM

32MB SDRAM

Housing

Indoor use

Power

Input: 100~240VAC, 50/60Hz, 0.4A

Output: 5VDC, 2A

Temperature

Operating: 0°C ~50°C (32°F ~ 122°F)

Humidity

Operating: 10%~95%(Non-Condensing)

Dimension

72.8mm(W) * 28.6mm(D) * 115.2mm(H)

Weight

215g

Supported Protocols

IPv4,TCP/IP, HTTP,HTTPS,UPnP,RTSP/RTP/RTCP, GMP,SMTP,FTP,D

HCP,NTP,DNS,DDNS and PPPoE

Software

Bundled with 32-Channel LevelOne IP CamSecure Lite

surveillance management software

Viewing System Requirement

Microsoft Windows 2000/XP/Vista

Browser

Mozilla, Firefox, Safari, Netscape, IE 6.x or above

3GPP Player

Real Player 10.5 or above

Quick Time 6.5 or above

EMI and Safety

FCC, CE

Technical Specication



Internet

Remote

User

ADSL RouterSwitch

WCS-2030

Control Console

Order InformationWCS-2030: 11g Wireless IP Network Camera

Package ContentsWCS-2030

Power Adapter

Antenna

Camera Stand

CD Manual/Utility

Quick Installation Guide

Product Diagram

All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.

NAS

1000Mbps

100Mbps 100Mbps

100Mbps

Wireless AP

WCS-2030

V3.0
