DC Power Distribution Module 48212-DC
48212-DC
Product
Specifications
Leviton Mfg. Co., Inc.
59-25Little Neck Pkwy • Little Neck, NY 11362-2591•Tech Line: 1-800-824-3005 • Fax: 1-800-832-9538
Visit our Website at: www.leviton-lin.com
APPLICATION
The DC Power Distribution Module provides high-quality
electrical power for the separate DC-powered components in
the Structured Media™ Enclosure. Powered by a single DC
power supply,the Power Distribution Module supplies fully-
regulated 12 VDC power for multiple devices.
PHYSICAL SPECIFICATIONS
Dimensions: 6.58"H x 2.5"W x 1.5"D
Input: 110 VAC
Output: Provides 12 VDC power @ 1500 mA
Wire Gauge: 18-14 AWC
Bracket: White, ABS
FEATURES
•Contains six removable, double screw terminal jacks
•Each jack utilizes slot-drive screws
•Shipped with six wires containing 18gauge connectors
and 2.1mm power plugs
•Fully regulated (12 VDC regulated output)
DC Power Distribution Module
WARRANTY INFORMATION
•Two-year limited product warranty.
TYPICAL SPECIFICATIONS
The DC Power Distribution Module contains six removable, double
screw terminal jacks. It maintains a 12 VDC regulated output. It
uses up to 14 gauge wire. The manufacturer provides a two-year
limited product warranty.
2
Leviton Mfg. Co., Inc.
59-25 Little Neck Pkwy • Little Neck, NY 11362-2591 • Tech Line: 1-800-824-3005 • Fax: 1-800-832-9538
Visit our Website at: www.leviton-lin.com
Product Specifications 48212-DC
.............................
DIMENSIONAL DIAGRAM
ORDERING INFORMATION
Cat. No. Description
48212-DC DC Power Distribution Module
©2005 Leviton Manufacturing Co., Inc. B-1079/D5 js
Note: Features and specifications are subject to change.
