To Other Slaves
(if applicable)
Master/Slave Modes
The Lex7Star can be linked together with other Lex7Star units to
create a stunning, in-sync lightshow. This is acheived by linking the
units together via the 3 pin DMX connections at the rear. Please see
diagram below:
Lex7Star
Master
Lex7Star
Slave 1
Lex7Star
Slave 2
DMX
IN OUT
DMX
IN OUT
DMX
IN OUT
Master Dip Switch Setting:
1 2 3 4 5 678 9 10
on
o
Slave(s) Dip Switch Setting:
1 2 3 4 5 678 9 10
on
o
By choosing the Master program mode and connecting the DMX OUT
to another xture will allow the Slaves to copy the Master. The above
example shows the Master set to Sound-To_Light Mode. Dip switch 9
on the Slave(s) tell the unit it is a slave.
DMX Mode
DMX (Digital Multiplex) is a universal protocol used as a form
of communication between intelligent xtures and controllers. A
DMX controller sends DMX data instructions from the controller
to the xture. DMX data is sent as serial data that travels from
xture to xture via the DATA “IN” and DATA “OUT” XLR termi-
nals located on all DMX xtures.
The Lex7Star is a DMX enabled xture and the DMX mode and
DMX address settings are controlled via the Dip Switches. It
also carries the standard 3-pin XLR connections for DMX use.
To set your xture for use with a universal DMX controller:
Dip Switches all to the OFF position
12345678 9 10
o
on
With all Dip switches set to OFF position now means your
xture is now in DMX mode and is awaiting for you to assign a
DMX Fixture address. Address settings are obtained by using
dip switches 1 - 9. See example below:
Light 1 in the (01)DMX Universe - Dip 1 to ON
Light 2 in the (17)DMX Universe - Dip 1 & 5 to ON
Light 3 in the (34)DMX Universe - Dip 2 & 6 to ON
This based on the controller having 16 channels per xture.
Please see the instructions of your controller for more details on
xture addressing.
DIP #1 #2 #3 #4 #5 #6 #7 #8 #9 #10
Value 1 2 4 8 16 32 64 128 256 No
Function
