Lexmark 4600 Series Manuale utente

Quick Reference

Lexmark™ X4600

Avoiding jams in the ADF

To avoid jams in the Automatic Document Feeder

(ADF), make sure that the leading edge of the

original document has no damage. Use the scanner

glass instead of the ADF to scan damaged paper or

the following paper types. These paper types cannot

be properly fed by the ADF:

•Paper with clip or staple attached

•Paper with ink not totally dry

•Paper with inconsistent thickness, such as

envelopes

•Paper with wrinkles, curls, folds, or tears

•Tracing paper, coated paper, or carbonless

paper

•Paper that is too large or too small

•Items other than papers, such as cloth, metal,

or OHP film

•Notched paper

•Paper with an odd (non-rectangular) shape

•Photographic paper

•Paper with perforations on its side

•Very thin paper

Avoiding misfeeds in the ADF

•Make sure the original document has been

inserted all the way into the ADF.

•Clean or replace the pick pad and pick rollers

regularly. For more information, see “Cleaning

or replacing the pick roller” on page 2 or

“Cleaning or replacing the pick pad” on page 2.

Loading original documents in the

ADF

1Load an original document faceup in the ADF.

2Adjust the paper guides on the ADF to rest

lightly against the edges of the paper.

Note: Adjusting the paper guides

incorrectly may cause the paper to

jam or skew.

Loading original documents on

the scanner glass

1Open the scanner cover.

2Place the document facedown on the scanner

glass in the upper left corner.

3Close the scanner cover to avoid dark edges on

the scanned image.

Cleaning the scanner glass

Clean the scanner glass at least once a month or

more frequently, if needed. Clean the scanner glass

when vertical streaks appear on your printed pages.

1Open the scanner cover.

2Dampen a clean, lint-free cloth or paper towel

with an ammonia-free, de-ionized glass

cleaner.

Warning: Do not spray the cleaner directly on

the glass or use alcohol.

3Wipe the scanner glass, ADF scanner glass,

and backing material

4Close the scanner cover.

Cleaning the printer control panel

1Dampen a clean, lint-free cloth or paper towel

with an ammonia-free, de-ionized glass

cleaner.

Note: Do not spray the cleaner directly on

the printer control panel.

2Wipe the printer control panel by moving the

cloth or paper towel from side to side.

Backing material

Scanner glass

ADF scanner

glass

Cleaning or replacing the pick

roller

Clean the pick roller on a regular basis to ensure that

the ADF feeds paper properly. Replace the pick roller

when needed.

1Open the ADF cover.

2Press down on the pick roller release lever.

3Pull down on the pick roller, and then remove it.

4If you are cleaning the pick roller, dampen a

clean, lint-free cloth or paper towel with 91% or

greater Isopropyl Alcohol, and then wipe the

pick roller.

5If you are replacing the pick roller, unpackage

the replacement pick roller.

6Insert the cleaned or replacement pick roller,

and then push up on it to lock it into place.

7Press up on the pick roller release lever to lock

it.

8Close the ADF cover.

Cleaning or replacing the pick pad

Clean the pick pad on a regular basis to ensure that

the ADF feeds paper properly. Replace the pick pad

when needed.

1Open the ADF cover.

2Remove the pick pad.

3If you are cleaning the pick pad, dampen a

clean, lint-free cloth or paper towel with 91% or

greater Isopropyl Alcohol, and then wipe the

pick pad by moving the cloth or paper towel

from side to side.

4If you are replacing the pick pad, unpackage the

replacement pick pad.

5Insert the cleaned or replacement pick pad.

6Click the pick pad into place.

7Close the ADF cover.

Clearing jams

290–292 Scanner Jam

1Open the ADF cover.

Note: Make sure that the ADF cover is

opened completely.

2Remove the jammed paper by gently pulling it

straight out, and then close the ADF cover.

3If the paper cannot be removed from the ADF

cover, then open the scanner cover, and gently

remove the jammed paper.

Note: Make sure that the scanner cover is

opened completely.

Warning: Do not fold or crease the ADF tabs.

Doing so may cause jams.

4Load the documents back into the ADF.

ADF tabs
