LEYBOLD VARODRY VD65 Manuale utente

VARODRY

VD65/VD100/VD160/

VD200

Operating instructions 300766038_002_C3

Part No.

111065Vxx

111100Vxx

111160Vxx

111200Vxx

Trademark credit

Leybold and the Leybold logo are trademarks of Leybold GmbH, Bonner

Strasse 498, D-50968 Cologne.

1 Safety and compliance. . . . . . . . . . . . . . . . . . . . . . . 6

1.1 Denition of Warnings and Cautions. . . . . . . . . . . . . . . . . . 6

2 Important Safety Information. . . . . . . . . . . . . . . . . . 7

2.1 Mechanical hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.2 Electrical hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3 Thermal hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.4 Hazards caused by materials and substances. . . . . . . . . . 8

2.5 Noise hazard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.6 Risk of damaging the pump. . . . . . . . . . . . . . . . . . . . . . . . 8

3 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.1 Supplied equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.2 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.3 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4 Transport and storage. . . . . . . . . . . . . . . . . . . . . . 13

5 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5.1 Placement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5.2 Conforming use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5.2.1 Non-conforming use. . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5.3 Connect the pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5.4 Removal of pump cover. . . . . . . . . . . . . . . . . . . . . . . . . . 16

5.5 Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

5.6 Optional VFD use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

5.7 Purge gas/Gas ballast connection (optional). . . . . . . . . . . 17

5.8 Manual Gas Ballast Conguration. . . . . . . . . . . . . . . . . . . 18

5.9 Connecting solenoid gas ballast/purge valves. . . . . . . . . . 19

6 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

6.1 Switching off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

7 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

7.1 Maintenance schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . 21

7.2 Tools required for maintenance. . . . . . . . . . . . . . . . . . . . . 22

7.3 Pump timing belt change. . . . . . . . . . . . . . . . . . . . . . . . . 22

Contents

7.4 Replace the belt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

7.4.1 Disassemble drive enclosure. . . . . . . . . . . . . . . . . . . . . 23

7.4.2 Disassemble rotor disc, screw and fan. . . . . . . . . . . . . 24

7.4.3 Disassemble belt chamber cover. . . . . . . . . . . . . . . . . . 24

7.4.4 Disassemble fail safe gears. . . . . . . . . . . . . . . . . . . . . . 25

7.4.5 Disassemble belt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

7.4.6 Assemble tooth belt. . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

7.4.7 Assemble motor screw. . . . . . . . . . . . . . . . . . . . . . . . . 28

7.4.8 Assemble fail safe gear. . . . . . . . . . . . . . . . . . . . . . . . . 28

7.4.9 Assemble belt chamber cover. . . . . . . . . . . . . . . . . . . . 30

7.4.10 Assemble fan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

7.4.11 Assemble drive enclosure. . . . . . . . . . . . . . . . . . . . . . 31

7.4.12 Electric connection. . . . . . . . . . . . . . . . . . . . . . . . . . . 32

7.4.13 Verify motor rotation. . . . . . . . . . . . . . . . . . . . . . . . . . 32

7.5 Blow off valve cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . 33

7.6 Replace electrical motor. . . . . . . . . . . . . . . . . . . . . . . . . . 34

7.6.1 Motor disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

7.6.2 Motor assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

7.7 Table: Motor part list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

8 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . 44

9 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

9.1 Waste disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

10 Leybold Service. . . . . . . . . . . . . . . . . . . . . . . . . . . 47

300766038_002_C3 - 09/2021 - © Leybold

Contents

Figure 1. Dimensional drawing (mm). . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Figure 2. Transportation of the pump. . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Figure 3. Connections and controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Figure 4. Remove the cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Figure 5. Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 6. Arrow - direction of rotation. . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 7. Manual gas ballast conguration. . . . . . . . . . . . . . . . . . . . . . 18

Figure 8. Connecting solenoid gas ballast/purge valves. . . . . . . . 19

Figure 9. Tools required for maintenance. . . . . . . . . . . . . . . . . . . . . . . 22

Figure 10. Blow off valve cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

List of Figures

1 Safety and compliance

1.1 Denition of Warnings and Cautions

NOTICE:

For safe operation from the start, read these instructions carefully before you install or

commission the equipment and keep them safe for future use.

Read all the safety instructions in this section and the rest of this manual carefully

and make sure that you obey these instructions. The equipment must only be

operated and maintained by trained personnel in the proper condition and as

described in this instruction manual.

Obey local and state requirements and regulations. If you have any questions about

safety, operation or maintenance of the device, please contact our nearest subsidiary.

Important safety information is highlighted as warning and caution

instructions. Obey these instructions.

WARNING:

If you do not obey a warning, there is a risk of injury or death. Different symbols are

used according to the type of hazard.

CAUTION:

If you do not obey a caution, there is a risk of minor injury, damage to equipment,

related equipment or process.

NOTICE:

Information about properties or instructions for an action which, if ignored, will cause

damage to the equipment.

We reserve the right to change the design and the stated data. The

illustrations are not binding.

Keep the instructions for future use.

300766038_002_C3 - 09/2021 - © Leybold

Safety and compliance

2 Important Safety Information

Pressures given in bar or mbar are absolute values. If exceptionally a gauge

pressure is meant, a “g” is added (for example, bar (g)).

2.1 Mechanical hazards

WARNING:

When rotated in the wrong direction, the pump will generate up to 4.5bar (g) pressure

at the inlet. If a vacuum system is connected, the pressure build up can lead to

explosion of the system.

1. Avoid exposing any part of the human body to the vacuum.

2. Select a secure place for the appliance (level surface).

3. Never operate the pump without a connected intake line or without

tting a blank ange.

4. The discharge port of the pump must not be blocked or constricted.

Never operate the pump with a seal-off stopper in place blanking off

the exhaust port. Operate the pump only with a connected vacuum

system to the intake ange.

5. With a closed exhaust pipe, the pump can generate up to 1.5 bar (g)

overpressure on the exhaust. The exhaust pipes should be laid out

accordingly.

6. Condensates from the pump can collect inside or at the exhaust,

escape and spill onto the oor, when operating the pump without an

exhaust line or during transport with an exhaust being not blanked off.

In this case there exists the risk of slipping.

7. Take note of the labelling of inlet and outlet. A mix-up can lead to

dangerous build-up of pressure in the vacuum system or in the

system. After each change of the electrical connection, check the

pump's rotational direction.

8. In case of power supply outage, the vacuum system is ventilated by

the pump. If this is not wanted, install a non-return valve at the inlet.

9. After a loss of power, the pump restarts independently. If this is not

wanted, install a restart inhibitor.

10. Do not operate the pump with any of the covers removed. This may

result in serious injury.

2.2 Electrical hazards

DANGER:

After a mains power failure the pump will run up automatically again. This also applies

in the case of an emergency shut-down. In order to prevent the pump from running

up automatically again, the pump must be integrated within a control arrangement

such that it can only be switched on manually again after the mains power has

returned.

1. Housing parts must not be removed.

2. The electrical connection must only be provided by a trained person.

3. Obey the national regulations in the country of use like EN 50110-1 for

Europe.

300766038_002_C3 - 09/2021 - © Leybold

Important Safety Information

4. Note the information on the IP type of protection.

2.3 Thermal hazards

CAUTION:

The surface of the pump may attain temperatures over 80 °C. There is the risk of burn

injury.

1. Before servicing and maintenance work, always leave the pump to

cool down.

2.4 Hazards caused by materials and substances

DANGER:

Before commissioning the pump, make sure that the media which are to be pumped

are compatible with each other so as to avoid hazardous situations. Observe the

instructions for proper and improper use of the pump in Conforming Use.

2.5 Noise hazard

CAUTION:

The noise level of the pump during ultimate pressure operation corresponds to the

values stated in the technical data. In other operating modes and depending on the

connected vacuum system, higher values can be expected. Make sure that suitable

protection measures are taken to protect your hearing.

2.6 Risk of damaging the pump

1. Before starting up for the rst time, the motor circuit must be equipped

with a suitable protective motor switch. Please take note of the

information in these Operating Instructions and on the electric motor

(wiring diagram).

2. Do not allow the ingestion of objects (screws, nuts, washers, pieces of

wire, etc.) through the inlet port. If required, use an inlet lter.

3. Do not use the pump for applications that produce abrasive or

adhesive powder vapour sales or service department for advice.

4. This pump is suited for pumping water vapour within the specied

water vapour tolerance limits.

5. Avoid vapour that can condense into liquids when being compressed

inside the pump, if these substances exceed the vapour tolerance of

the pump.

6. In the case of wet processes we recommend the installation of liquid

separators upstream and downstream of the pump as well as the use

of the gas ballast.

7. The exhaust line should be laid so that it slopes down and away from

the pump so as to prevent condensate from back streaming into the

pump.

8. Avoid the entry of particles and uids.

9. The air intakes of the pump and the motor must remain free.

300766038_002_C3 - 09/2021 - © Leybold

Important Safety Information

3 Description

The pump is a dry-compressing vacuum pump and can evacuate containers

in the rough vacuum range.

The pump is connected to a 3-phase network on the motor terminal board

and operated directly from the mains. It is air-cooled and requires minimum

maintenance.

3.1 Supplied equipment

The pump is delivered ready for operation. Intake and exhaust anges are

covered with caps.

300766038_002_C3 - 09/2021 - © Leybold

Description

3.2 Technical data

Table 1 Technical data

VARODRY 65 100 160 200

Maximum pumping speed without gas ballast 65 m3/h 105 m3/h 150 m3/h 200 m3/h

Ultimate pressure without gas ballast 0.01 mbar

Ultimate pressure with gas ballast 0.1 mbar

Maximum permissible inlet pressure 1200 mbar

Maximum permissible discharge pressure

(Relative to ambient)5) 200 mbar

Water vapour tolerance with gas ballast4) 60 mbar

Water vapour capacity with gas ballast 4) 1.9 kg/h 2.9 kg/h 5.2 kg/h 6.9 kg/h

Permissible ambient temperature 0 to +40 °C

Storage temperature -20 to +60 °C

Purge gas consumption 5 slm

Purge gas supply pressure (optional) 2-4 bar (g)

Gas consumption exhaust purge (optional) 7.5-16 slm

Gas consumption inlet purge (optional) 2.5-5 slm

Noise level without external silencer, at ultimate pres‐

sure (according to DIN EN ISO 2151)

▪50 Hz versions 67 dB(A) 70 dB(A)

▪60 Hz versions 70 dB(A) 73 dB(A)

Relative ambient atmospheric humidity 95%, non-condensing

Maximum installation height1) Up to 1000 m above sea level

Cooling Air

Mains voltage 50 Hz versions 2) 400 V ± 10% or 200 V ± 10%

Mains voltage 60 Hz versions 2)

460 V ± 10% or 230 V ± 10%

200/380 V ± 10% , 3 ph

Phases 3-ph

Maximum current 50 Hz versions 200/400 V3) 6.4/3.2 A 8.6/4.3 A 13.0/6.7 A 15.5/7.5 A

Maximum current 60 Hz versions 230/460 V3) 5.6/2.8 A 7.6/3.8 A 11.3/5.7 A 13.7/6.5 A

Maximum current 60 Hz versions 200/380 V3) 6.0/3.4 A 8.3/4.6 A 12.8/6.9 A 15.5/8.9 A

Maximum power consumption 1500 W 2200 W 3000 W 4000 W

Permissible motor speed 2) 50/60 Hz

Protection class IP 55

Intake connection G 2"

Discharge ange DN G 1 1/2"

Weight (approximate) 105 kg 115 kg 130 kg 140 kg

1) Please inquire for installation heights above 1000 m.

2) Depending on version 50 or 60 Hz. Please see pump nameplate.

3) Motor protective switch must be suitable for operation with IE3 motors.

300766038_002_C3 - 09/2021 - © Leybold

Description

Altri manuali per VARODRY VD65

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali LEYBOLD Pompa dell'acqua

LEYBOLD

LEYBOLD TRIVAC B SERIES Manuale utente

LEYBOLD

LEYBOLD TRIVAC B D 40 BCS Manuale utente

LEYBOLD

LEYBOLD Sogevac Neo D Series Guida utente

LEYBOLD

LEYBOLD SOGEVAC SV300 FP Manuale utente

LEYBOLD

LEYBOLD TRIVAC B SERIES Manuale utente

LEYBOLD

LEYBOLD 11286 3i Manuale utente

LEYBOLD

LEYBOLD MAG Series Manuale utente

LEYBOLD

LEYBOLD TURBOVAC TW 250 S Manuale utente

LEYBOLD

LEYBOLD 666 420 Manuale utente

LEYBOLD

LEYBOLD TRIVAC D 16 B-DOT Manuale utente

LEYBOLD

LEYBOLD SCREWLINE SP 630 F Manuale utente

LEYBOLD

LEYBOLD TRIVAC T Series Manuale utente

LEYBOLD

LEYBOLD SOGEVAC SV200 FP Manuale utente

LEYBOLD

LEYBOLD TURBOVAC 850 i Manuale utente

LEYBOLD

LEYBOLD SOGEVAC SV630 B Manuale utente

LEYBOLD

LEYBOLD Ruvac WH 700 Manuale utente

LEYBOLD

LEYBOLD SOGEVAC SV 16 Manuale utente

LEYBOLD

LEYBOLD SOGEVAC SV40 BI FC Manuale utente

LEYBOLD

LEYBOLD DRYVAC 50 S Manuale utente

LEYBOLD

LEYBOLD RUVAC WS 251 Manuale utente

LEYBOLD

LEYBOLD DRYVAC DV 200 Manuale utente

LEYBOLD

LEYBOLD TURBOVAC TW 700 Manuale utente

LEYBOLD

LEYBOLD TRIVAC D 2,5 E-LD Manuale utente

LEYBOLD

LEYBOLD SOGEVAC SV65 B Manuale utente

Manuali Pompa dell'acqua popolari di altre marche

Neptun

Neptun NPHW 5500 Manuale utente

Sensidyne

Sensidyne Gilian BDX-II Istruzioni per l'installazione e il funzionamento

Draper

Draper 47808 Manuale utente

Trolla

Trolla 12820 Manuale utente

Sunfab

Sunfab SVH Series Manuale utente

WilTec

WilTec 50740 Manuale utente

Fieldmann

Fieldmann FVC 5015 EK Manuale utente

Everbilt

Everbilt EFSUB5-122HD Manuale utente

Graco

Graco Husky 3300e Manuale utente

esotec

esotec 101018 Manuale utente

moyno

moyno 2000 CC Manuale utente

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manuale utente

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guida alla risoluzione dei problemi

DUROMAX

DUROMAX XP WX Series Manuale utente

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manuale utente

Franklin Electric

Franklin Electric IPS Manuale utente

Xylem

Xylem e-1532 Series Manuale utente

Milton Roy

Milton Roy PRIMEROYAL Manuale utente
