Submittal Data :
Job Name :
Purchaser :
Engineer :
Submitted To :
Submitted By :
Unit Designation : Schedule No.:
Location :
P.O. No. :
Architect :
Date :
For : □Reference □Approval □Construction
Model No.:
37 13/32
1 3/16
37 13/32
R 1 3/8
33 1/16
3
5 5/16
8 7/8
31 23/32
33 1/16
27 3/32 (hanging bolt)
33 1/16
35 7/16 (ceiling opening)
37 13/32
27 3/32 (hanging bolt)
33 1/16
35 7/16 (ceiling opening)
33 1/16
27 3/32
LCN340CP
LCU340CP
Capacities :
Cooling
Outdoor Design Temp.(℉,DB/WB)
Cooling
SEER
EER
Indoor Unit :
Power Supply (V,Ph,Hz)
Maximum Fuse Size
Minimum Ampacity
Weight (lbs)
Sound (dB(A),H/M/L Cool)
Air Circulation (CFM)
Dehumidification (pts/hr)
Outdoor Unit :
Power Supply (V,Ph,Hz)
Maximum Fuse Size
Minimum Ampacity
Weight (lbs)
Sound (dB(A), High Cool)
Refrigerant Piping :
Maximum Length (ft)
Maximum Height Difference (ft)
Liquid Side (O.D)
Gas Side (O.D)
Standard Features :
• Five Year Compressor Warranty
• Two Year Functional Parts Warranty
• R-410a Refrigerant
• Multi Power System TM
• Internal Condensate Pump
• Plasma Air Purifying System
• Swirl Wind Air Circulation
• Temperature Display on Wired Thermostat Controller
and LCD Wireless Remote Controller
• Auto Restart
• 24 Hour On/Off Timer
34,000/33,500 Btu/h
95/75
13
9.4
230/208,1,60
Powered by Outdoor Unit
Powered by Outdoor Unit
57.3
40/37/34
850
7.8
230/208,1,60
50
15.1/16.5
190
58
115
66
1/4”
5/8”
Front Panel Assembly : PT-CDC1
Weight (lbs) 6.6
PT-CDC1
LC340CP
Note :
ⒸLG Electronics USA 2006 SD-LC340CP-VER1
