LG Glimmer Manuale utente

Touch

Screen

Transferring

Music

Playing

Music

Bluetooth®

Pairing

Taking a Picture/

Recording a Video

Quick Start Guide

www.LGUSA.com

Hold Key

(Unlocks

Touch Screen)

Power/

End Key

Talk Key

Clear &

Back Key

Getting to Know Your Phone

BACK SIDE

FRONT SIDE LEFT

SIDE

RIGHT

SIDE

Volume

Up/Down

USB/

Charging

Port

Headset Jack

Camera Key

Camera

microSDTM

Port

Quick Menu*

Mirror

Flash

Touch Screen

(Adaptive Menu

Interface)

Quick Touch Keys

Menu Dial Messaging Contacts

*Customizable.

Getting to Know Your Phone Touch Screen

Touch Protection

The touch screen is automatically locked when the phone is

closed or after the phone is inactive for 14 seconds (default).

Unlocking the Touch Screen

• Press the Key on the left side of the phone twice.

– or –

• Open the slider.

Using the Touch Screen

• Use the tip of your nger or the stylus to touch

the center of a touch key.

• It’s not necessary to press hard. A light touch will do.

• Press and drag your nger/stylus up or down to scroll.

• Touch End at any time to return to the idle screen.

Touch Screen Settings

• Touch Menu > Settings > Sound & Touch. Then scroll down and select

Touch Key Feedback (8) to adjust the touch screen’s sound and vibration.

• If the touch screen is not responding as you expect, calibrate the screen for touch

accuracy. Touch Menu > Settings > Sound & Touch > Touch Calibration (9).

Transferring Music

Make a soundtrack for your life! Using an optional 4GB microSD

card, you can store up to approximately 960 songs on Glimmer.

Transfer music from your PC in a ash.*

1. Insert your microSD card (gold contacts facing

down) into the memory port underneath the

battery cover.

2. Press the Key twice on the left side of the

phone to unlock the touch screen.

3. The rst time you transfer music, you must format the card.

Touch Menu > Settings > Phone Information. Scroll down

and touch Memory (6).

4. Touch Card Memory (3) > Format > Yes (1). Then touch

End to exit.

5. Connect a USB cable* from the phone to your PC.

6. The PC will recognize the phone as a Removable Disk and a

screen will appear. Drag and drop music les on your PC into the

My_Music folder.

7. When done, disconnect the phone.

*microSDcardandUSBcablerequired.Soldseparately.

Add some sparkle to your Glimmer by listening to crystal-clear music. You’ll always have

your favorite tunes on hand – and in your pocket – with this all-in-one device.*

1. Insert a microSD card containing music.

2. Press the Key twice on the left side of the phone to unlock the touch screen.

3. Touch Quick Menu , then Music.†

4. Select a song from one of the categories, then touch Play.

*microSDcardrequired.Soldseparately.

†BasedondefaultQuickMenu.

Note: You can play

music in the back-

ground while doing

other tasks. Once you

have exited the music

player with background

music enabled, touch

the song shown at the

top of the idle screen to

return to the player.

Playing Music

Minimize

(Activates background

music mode and returns

to the idle screen.)

Previous/Rewind

Play/Pause

Volume Up/Down

Back

Library

Next/Fast Forward

Exit

Options

1 Repeat

2 Shufe

3 Background Music

4 Information

Sound Effects

Repeat

Shufe

Bluetooth® Pairing

With the convenience of Bluetooth technology, you can wirelessly

connect your Glimmer to headsets, speakers, phones, and much

more. Say goodbye to that tangled mess of cables and cords.

1. Set your Bluetooth accessory into pairing mode.*

2. Press the Key twice on the left side of the phone to unlock

the touch screen.

3. Touch Menu > Settings > Bluetooth > Add New (2).

4. When prompted to turn on Bluetooth, touch Yes (1).

5. Touch Search (1) to begin a new search.

6. Once the Bluetooth device has been found, highlight it

and touch Pair.

7. Enter the PIN code* (typically “0000” – 4 zeroes) and

touch Pair.

8. Touch Yes (1) to connect with the device.

*RefertoyourBluetoothaccessory’susermanualfor

informationaboutinitiatingpairingmodeandthePINcode.

Taking a Picture/Recording a Video

Capture the action right as it happens. Glimmer features a 2.0 megapixel camera/

camcorder that is sure to give you the exibility you need to never miss a moment!

Taking a Picture

1. Press the Key twice on the left side of the phone to unlock the touch screen.

2. Rotate the phone horizontally and press and hold the side Key.

3. Refer to the callouts below for options.

4. Press to take the picture. Touch Send to send it to someone.

Recording a Video

1. Press twice on the left side of the phone to unlock the touch screen.

2. Rotate the phone horizontally and press and hold .

3. Touch Record Video , then press the side Key to start or stop recording.

Camerasettingof

1600x1200pixels

doesnotsupport

zoomfunction.

Flash

View Mode

Photo Settings

Settings

Back

Zoom In

Zoom Scroll Bar

Zoom Out

My Image

Record Video

Optional Accessories

Maximize your phone with these cutting-edge accessories at www.LGUSA.com.

Bluetooth Stereo Speakers

Portable Stereo Speakers

The Bluetooth® trademark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license.

Bluetooth Headset (HBM-750)

Stereo Headset

Bluetooth Headset (HBM-760)

Vehicle Power Charger

GLIMMERQSG/ALLTEL
