LG HT MOBILE HD3000 Manuale utente
P/N : MMBB0249001(1.0) W
HD3000 User Guide
HD3000 Hướng dẫn sửdụng
PHONE COMPONENTS 2
ONSCREEN ICONS 4
USING THE BATTERY AND
CHARGER 5
Installing and Removing the Battery 5
Charging the Battery 6
Battery Charge Level 6
BASIC FUNCTIONS 7
Turning the Phone On and Off 7
Changing the display language 7
Airplane Mode 7
Making a Call 8
Receiving Calls 8
MENU TREE 9
ENTERING AND EDITING
INFORMATION 10
Entering Information Using T9 Text
Input 10
To Edit in Viet Mode 11
MESSAGES 12
Write 12
INTRODUCTION 14
MENU FEATURES 15
SAFETY INFORMATION 25
Charger and Adapter Safety 25
Battery Information and Care 25
General Notice 25
1
CONTENTS
HD3000_Slim_Eng 7/10/07 2:29 PM Page 1
The following shows key components of your mobile phone.
PHONE COMPONENTS
2
1. Earpiece
2. Headset Jack
3. OK Key / Speaker Mode
4. Soft Key 1
5. CALL Key
6. Vibrate Mode Key
7. Microphone
8. Data Port
9. LCD Screen
10. 4 Way Navigation Key
11. Soft Key 2
12. END/PWR Key
13. Alphanumeric Keypad
14. Key Guard Key
15. Charger Port
HD3000_Slim_Eng 7/10/07 2:29 PM Page 2
LCD Screen
Displays messages &
indicator icons.
Soft Keys
The names of the functions of
these keys appear at the bottom of the
screen.
GSoft Key 1
Used to display the function setting
menu. Accepts the highlighted choice
when navigating through a menu.
GSoft Key 2
Used to search phonebook, change text
input mode, edit profiles and clear a
single space or character. Go to
previous menu.
CALL Key
Allows user to place or answer
calls. See and redial from call history.
END/PWR Key
Used to turn power On/Off
and to end a call. Using this key, you can
return to the main menu display screen.
When you press once, when a call is
received, the phone stops ringing or
vibrating depending on the mode it is in.
Press twice to reject the call.
Alphanumeric Keypad
These keys
enable you to enter numbers and
characters and choose menu items.
Navigation Key
This Navigation key
allows quick access Messages and
Voice Mail notification messages.
Ring Tone, Scheduler,
Profiles.
Vibrate Mode Key
In standby mode, set
the vibrate mode by pressing and holding
the key about 2 seconds.
OK Key / Speaker Mode
Accepts the
highlighted choice when navigating
through a menu. When pressed long,
access to Speaker Mode. When pressed
shortly, access to My Menu.
3
HD3000_Slim_Eng 7/10/07 2:29 PM Page 3
The phone screen displays several onscreen icons which appear when the phone
is powered on.
ONSCREEN ICONS
4
Displays the strength of the
signal received by the phone and
current signal strength is
indicated by the number of bars
displayed on the screen.
No service
The phone is not receiving a
system signal.
In use. A call is in progress.
* No icon indicates the phone is
in standby mode.
Charge level. Indicates battery
charge level.
Roaming mode.
In General mode
In Silent mode
In Alarm mode
In Vibrate Only mode
In Outdoor mode
Indicates that a Text Message
has been received.
In Headset mode.
R
HD3000_Slim_Eng 7/10/07 2:29 PM Page 4
Charge the battery fully before the initial use of the phone.
The phone comes with a rechargeable battery. Keep the battery charged while not
in use in order to maximize talk and standby time when using the phone.
Installing and Removing the Battery
GTo install, insert the battery into the opening on the back of the phone, and insert
the bottom of battery into groove
at the bottom of the handset.
Gently press down the cover until
the latch snaps into place.
GTo remove, push the back cover
down. Push the tab with one hand
and lift the top of the battery to
separate.
5
USING THE BATTERY AND CHARGER
groove slot
HD3000_Slim_Eng 7/10/07 2:29 PM Page 5
6
Charging the Battery
To use the AC adapter charger provided with your phone:
1. Plug the AC adapter into the electrical outlet.
2. Insert the round end of the adapter into the AC adapter jack on the bottom of the
phone. (Make sure the battery is installed.)
GAs the phone charges, the battery icon continually displays a progression from
empty ( ) to full ( ).
It takes about three hours to fully recharge a completely rundown battery. When
fully charged, battery icon indicates charging by twinkling.
Battery Charge Level
The battery charge level is shown at the top right of the LCD screen.
When the battery charge level becomes low, the low battery sensor will alert you in
three ways: sounding an audible tone, blinking the battery icon outline, and
displaying Recharge the battery If the battery charge level becomes exceedingly
low, the phone will automatically switch off and any function in progress will not be
saved.
HD3000_Slim_Eng 7/10/07 2:29 PM Page 6
Turning the Phone On and Off
1. Install a charged battery pack or connect the phone to an external power source
such as the cigarette lighter charger, car kit or AC adaptor.
2. Hold down the Key for 2 seconds until the LCD screen flashes.
NNootteeAs any other communication device, avoid any unnecessary contact with the
antenna while your phone is turned on.
Changing the display language
1. In standby mode, press Soft Key 1 Menu.
2. Press , .
3. Set
TTiiªªnnggVVii®®tt//EEnngglliisshh
with and then press Soft Key 1.
Airplane Mode
When your phone is in Airplane Mode, it cannot send or receive any calls or access
online information. You may use the phone’s other features, such as Game,
Scheduler, Memo, etc. When Airplane Mode is enabled, a message “Airplane Mode
On” is displayed on the screen.
1. In standby mode, press Soft Key 1 Menu, , , .
7
BASIC FUNCTIONS
HD3000_Slim_Eng 7/10/07 2:29 PM Page 7
2. Select On or Off and press Soft Key 1.
Making a Call
Every time you make a call, follow these steps:
1. Make sure that the phone is turned on. If not, hold down for 2 seconds.
2. Type the phone number and then press .
GIf the phone is locked, press Soft Key 2 Unlock and type the 4 digits lock code.
3. To end the call press .
Receiving Calls
1. When the phone rings or vibrate (if the Vibrate Mode is enabled), press any key
(except ) or depending on the Call setting.
GWhen you press once, when a call is received, the phone stops ringing
or vibrating depending on the mode it is in. Press twice to disconnect.
2. To end an answered call, press .
3. If you are not in the condition to receive call, pressing Soft key 2 will send a
Preset SMS to Caller. The SMS can be editted using "Edit SMS on Call Reject"
function given under Settings' Call.
8
HD3000_Slim_Eng 7/10/07 2:29 PM Page 8
9
1. Names
1. Add Name
2. Find
3. Groups
4. Speed Dial
5. Copy & Move
6. Erase Names
7. My Profile
8. Memory Info
2. Messages
1. Write
2. Inbox
3. Outbox
4. Voice Mail
5. Archive in UIM
6. Drafts
7. Templates
8. SMS Groups
9. Erase Msgs
0. Msg Settings
3. Call History
1. Missed
2. Received
3. Dialled
4. In Call Memo
5. Call Duration
6. Erase History
4. Display
1.
Ngoân ngöõ
2. Clock
3. Time & Date
4. Wallpaper
5. Menu Style
6. Rhythmic Lighting
7. LCD Backlight
8. Keypad Backlight
9. Contrast
5. Games
1. Snake2
2. Game Settings
6. Profiles
1. Vibrate Only
2. Silent
3. General
4. Outdoor
5. Headset
7. Organiser
1. Scheduler
2. Memo
3. Alarm
8. Tools
1. Stopwatch
2. Calculator
3. World Clock
4. Unit Converter
9. Settings
1. My Menu
2. Call
3. Phone
4. Security
MENU TREE
HD3000_Slim_Eng 7/10/07 2:29 PM Page 9
