Rev 2.0 US
All rights reserved.
LG Electronics Inc., 2013
Note: Please read all information carefully prior to
using HBS-800 in order to prevent damages to the
product and to enjoy the best performance.
WARNING :
This product contains chemicals known to the State
of California to cause cancer and birth defects or
reproductive harm.
Wash hands after handling.
HBS-800 User Manual
BLUETOOTH®Stereo Headset
2
ENG
Introduction 3
- Included in the package 3
Description of Parts 3
How to Use 4
- Charging 4
- Low Battery 4
- Battery Status Alert 4
- Power On / Power Off 4
- Pairing 5
- ANC - Ambient Noise Cancelling 6
- Multi-connection 7
- Auto Reconnect 8
- Audio Streaming Controls 8
- Equalizer 9
- aptX
®
9
- Volume Control 9
- Calling 9
• Answering a call 9
• Transferring a call 9
• Voice dialing 9
• Last number redial 9
• Ending a call 10
• Call waiting 10
• Rejecting a call 10
• Mic mute 10
- SMS reader 10
Summary of Button Functions 11
LED Indicator 12
Troubleshooting 12
Specification 13
Precautions 13
Declaration of Confirmation 14
Additional Information 14
Limited Warranty 17
Important Safety Information 17
Table of Contents
3
ENG
Included in the Package
Headset
The LG TONE ULTRATM (HBS-800) is a lightweight wireless headset that uses
Bluetooth®technology.
This product can be used as an audio accessory for devices supporting either the
A2DP or Hands-Free Bluetooth Prole.
Earbuds
(2 Sets)
USB Charging
Cable
User Manual Quick Start
Guide Warranty
Card
Introduction
Description of Parts
HBS-800
VOLUME UP Button
REWIND Button
ANC Switch
FAST FORWARD Button
PLAY / PAUSE / STOP Button
Earphone (R)
Charging Port
LED Indicator
Power Switch
VOLUME DOWN Button
CALL Button
Microphone
Earphone (L)
Memory Flex Neck Strap
4
ENG
Charging
- When the charger is connected, with the power switched on or off, the headset
will turn off.
- While charging, the LED indicator will show a solid red light.
- When charging is complete, the LED indicator will turn off.
- When ANC is ON, the LED remains lit in violet and charging is not completed.
Please turn off the ANC.
Low Battery
- A low battery alert will play once every 2 minutes.
- If the battery is not charged, the headset will turn off.
Power On / Power Off
- Slide the power switch to the ‘ON’ or ‘OFF’ position.
How to Use
Battery Status Alert
- Press and hold the VOLUME DOWN button for 1 second to check the battery
status of the HBS-800. The audible battery status alert will inform you of the
battery level. There are 3 levels of battery power:
1. Battery High
2. Battery Medium
3. Battery Low
- An HBS-800 battery status indicator will appear on the iPhone screen.
5
ENG
Pairing
- Before using the headset for the rst time, you must pair it with a Bluetooth-enabled
device.
- There are 2 pairing mode methods with the HBS-800.
1) Easy Pairing
a) Slide the power switch to the “ON” position.
b) If it is your rst time pairing the device it will automatically enter pairing mode.
If it has been paired but no paired device is in range it will enter pairing mode
after 10 seconds.
• The LED indicator will be solid blue.
c) On the device you wish to pair, nd the Bluetooth menu and search for new
devices.
d) Select “LG HBS800” from the list of devices.
e) If asked for a Password/Pin Code enter 0000 (4 Zeros).
f) Once the devices are paired, you will hear “Your headset paired”.
• The HBS-800 will automatically turn off if not paired within 3 minutes.
2) Manual Pairing (pairing with another phone or re-pairing)
a) With the power off, press the CALL button and slide the power switch to the
‘ON’ position. Hold the CALL button for about 2 seconds.
b) When the headset enters Pairing Mode, the LED indicator will show a solid blue
light. After the procedure repeat Easy Pairing steps “c)” through “f)”.
How to Use
6
ENG
How to Use
ANC - Ambient Noise Cancelling
Ambient Noise Cancelling is new technology that reduces ambient noise in a
noisy environment. It provides a better listening experience to you.
1) Performance
Ambient Noise Cancelling actively reduces more background noise than any other
noise cancellation technology.
2) Activating / Deactivating
a) Slide the ANC switch to the “ON” position.
b) The LED indicator will show a solid violet light and you will hear “ ANC On”.
c) Slide the ANC switch to the “OFF” position to deactivate the Ambient Noise
Cancelling feature. You will hear “ANC off”.
d) The Ambient Noise Cancelling feature is also available when the HBS-800
is set to OFF. The solid violet light will be displayed but the voice prompt will
not be played to indicate on and off.
Status ANC On ANC Off
LED Indicator Voice Prompt LED Indicator Voice Prompt
Power on
Violet “ANC On” Blue “ANC Off”
Power off Violet X X
X
3) Precautions when using Ambient Noise Cancelling
a) The Ambient Noise Cancelling feature optimizes noisy environments, such
as buses, trains, and airplanes. There is no need to use this feature in a
quiet environment.
b) Be extra cautious while walking, bicycling, or driving. You may not hear
warning signals or alarms.
c) The ANC performance might vary depending on how the headset is placed
into the ear.
7
ENG
Multi-connection
Advanced Multipoint
The HBS-800 is capable of having two devices connected to the headset at the
same time. This will give you the freedom of using call waiting between calls on
both of your connected phones.
Connection
1. Pair the headset with one of your Bluetooth-enabled phones. (per the pairing
instructions on page 4).
2. Turn the headset off and use the Manual Pairing method as described on page
5 to enter Pairing Mode.
3. Now, pair and connect the headset with your other Bluetooth-enabled phone.
(this will be your primary phone).
4. Once this phone is paired and connected, go back and connect the originally
paired phone to the headset. This will now be your secondary phone.
Note: When the HBS-800 is connected to two phones at the same
time(Multipoint), the headset calling functions will work with the primary phone.
Note: In case of failure to connect to the primary phone through Easy Pairing, the
HBS-800 will enter pairing mode.
Calling Function
- Voice Dialing and Last Number Redial features work with the primary phone (or
phone which made the last outgoing call).
Call Waiting
- While speaking on an active call, press and hold the CALL button for 1 second to
switch to an incoming call.
- To switch between 2 active calls, press and hold the CALL button for 1 second.
- To end both calls briey press the CALL button.
- If both phones are receiving an incoming call, the headset will default to the
primary device.
How to Use
8
ENG
How to Use
Auto Reconnect
- If the HBS-800 is turned off (either accidentally or intentionally) while connected
to a phone, the headset and phone will disconnect. The headset and phone will
automatically reconnect when the HBS-800 is turned back on while in range.
- The secondary phone will need to be connected manually. Select “LG HBS-800”
from the list of devices in the Bluetooth menu and pair.
Out of Range
- If the paired devices are separated by a range of 30 feet (10 meters) or more,
the headset and phone will disconnect and the HBS800 will vibrate to alert you.
- If the headset and phone do not automatically reconnect when they are back within
the required range, briey press the CALL button on the HBS-800 to reconnect
manually.
- While in multi-connection and streaming, the inactive paired device, which is out
of range, will be disconnected. The HBS-800 will alert you once with no attempt to
reconnect.
Audio Streaming Controls
Play
- Briey press the PLAY/PAUSE/STOP Button.
Pause
- While playing music, briey press the PLAY/PAUSE/STOP button.
Stop
- While playing music, press and hold the PLAY/PAUSE/STOP button for 1
second.
Next song
- Briey press the FAST FORWARD button.
Previous song
- Briey press the REWIND button.
Fast Forward
- Press and hold the FAST FORWARD button.
Rewind
- Press and hold the REWIND button.
9
ENG
Volume Control
- Press the VOLUME UP or VOLUME DOWN button to adjust the speaker volume.
- There are eight levels of speaker volume in Hands-Free mode.
- There are eight levels of speaker volume in Audio Streaming mode.
aptX®
- The HBS-800 features aptX®technology that ensures audio content transmitted
over Bluetooth is instant and crystal-clear.
- aptX®is automatically enabled as long as the source device supports it.
Calling
Answering a Call
- When there is an incoming call, the headset will ring and vibrate.
- Briey press the VOLUME DOWN button to stop vibration.
- Briey press the CALL button to answer the incoming call.
Transferring a Call
- If you make a call from the phone, the call will (depending on the phone settings)
automatically transfer to the headset. If the call is not automatically transferred, you can
manually transfer the call to, or from, the headset by pressing and holding VOLUME
UP button for 3 seconds on the HBS-800 (phone and headset must be paired).
Voice Dialing
- Briey press the CALL button to activate “Voice Command”. For best results,
record the voice dialing tag through your headset.
Note: If your phone does not support voice dialing, this action may activate Last
Number Redial.
Last Number Redial
- Press and hold the CALL button for 1 second to activate “Last Number Redial”.
The headset will beep and then call the last number dialed.
Equalizer
- While playing music, press and hold the VOLUME UP and VOLUME
DOWN buttons at the same time for 1 second to switch between EQ’s (Bass
Boost(Default) gNormal gTreble Boost).
- The bass coming from the speakers can vary as a result of the size of the earbud
that is being used.
How to Use
10
ENG
Ending a Call
- Briey press the CALL button.
Call Waiting
- Answer a second call without hanging up the rst call by pressing and holding the
CALL button for 1 second. Press and hold the CALL button for 1 second to return
to the original call.
- Briey press the CALL button to terminate both calls at once.
Rejecting a Call
- Activate call reject by pressing and holding the CALL button for 1 second when
the phone rings.
* These functions may only be used if your phone supports them. For further
information about using these features, please consult your phone’s user manual.
Mic Mute
- Press and hold the VOLUME UP and VOLUME DOWN buttons at the same time
for 1 second to mute/unmute the mic during conversation.
SMS Reader
The HBS-800 Bluetooth headset supports SMS reading on Android TM based devices.
Search the Google Play™ Store for the LG ‘BT Reader’ application and install it on
your device to use this function.
* The QR code shown below helps you download the LG ‘BT Reader’ application
from the Google Play™ Store. Google Play is a trademark of Google, Inc.
How to Use
Altri manuali per HBS-800
3
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali LG Cuffia
LG
LG TONE Free TONE-DFP5 Manuale utente
LG
LG TONE-FP9 Manuale utente
LG
LG TONE Free TONE-DFP9W Manuale utente
LG
LG BLUETOOTH HBS-250 Manuale utente
LG
LG Tone Infinim HBS900 Manuale utente
LG
LG TONE PLATINUM HBS-1100 Manuale utente
LG
LG Tone Free HBS-FN7 Manuale utente
LG
LG HBM-585 Manuale utente
LG
LG TONE Free HBS-FN5U Manuale utente
LG
LG TONE PRO HBS-770 Manuale utente
LG
LG HBS-800 Manuale utente
LG
LG HBM-730 Manuale utente
LG
LG TONE Free TONE-T90Q Manuale utente
LG
LG HBM-550 Manuale utente
LG
LG Tone Free Fit TONE-DTF7Q Manuale utente
LG
LG HBM-580 Manuale utente
LG
LG TONE-FP9 Manuale utente
LG
LG HBS-700 Manuale utente
LG
LG TONE FREE Manuale utente
LG
LG TONE INFINIM HBS-920 Manuale utente
