LG MT46 Series Manuale utente
www.lg.com
MT45*
MT46*
Please read this manual carefully before operating your TV
and retain it for future reference.
* LG LED TV applies LCD screen with LED backlights.
OWNER’S MANUAL
LED TV
ENGLISH
2TABLE OF CONTENTS
WARNING
yIf you ignore the warning message, you
may be seriously injured or there is a
possibility of accident or death.
CAUTION
yIf you ignore the caution message, you
may be slightly injured or the product may
be damaged.
NOTE
yThe note helps you understand and use
the product safely. Please read the note
carefully before using the product.
TABLE OF CONTENTS
3 LICENSES
3 OPEN SOURCE SOFTWARE
NOTICE
4 ASSEMBLING AND PREPARING
4 Unpacking
6 Part and buttons
6 - Using the Joystick button
9 Lifting and moving the TV
10 Setting up the TV
10 - Attaching the Stand
11 - Detaching the Stand
13 Mounting on a table
14 Mounting on a wall
16 Tidying cable
17 MAKING CONNECTIONS
17 Antenna Connection
18 Other Connections
20 - Connecting to a PC
21 REMOTE CONTROL
22 SETTINGS
26 TO SEE WEB MANUAL
27 MAINTENANCE
27 Cleaning your TV
27 - Screen, frame, cabinet and stand
27 - Power cord
27 Preventing “Image burn” or “Burn-in” on
your TV screen
28 TROUBLESHOOTING
29 SPECIFICATIONS
ENGLISH
3
LICENSES / OPEN SOURCE SOFTWARE NOTICE
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC,
a subsidiary of Rovi Corporation. This is an official DivX Certified® device
that has passed rigorous testing to verify that it plays DivX video. Visit divx.
com for more information and software tools to convert your files into DivX
video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must
be registered in order to play purchased DivX Video-on-Demand (VOD)
movies. To obtain your registration code, locate the DivX VOD section in
your device setup menu. Go to vod.divx.com for more information on how to
complete your registration.
“DivX Certified® to play DivX® video up to HD 1080p, including premium
content.”
“DivX®, DivX Certified® and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used under license.”
“Covered by one or more of the following U.S. patents :
7,295,673; 7,460,668; 7,515,710; 7,519,274”
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in
this product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices
are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of media, shipping and handling) upon email request to
product.
ENGLISH
4ASSEMBLING AND PREPARING
NOTE
yImage shown may differ from your TV.
yYour TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
yThe available menus and options may differ from the input source or product model that you
are using.
yNew features may be added to this TV in the future.
yThe TV can be placed in standby mode in order to reduce the power consumption. And the
TV should be turned off if it will not be watched for some time, as this will reduce energy
consumption.
yThe energy consumed during use can be significantly reduced if the level of brightness of the
picture is reduced, and this will reduce the overall running cost.
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
CAUTION
yDo not use any unapproved items to ensure the safety and product life span.
yAny damage or injuries caused by using unapproved items are not covered by the warranty.
ySome models have a thin film attached on to the screen and this must not be removed.
NOTE
yThe items supplied with your product may vary depending on the model.
yProduct specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
yFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm
thick and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB
memory stick does not fit into your TV’s USB port.
A
B
A
B
*A
<
10 mm
*B
<
18 mm
ENGLISH
5
ASSEMBLING AND PREPARING
Remote control /
batteries (AAA)
(See p.21)
CD (Owner’s Manual) /
Cards
Stand Base
(Only 22MT45*)
(See p.10, 11)
Stand Base
(Only 24MT46*)
(See p.10, 12)
Power Cord
(Depending on model)
(See p.13)
AC-DC Adapter
(Depending on model)
(See p.13)
Stand Body
(Only 24MT46*)
(See p.10, 12)
Cable Holder
(Only 24MT46*)
(See p.16)
ENGLISH
6ASSEMBLING AND PREPARING
Part and buttons
Using the Joystick button
You can simply operate the TV functions, by pressing to turn ON/OFF or sliding your finger over
joystick button moving up, down, left or right.
Basic Functions
Power On When the TV is turned off, place your finger on the joystick
button and press it once and release it.
Power Off
When the TV is turned on, place your finger on the joystick
button and press it once for a few seconds and release it.
(However, if the Menu button is on the screen, pressing and
holding the joystick button will let you exit the Menu.)
Volume
Control
If you place your finger over the joystick button and move it left
or right, you can adjust the volume level you want.
Programmes
Control
If you place your finger over the joystick button and move it up
or down, you can scrolls through the saved programmes you
want.
NOTE
yYou can set the power indicator light to on or off by selecting OPTION in the main menus.
Screen
Speakers
Joystick button
(* This button is located below the TV
screen.)
Remote control sensor
Power Indicator
yRed : When the power is turned off
yOff : When the power is turned on
yAmber : When the power is in power saving mode
(Only 22MT45*)
ENGLISH
7
ASSEMBLING AND PREPARING
NOTE
yWhen your finger is over the joystick button and you are sliding finger forward/back ,left or right,
be careful not to press down to hard on joystick. If you press down hard on joystick button first
then the adjustment of Volume level and program scroll action will not operate.
Adjusting the Menu
When the TV is turned on, press the joystick button one time.
You can adjust the Menu items ( ) moving the joystick button up, down, left or right.
TV off Turns the power off.
Settings Accesses the main menu.
Close Clears on-screen displays and returns to TV viewing.
Input List Changes the input source.
ENGLISH
8ASSEMBLING AND PREPARING
(Only 24MT46*)
Remote control sensor
Power Indicator
yRed : When the power is turned off
yOff : When the power is turned on
yAmber : When the power is in power
saving mode
Screen
Touch buttons
Speakers
NOTE
yAll of the buttons are touch sensitive and can be operated through simple touch with your
finger.
yYou can set the power indicator light to on or off by selecting OPTION in the main menus.
Touch button Description
Scrolls through the saved programmes.
Adjusts the volume level.
OK Selects the highlighted menu option or confirms an input.
SETTINGS Accesses the main menus, or saves your input and exits the menus.
INPUT Changes the input source.
Turns the power on or off.
ENGLISH
9
ASSEMBLING AND PREPARING
Lifting and moving the TV
Please note the following advice to prevent the
TV from being scratched or damaged and for
safe transportation regardless of its type and
size.
CAUTION
yAvoid touching the screen at all times, as
this may result in damage to the screen.
yIt is recommended to move the TV in the
box or packing material that the TV originally
came in.
yBefore moving or lifting the TV, disconnect
the power cord and all cables.
yWhen holding the TV, the screen should face
away from you to avoid damage.
yHold the top and bottom of the TV frame
rmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
yWhen transporting the TV, do not expose the
TV to jolts or excessive vibration.
yWhen transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.
yDo not apply excessive pressure to cause
exing /bending of frame chassis as it may
damage screen.
CAUTION
yWhen handling the TV, be careful not to
damage the protruding joystick button.
(Depending on model)
ENGLISH
10 ASSEMBLING AND PREPARING
Setting up the TV
Image shown may differ from your TV.
Attaching the Stand
1
2
Stand Base
CAUTION
yWhen attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
(Only 22MT45*)
(Only 24MT46*)
1
Stand Base
Stand Body
or
2
3
