LG 43UN672M0UB Guida rapida

www.lg.com

LED TV

43UN672M0UB

50UN672M0UB

55UN672M0UB

ENGLISH Easy Setup Guide

Please read this manual carefully before operating your set and retain it for future reference.

ESPAÑOL Guía Rápida de Configuración

Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.

FRANÇAIS Guide de configuration rapide

Avant d’utiliser l’appareil, veuillez lire attentivement ce manuel et le conserver pour pouvoir vous y reporter

ultérieurement.

Depending upon model / Según el modelo / Selon le modèle

Printed in Korea / Imprimé en Corée

ENGLISH Read Safety and Reference.

WARNING : To prevent injury, this apparatus must be securely attached to the desk/wall in accordance with the Safety and Reference.

ESPAÑOL Leer Seguridad y Consultas.

ADVERTENCIA : Para prevenir daños, este aparato debe ser instalado a la mesa/pared de acuerdo a la guía de Seguridad y Consultas.

FRANÇAIS Lisez Sécurité et références.

AVERTISSEMENT : Pour éviter les blessures, cet appareil doit être solidement xé au bureau ou au mur, conformément aux directives du

manuel Sécurité et références.

TV-LINK CFG

M.P.I.

TV-LINK CFG

M.P.I.

43UN672M0UB 967

(38.0)

967

(38,0)

564

(22.2)

564

(22,2)

57.1

(2.2)

57,1

(2,2)

8.8

(19.4)

8,8

(19,4) 110 W

50UN672M0UB 1,121

(44.1)

1 121

(44,1)

651

(25.6)

651

(25,6)

57.1

(2.2)

57,1

(2,2)

11.7

(25.7)

11,7

(25,7) 130 W

55UN672M0UB 1,235

(48.6)

1 235

(48,6)

715

(28.1)

715

(28,1)

57.5

(2.2)

57,5

(2,2)

14.0

(30.8)

14,0

(30,8) 160 W

AC 120 V~ 50 / 60 Hz

*MFL71998402*

(2303-REV00)

*MFL71998702*

(2303-REV00)

OWNER’S MANUAL

Safety and Reference

LED TV*

43UN672M0UB

50UN672M0UB

55UN672M0UB

www.lg.com

Printed in Korea

* LG LED TV applies LCD screen with LED backlights.

Please read this manual carefully before operating your set and retain it for future

reference.

ENGLISH

TABLE OF CONTENTS

Important Safety Instruction

Warning! Safety instructions

Preparing

Optional Extras

8 Wall Mounting Bracket

Lifting and Moving the TV

9 Using the Kensington Security System (optional)

Securing TV to the Wall

Mounting on a Wall

Connections

11 Antenna/Cable

12 Other connections

13 Network setup

Using the Button

Troubleshooting

Settings

16 Selecting Picture Mode

16 Adjusting the Brightness of a Picture

16 Using Energy Saving Feature

Specifications

18 HDMI-DTV supported mode

18 HDMI-PC supported Mode

19 Supported Photo Formats

19 Supported Audio Formats

20 Supported Video Formats

20 Cautions forVideo Playback

20 Supported External Subtitles

External Control Device Setup

21 RS-232C Setup

21 Phone jack Type

21 Type of Connector: D-Sub 9-Pin Male

22 RS-232C Configurations

22 Communication Parameters

22 Set ID

23 Command Reference List

24 Transmission / Receiving Protocol

IR OUT Using Guide

32 Suitable / Not Recommend remote-controller data

format

32 IR Receiver specifications

Open Source Software Notice

Information

Updating Firmware
