MICROWAVE/GRILL OVEN

OWNER’S MANUAL

PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING.

MG-7243J

P/No: MFL38195701

You cannot operate your oven with the door open due to the safety interlocks

built into the door mechanism. These safety interlocks automatically switch off

any cooking activity when the door is opened; which in the case of a

microwave oven could result in harmful exposure to microwave energy.

It is important not to tamper with the safety interlocks.

Do not place any object between the oven front face and the door or allow

food or cleaner residue to accumulate on sealing surfaces.

Do not operate your oven if it is damaged. It is particularly important that the

oven door closes properly and that there is no damage to the: (1) door(bent),

(2) hinges and latches (broken or loosened), (3) door seals and sealing

surfaces.

Your oven should not be adjusted or repaired by anyone except qualified

service personnel.

WARNING

Precautions to avoid possible exposure to excessive microwave energy.

Precautions

When heating liquids, e.g. soups, sauces and beverages in your microwave

oven, overheating the liquid beyond boiling point can occur without

evidence of bubbling. This could result in a sudden boil over of the hot

liquid. To prevent this possibility the following steps should be taken:

1 Avoid using straight sided containers with narrow necks.

2 Do not overheat.

3 Stir the liquid before placing the container in the oven and again halfway

through the heating time.

4 After heating, allow to stand in the oven for a short time, stir or shake

them again carefully and check the temperature of them before

consumption to avoid burns (especially, contents of feeding bottles and

baby food jars).

Be careful when handling the container.

WARNING

Always allow food to stand after being cooked by

microwaves and check the temperature of them

before consumption. Especially contents of feeding

bottles and baby food jars.

Please ensure cooking times are correctly set as

over cooking may result in the FOOD catching fire

and subsequent damage to your oven.

How the Microwave Oven Works

Microwaves are a form of energy similar to radio and television waves and

ordinary daylight. Normally, microwaves spread outwards as they travel

through the atmosphere and disappear without effect. Microwave ovens,

however, have a magnetron which is designed to make use of the energy in

microwaves. Electricity, supplied to the magnetron tube, is used to created

microwave energy.

These microwaves enter the cooking area through openings inside the oven.

A turntable or tray is located at the bottom of the oven. Microwaves cannot

pass through metal walls of the oven, but they can penetrate such materials

as glass, porcelain and paper, the materials out of which microwave-safe

cooking dishes are constructed.

Microwaves do not heat cookware, though cooking vessels will eventually get

hot from the heat generated by the food.

A very safe appliance

Contents

Your microwave oven is one of the safest of all home

appliances. When the door is opened, the oven

automatically stops producing microwaves. Microwave

energy is converted completely to heat when it enters

food, leaving no “left over” energy to harm you when

you eat your food.

Precautions_____________________________________________2

Contents _______________________________________________3

Unpacking & Installing ___________________________________4 ~ 5

Setting the Clock ________________________________________6

Setting the Scroll Speed __________________________________7

Child Lock _____________________________________________8

Micro Power Cooking ____________________________________9

Micro Power Level _______________________________________10

Two Stage Cooking______________________________________11

Quick Start_____________________________________________12

Grill Cooking___________________________________________13

Combination Cooking____________________________________14

Auto Defrost____________________________________________15 ~ 16

Quick Defrost___________________________________________17 ~ 18

Auto Cook _____________________________________________19 ~ 21

Auto Reheat ____________________________________________22 ~ 23

Auto Roast _____________________________________________24 ~ 25

More or Less Cooking____________________________________26

Timer _________________________________________________27

Important Safety Instructions ______________________________28 ~ 29

Microwave - safe Utensils_________________________________30

Food characteristics & Microwave cooking __________________31 ~ 32

Questions & Answers ____________________________________33

Plug Wiring Information/Technical Specifications _____________34

Place the oven in the level location of your choice with

more than 85cm height but make sure there is at least

20cm of space on the top and 10cm at the rear for proper

ventilation. The front of the oven should be at least 8cm from the

edge of the surface to prevent tipping.

An exhaust outlet is located on top or side of the oven. Blocking the

outlet can damage the oven.

Unpacking &

Installing

Unpack your oven and place it on a flat level

surface.

By following the basic steps on these two pages you will be able to quickly check that your oven is operating

correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your

oven make sure you remove all accessories and packing. Check to make sure that your oven has not been

damaged during delivery.

THIS OVEN SHOULD NOT BE USED FOR COMMERCIAL CATERING

PURPOSES

GLASS TRAY

ROTATING RING

HIGH RACK LOW RACK

The DISPLAY will count down from 30 seconds. When it

reaches 0 it will sound BEEPS. Open the oven door and

test the temperature of the water. If your oven is operating the water

should be warm. Be careful when removing the container it may

be hot.

YOUR OVEN IS NOW INSTALLED

Fill a microwave safe container with 300 ml (1/2 pint)

of water. Place on the GLASS TRAY and close the oven

door. If you have any doubts about what type of container to

use please refer to page 30.

Open your oven door by pulling the DOOR HANDLE.

Place the ROTATING RING inside the oven and place

the GLASS TRAY on top.

Plug your oven into a standard household socket. Make

sure your oven is the only appliance connected to the

socket. If your oven does not operate properly, unplug it

from the electrical socket and then plug it back in.

The contents of feeding bottles and baby food jars shall

be stirred or shaken and the temperature checked

before consumption, in order to avoid burns.

Press the Stop/Clear button, and press the

Start/Q-start button one time to set 30

seconds of cooking time.

Setting the

Clock You can set either12 hour clock or 24 hour clock.

In the following example I will show you how to set the time for 14:35 when using the 24 clock.

Make sure that you have removed all packaging from your oven.

When your oven is plugged in for the

first time or when power resumes after a

power cut, a ‘ : ’ will be shown in the

display; you will have to reset the clock.

If the clock (or display) shows any

strange looking symbols, unplug your

oven from the electrical socket and plug

it back in and reset the clock.

Make sure that you have correctly installed your oven as described earlier

in this book.

Press Stop/Clear.

Press Setting once.

Press More( ) or Less( ) once to select clock setting and then press

Setting to confirm.

(If you want to use a 24 hour clock, Press More( ) or Less( ).

If you want to change different option after setting clock,

you have to unplug and plug it back in.)

Press 10min fourteen times.

Press 1min three times and press 10sec five times.

If the key (10 MIN / 1 MIN / 10 SEC) is pressed and held, the time will

increase rapidly.

Press Setting.

The clock starts counting.

Setting the

Scroll Speed

Press Setting once.

Press More( ) or Less( ) two times to select scroll speed setting and

then press Setting to confirm.

Press More( ) or Less( ) until display shows “SLOW”.

Press Setting.

When your oven is plugged in for the

first time or when power resumes after a

power cut, a ‘ : ’ will be shown in the

display; you will have to reset the scroll

speed.

If display shows any strange looking

symbols, unplug your oven from the

electrical socket and plug it back in and

reset the scroll speed.

Make sure that you have correctly installed your oven as described earlier

in this book.

Press Stop/Clear.

You can set scroll speed.

In the following example I will show you how to set Slow scroll speed.

Make sure that you have removed all packaging from your oven.

Child

Lock

Press and hold Stop/Clear until “CHILD LOCKED” appears on the display

and BEEP sounds.

The CHILD LOCK is now set.

To cancel CHILD LOCK press and hold Stop/Clear until “CHILD LOCKED”

disappears.

You will hear BEEP when it’s released.

Your oven has a safety feature that

prevents accidental running of the oven.

Once the child lock is set, you will be

unable to use any functions and no

cooking can take place.

However your child can still open the

oven door.

Press Stop/Clear.

Micro Power

Cooking

Make sure that you have correctly installed your oven as described earlier

in this book.

Press Stop/Clear.

Press Micro twice to select 720W (80%) power.

“720W” appears on the display.

Press 1min five times.

Press 10sec three times.

Press Start.

Your oven has five microwave Power

settings. High power is automatically

selected but repeated presses of the

MICRO key will select a different power

level.

In the following example I will show you how to cook some food on 720W (80%) power for 5 minutes and

30 seconds.

POWER

HIGH

MAX

MEDIUM

HIGH

MEDIUM

DEFROST

MEDIUM LOW

LOW

Power Output

100%

80%

60%

40%

20%

900W

720W

540W

360W( )

180W

Micro Power

Level Your microwave oven is equipped with 5 power levels to give you maximum flexibility and control over cooking.

The table below shows the examples of food and their recommended cooking power levels for use with this

microwave oven.

POWER LEVEL POWER LEVEL (%)

HIGH * Boil Water

* Brown minced beef

* Cook poultry pieces, fish, vegetables

* Cook tender cuts of meat

MEDIUM HIGH * Reheating(Liquid)

* Roast meat and poultry

* Cook mushrooms and shellfish

* Cook foods containing cheese and eggs

MEDIUM * Reheating(Mashed potato, Plated meal, Ready meal)

* Prepare eggs

* Cook custard

* Prepare rice, soup

DEFROST/ * All thawing

MEDIUM LOW * Melt butter and chocolate

* Cook less tender cuts of meat

LOW * Soften butter & cheese

* Soften ice cream

* Raise yeast dough

USE POWER OUTPUT

100%

80%

60%

40%

20%

900W

720W

540W

360W( )

180W

Indice

Manuali Forno a microonde popolari di altre marche

Daewoo

Daewoo KOG-574R0S Manuale utente

Sharp

Sharp R-895(AL)M Manuale utente

Dometic

Dometic DOTRM13W Manuale utente

Sanyo

Sanyo EM-X680 Manuale utente

Sharp

Sharp R-393M Manuale utente

KitchenAid

KitchenAid KMCX4510 Istruzioni per l'installazione

Smeg

Smeg S45MCX1 Manuale utente

Russell Hobbs

Russell Hobbs RHM2044 Manuale utente

Sunbeam

Sunbeam SMW759 Manuale utente

Gallet

Gallet FMOE230S Manuale utente

Bosch

Bosch CEG732X.1B Manuale utente

Dometic

Dometic Roadmate 230 Manuale utente

Samsung

Samsung SJ0396W Manuale utente

Sanyo

Sanyo EM-P494WS Manuale utente

Sharp

Sharp R-240 Manuale utente

Electrolux

Electrolux EMS2840 Manuale utente

Daewoo

Daewoo KOC-984T2S13 Manuale utente

Impecca

Impecca CM07M2 Manuale utente
