LG 20MP38A Manuale utente

www.lg.com

IPS LED MONITOR MODEL

Please read this manual carefully before operating

your set and retain it for future reference.

Owner's Manual

IPS LED MONITOR

(LED MONITOR*)

*LG LED Monitors are LCD Monitors with LED Backlighting.

20MP38A

20MP38H

20MP38HQ

22MP48A

22MP48D

22MP48HQ

23MP48D

23MP48HQ

20MP48A 24MP48HQ 27MP48HQ

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 LICENSE

4 ASSEMBLINGANDPREPAR-

ING

4 Unpacking

6 Partsandbuttons

7 Partsandbuttons

8 Partsandbuttons

9 MovingandLiftingtheMonitor

10 SettinguptheMonitorset

10 - AttachingtheStandBase

11 - Mountingonatable

12 - Usingthecableholder

15 - Mountingonawall

16 USINGTHEMONITORSET

16 ConnectingtoaPC

16 - D-SUBconnection

16 - DVI-Dconnection

17 - HDMIconnection

17 ConnectingtoAVDevices

17 - HDMIconnection

18 ConnectingtoExternalDevices

18 - Peripheraldeviceconnection

19 CUSTOMIZINGSETTINGS

21 CustomizingSettings

21 - MenuSettings

23 -Picture

24 -Color

25 -Display

25 -Audio

26 -Others

27 READERSetting

28 FUNC.Setting

28 -SMARTENERGYSAVING

29 -PictureMode

30 -ColorWeakness

31 TROUBLESHOOTING

33 SPECIFICATIONS

43 FactorySupportMode

(PresetMode,D-SUB/DVI/HDMIPC)

44 HDMITiming(Video)

44 Indicator

ENG

ENGLISH

LICENSE

Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

ThefollowingcontentisonlyappliedtothemonitorwhichissoldinEuropemarketandwhichneedsto

meettheErPDirective:

*Thismonitorissettobeturnedoffautomaticallyin4hoursafteryouturnedondisplayifthereisnoadjust-

menttodisplay.

*Tomakethissettingbedisabled,changetheoptionto‘Off’inOSDmenuof“AutomaticStandby”.

20MP38H 20MP38HQ 22MP48HQ 23MP48HQ 24MP48HQ 27MP48HQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

CD(Owner'sManual)/

Card

(Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter

AC-DCAdapter

or

D-SUBCable

(Thiscableisnotincludedinall

countries.)

HDMICable

StandBody StandBase

(Thiscableisnotincludedinall

countries.)

DVI-DCable

(Thiscableisnotincludedinall

countries.)

StandBody StandBody

StandBase StandBase

Cableholder

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

ENG

ENGLISH

ASSEMBLING AND PREPARING

HDMI IN

READER

Partsandbuttons

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Connectionpanel(Seep.16~18)

Button(Seep.19~20)

(PowerButton)

 Thebuttonislocatedatthebottomofthemonitor.

NOTE

22MP48A

22MP48D

22MP48HQ

23MP48D

23MP48HQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Button(Seep.19~20)

(PowerButton)

Partsandbuttons

Connectionpanel(Seep.16~18)

 Thebuttonislocatedatthebottomofthemonitor.

NOTE

20MP48A 24MP48HQ 27MP48HQ

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

20MP38A 20MP38H 20MP38HQ

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

(PowerButton)

Button(Seep.19~20)

Connectionpanel(Seep.16~18)

ENG

ENGLISH

ASSEMBLING AND PREPARING

MovingandLiftingtheMonitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.

 Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.

 Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.

 Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.

 Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.

 Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.



 Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.

 Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

AttachtheStandBodytothemonitorset.

AttachtheStandBase.

Tightenthescrewtotherightwithacoin.

SettinguptheMonitorset

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION

2

StandBase

StandBody

22MP48A

22MP48D

22MP48HQ

23MP48D

23MP48HQ

20MP38A 20MP38HQ20MP38H

StandBase

StandBody

StandBase

StandBody

InserttheCableHolder.

AttachtheStandBodytothemonitorset.

AttachtheStandBasetoStandBody.

Tightenthescrewtotheright.

 Youcandisassemblethestandinthe

reverseorderoftheassembly.

NOTE
