LG Flatron L1922P Manuale utente
Make sure to read the Important Precautions before using the product.
Keep the User's Guide(CD) in an accessible place for furture reference.
See the label attached on the back cover and quote this information to your
dealer when you require service.
L1922P
User’s Guide
A1
Important Precautions
This unit has been engineered and manufactured to ensure your personal
safety, however improper use may result in potential eletrical shock or fire
hazards. In order to allow the proper operation of all safeguards
incorporated in this display, observe the following basic rules for its
installation, use, and servicing.
On Safety
Use only the power cord supplied with the unit. In case you use another power
cord, make sure that it is certified by the applicable national standards if not being
provided by the supplier. If the power cable is faulty in any way, please contact the
manufacturer or the nearest authorized repair service provider for a replacement.
The power supply cord is used as the main disconnection device. Ensure that the
socket-outlet is easily accessible after installation.
Operate the display only from a power source indicated in the specifications of
this manual or listed on the display. If you are not sure what type of power supply
you have in your home, consult with your dealer.
Overloaded AC outlets and extension cords are dangerous. So are frayed power
cords and broken plugs. They may result in a shock or fire hazard. Call your service
technician for replacement.
Do not Open the Display.
There are no user serviceable components inside.
There are Dangerous High Voltages inside, even when the power is OFF.
Contact your dealer if the display is not operating properly.
To Avoid Personal Injury :
Do not place the display on a sloping shelf unless properly secured.
Use only a stand recommended by the manufacturer.
To Prevent Fire or Hazards:
Always turn the display OFF if you leave the room for more than a short period
of time. Never leave the display ON when leaving the house.
Keep children from dropping or pushing objects into the display's cabinet
openings. Some internal parts carry hazardous voltages.
Do not add accessories that have not been designed for this display.
During a lightning storm or when the display is to be left unattended for an
extended period of time, unplug it from the wall outlet.
A2
Important Precautions
On Installation
Do not allow anything to rest upon or roll over the power cord, and do not place
the display where the power cord is subject to damage.
Do not use this display near water such as near a bathtub, washbowl, kitchen
sink, laundry tub, in a wet basement, or near a swimming pool.
Displays are provided with ventilation openings in the cabinet to allow the release
of heat generated during operation. If these openings are blocked, built-up heat
can cause failures which may result in a fire hazard. Therefore, NEVER:
Block the bottom ventilation slots by placing the display on a bed, sofa, rug, etc.
Place the display in a built-in enclosure unless proper ventilation is provided.
Cover the openings with cloth or other material.
Place the display near or over a radiator or heat source.
Do not rub or strike the Active Matrix LCD with anything hard as this may scratch,
mar, or damage the Active Matrix LCD permanently.
Do not press the LCD screen with your finger for a long time as this may cause
some afterimages.
Some dot defects may appear as Red, Green or Blue spots on the screen.
However, this will have no impact or effect on the display performance.
If possible, use the recommended resolution to obtain the best image quality for
your LCD display. If used under any mode except the recommended resolution,
some scaled or processed images may appear on the screen. However, this is
characteristic of the fixed-resolution LCD panel.
On Cleaning
Unplug the display before cleaning the face of the display screen.
Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display
screen because over-spraying may cause electrical shock.
On Repacking
Do not throw away the carton and packing materials. They make an ideal
container in which to transport the unit. When shipping the unit to another
location, repack it in its original material.
On Disposal
The fluorescent lamp used in this product contains a small amount of mercury.
Do not dispose of this product with general household waste.
Disposal of this product must be carried out in accordance to the regulations of
your local authority.
A3
Connecting the Display
Using the Computer
1. Separate the back cap by sliding its
lower section downward as shown
in the picture.
3. After the cables are connected, set the
back cap into the groove of the upper
section and reassemble by pushing
upward.
4. Insert the back cap along the bottom
grooves on both sides, holding the
bottom.
2. Connect the signal input cable and the power cord. (see next page)
A4
Connecting the Display
Using the Computer
1. Connect the signal cable. When attached, tighten the thumbscrews to secure
the connection.
2. Connect the power cord into a proper power outlet that is easily accessible and
close to the display.
Mac adapter
For Apple Macintosh use, a separate plug adapter is needed
to change the 15 pin high density (3 row) D-sub VGA
connector on the supplied cable to a 15 pin 2 row connector.
PC
MAC
Wall-outlet type
*
PC-outlet type
*
Power Cord Signal Cable
Analog signal
2
1
Digital signal
3. Press button on the front switch panel to turn the power on.
When monitor power is turned on, the 'Self Image Setting Function' is
executed automatically.
NOTE
‘ Self Image Setting Function’? This function provides the user with optimal display settings.When the user
connects the monitor for the first time, this function automatically adjusts the display to optimal settings for
individual input signals. If you want to adjust the monitor while in use, or wish to manually run this function once
again, push the ‘AUTO’ button on the front panel of the monitor. Otherwise, you may execute the ‘ Factory reset’
option on the OSD adjustment menu. However, be aware that this option initializes all the menu items except
‘Language’.
NOTE
This is a simplified representation of the rear view.
This rear view represents a general model; your display may differ from the view as shown.
PROCESSING SELF
IMAGE SETTING
A5A5
Control Panel Functions
Front Panel Controls
Buttons
Use these buttons to choose or adjust items in
the On Screen Display.
MENU Button
Use this button to enter or exit the On Screen
Display.
Use this button to turn the display on or off.
This Indicator lights up blue when the display
operates normally. If the display is in DPM (Energy
Saving) mode, this indicator color changes to amber.
Power Button
Power (DPMS)
Indicator
Use this button to enter a selection in the On Screen
Display.
AUTO/SELECT
Button
Control Function
A6
Control Panel Functions
Use this button to make Dsub or DVI connector active.
This feature is used when two computers are connected
to the display. The default setting is Dsub.
SOURCE
FLATRON F-ENGINE
NORMAL
MENU
USER
OSD LOCKED
OSD UNLOCKED
PROCESSING AUTO
IMAGE ADJUSTMENT
This function allows you to secure the current control
settings, so that they cannot be inadvertently changed.
Press and hold the MENU button for 5 seconds: the
message “OSD LOCKED” appears.
You can unlock the OSD controls at any time by pushing
the MENU button for 5 seconds:
the message “OSD UNLOCKED” will appear.
OSD LOCKED/UNLOCKED
:
MENU
Control Direct Access Function
AUTO IMAGE ADJUSTMENT
Bring up Contrast and Brightness adjustment.
:
MENU
BRIGHTNESS
50
50
0
When adjusting your display settings, always press the
AUTO/SELECT button before entering the On Screen
Display(OSD).
This will automatically adjust your display image to the
ideal settings for the current screen resolution size
(display mode).
The best display mode is 1280x1024.
For more information, refer to page A12
A7
On Screen Display (OSD) Control Adjustment
Screen Adjustment
Making adjustments to the image size, position and operating parameters of
the display is quick and easy with the On Screen Display Control system. A
short example is given below to familiarize you with the use of the controls.
The following section is an outline of the available adjustments and selections
you can make using the OSD.
To make adjustments in the On Screen Display, follow these steps:
Press the MENU Button, then the main menu of the OSD appears.
To access a control, use the or Buttons. When the icon you want
becomes highlighted, press the AUTO/ SELECT Button.
Use the Buttons to adjust the item to the desired level.
Accept the changes by pressing the AUTO/ SELECT Button.
Exit the OSD by Pressing the MENU Button.
NOTE
Allow the display to stabilize for at least 30 minutes before making image adjustments.
A8
NOTE
The order of icons may differ depending on the model (A8~A12).
On Screen Display(OSD) Selection and Adjustment
To adjust the brightness, contrast
and gamma of the screen
COLOR
POSITION
TRACKING
FACTORY
RESET
SETUP
Main menu Sub menu A D Reference
The following table indicates all the On Screen Display control, adjustment,
and setting menus.
PRESET
RED
GREEN
BLUE
To adjust the position of the
screen
To restore the default settings
To customize the color of the
screen
To customize the screen status
for a user's operating environment
To select or customize desired
image settings
To improve the clarity and
stability of the screen
BRIGHTNESS
CONTRAST
GAMMA
H POSITION
V POSITION
CLOCK
PHASE
FACTORY RESET
WHITE BALANCE
LANGUAGE
OSD H POSITION
OSD V POSITION
FLATRON
F-ENGINE(
-
)
TEXT/ MOVIE
USER
NORMAL
: Adjustable
A : Analog Input
D : Digital Input
A9
On Screen Display(OSD) Selection and Adjustment
You were introduced to the procedure of selecting and adjusting an item
using the OSD system. Listed below are the icons, icon names, and icon
descriptions of the all items shown on the Menu.
Press the MENU Button, then the main menu of the OSD appears.
Menu Name
Icons
Sub-menus
50
50
0
MENU
NOTE
OSD (On Screen Display) menu languages on the monitor may differ from the manual.
MENU : Exit
Button Tip
