OWNER’S MANUAL

MONITOR TV

MONITOR TV MODELS

M197WDP

M227WDP

M237WDP

Please read this manual carefully before operating

your set and retain it for future reference.

ENGLISH

PREPARATION

FRONT PANEL CONTROLS

■

This is a simp ified representation of the front pane . The image shown may be somewhat different from your set.

INPUT MENU VOL PROK

PROGRAMME

Buttons

VOLUME

Buttons

Button

INPUT

Button

Power

Button

Headphone

Jack

PREPARATION

BACK PANEL INFORMATION

■

This is a simp ified representation of the back pane . The image shown may be somewhat different from your set.

AV 1 AV 2

AC IN

AUDIO IN

(RGB/DVI) OPTICAL

DIGITAL

AUDIO OUT

VIDEO

COMPONENT

AUDIO

RS-232C IN

(CONTROL & SERVICE)

USB IN

RGB IN (PC)

DVI-D (PC)

HDMI IN

AV 1

V 1

AV 2

V 2

AC IN

ANTENNA/

CABLE IN

910

87 1211

64 5

PPCCMMCCIIAA ((PPeerrssoonnaa CCoommppuutteerr MMeemmoorryy CCaarrdd

IInntteerrnnaattiioonnaa AAssssoocciiaattiioonn)) CCaarrdd SSoott

This feature is not avai ab e in a countries.

PPoowweerr CCoorrdd SSoocckkeett

This set operates on AC power. The vo tage is indicated

on the Specifications page. Never attempt to operate

the set on DC power.

HHDDMMII IInnppuutt((NNoott SSuuppppoorrtt PPCC))

Connect a HDMI signa to HDMI IN.

Or DVI (VIDEO) signa to HDMI IN with DVI to HDMI

cab e.

RRGGBB//DDVVII AAuuddiioo IInnppuutt

Connect the audio from a PC.

OOppttiiccaa DDiiggiittaa AAuuddiioo OOuutt

Connect digita audio from various types of eguipment.

RRGGBB IINNPPUUTT ((PPCC))

Connect the output from a PC.

UUSSBB IINN

DDVVII--DD IInnppuutt

Connect the output from a PC.

RRSS--223322CC IINN ((CCOONNTTRROOLL && SSEERRVVIICCEE)) PPOORRTT

Connect to the RS-232C port on a PC.

CCoommppoonneenntt IInnppuutt

Connect a component video/audio device to these

jacks.

EEuurroo SSccaarrtt SSoocckkeett ((AAVV11//AAVV22))

Connect scart socket input or output from an externa

device to these jacks.

AAnntteennnnaa IInnppuutt

Connect over-the-air signa s to this jack.

PREPARATION <M237WDP>

AUDIO IN

(RGB/DVI)

OPTICAL

DIGITAL

AUDIO OUT

VIDEO

COMPONENT

AUDIO

RS-232C IN

(CONTROL & SERVICE)

USB IN

RGB IN (PC)

DVI-D (PC)

HDMI IN

AV 1V 1 AV 2V 2

AC IN

ANTENNA/

CABLE IN

910

87 1211

64 5

PPCCMMCCIIAA ((PPeerrssoonnaa CCoommppuutteerr MMeemmoorryy CCaarrdd

IInntteerrnnaattiioonnaa AAssssoocciiaattiioonn)) CCaarrdd SSoott

This feature is not avai ab e in a countries.

PPoowweerr CCoorrdd SSoocckkeett

This set operates on AC power. The vo tage is indicated

on the Specifications page. Never attempt to operate

the set on DC power.

HHDDMMII IInnppuutt((NNoott SSuuppppoorrtt PPCC))

Connect a HDMI signa to HDMI IN.

Or DVI (VIDEO) signa to HDMI IN with DVI to HDMI

cab e.

RRGGBB//DDVVII AAuuddiioo IInnppuutt

Connect the audio from a PC.

OOppttiiccaa DDiiggiittaa AAuuddiioo OOuutt

Connect digita audio from various types of eguipment.

RRGGBB IINNPPUUTT ((PPCC))

Connect the output from a PC.

UUSSBB IINN

DDVVII--DD IInnppuutt

Connect the output from a PC.

RRSS--223322CC IINN ((CCOONNTTRROOLL && SSEERRVVIICCEE)) PPOORRTT

Connect to the RS-232C port on a PC.

CCoommppoonneenntt IInnppuutt

Connect a component video/audio device to these

jacks.

EEuurroo SSccaarrtt SSoocckkeett ((AAVV11//AAVV22))

Connect scart socket input or output from an externa

device to these jacks.

AAnntteennnnaa IInnppuutt

Connect over-the-air signa s to this jack.

BACK PANEL INFORMATION

■

This is a simp ified representation of the back pane . The image shown may be somewhat different from your set.

AV 1 AV 2

AC IN

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a

cushioned surface that wi protect product and

screen from damage.

Insert the ssttaanndd bbaasseeinto the product

Attach the monitor to the Stand Base by turning

the screw to the right.

* Turn the screw by using the screw hand e

Screw

PREPARATION <M237WDP>

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a

cushioned surface that wi protect product and

screen from damage.

Insert the ssttaanndd bbaasseeinto the product

Attach the monitor to the Stand Base by turning

the screw to the right.

* Turn the screw by using the screw hand e

Screw

PREPARATION <M197WDP/M227WDP>

DETACHING STAND

P ace the set screen side down on a cushion or

soft c oth.

Detach the monitor to the Stand Base by turn-

ing the screw to the eft.

Turn the screw by using the screw hand e 4

Pu the stand base.

■

The image shown may be somewhat different from your set.

PREPARATION <M237WDP>

DETACHING STAND

P ace the set screen side down on a cushion or

soft c oth.

Detach the monitor to the Stand Base by turn-

ing the screw to the eft.

Turn the screw by using the screw hand e 4

Pu the stand base.

■

The image shown may be somewhat different from your set.

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper venti ation, a ow a c earance of 10 cm on each side and from the wa .

10 c m

WALL MOUNT: HORIZONTAL INSTALLATION

For proper venti ation, a ow a c earance of 10 cm on each side and from the wa . Detai ed insta ation

instructions are avai ab e from your dea er, see the optiona Ti t Wa Mounting Bracket Insta ation and

Setup Guide.

10 c m

10 cm 10 cm

10 c m
