LG OLED55G2 Series Manuale utente

1. Model Name: OLED55G2PSA

2. Sux: TR

3. Part No: MFL71833935

4. REV REV00

5. Number of pages 16

6. Folded/Unfolded 3 Folded

7. Trim size (W x H)_Unfolded (mm) 296 x 420 (+/-5)

8. Trim size (W x H)_folded (mm) 148 x 105

9. Bindery -

10. Color (Cover) -

11. Paper (Cover) -

12. Weight (cover) (g/㎡) -

13. Color (inner) 4 (CMYK)

14. Paper (inner) Wood free

15. Weight (inner) (g/㎡) 70 (+/-10)

16. Coating No

17. Thomson No

18. Sub-material No

[Country Name]

LGERS/ LGEMX : Mexico

LGEKR: Korea

Changes the Country name. LGEMA: Poland

Printed in [Country Name] LGEIL: India

Others: Each Country name.

[Restriction of Hazardous Substances ]

Hazardous substances on this product should be satised by substance regulation of Level A-I, A-II, SVHC according to LG(52)B—5011 standard.

(1) Hazardous substances test report should be submitted when part certication test and rst mass production.

(2) Especially, Don’t use or contain lead (Pb) and cadmium (Cd) in ink.

REV07

REV06

REV05

REV04

REV03

REV02

REV01

Checked Aditya.K

Approved Nitin.H

Rev. Number Date ECO Number Owner Aditya.K

COVER

INNER

3. History

Description

NOTE Especially, Part should be followed and controlled the following specication.

03/05/2022

Printing Specication

1. Specification 1.1 Folding / Cover

Models

SIZE

REV00

2. Origin Notification

ENG

19. Languages

Barcode

Front Back

Folded Step

Folded

Front

420 mm

296 mm

105 mm

148 mm

OLED55G2*

OLED65G2*

www.lg.com

2 31

Head

washer

Head

washer

Head

washer

*M F L 7 1 8 3 3 9 3 5 2 2 0 3 R E V 0 0*

Quick Start Guide

Unpacking

Images shown in manual may vary depending

on model

Check your product box for the following items.

If there are any missing accessories, contact the

local dealer where you purchased your product.

The illustrations in this manual may differ from

the actual product and item.

: Depending on country : Depending on model

90°

A B C D(mm) E

Wallmount

OLED55G2* 300 x 200

OLED65G2* 300 x 300

AB C DE F G H

(mm) (kg)

OLED55G26LA

OLED55G2PSA 1222 703 27.2 452 129 13 17.1 1.2

OLED65G26LA

OLED65G2PSA 1441 826 24.3 452 129 13 22.8 1.2

Power requirement

The Analog Gender adapter can be purchased separately at Customer Service.

Do not look into the optical

output ports, looking at the

laser beam may damage

your vision

Audio with ACP (Audio Copy

Protection)function may

block digital audio output.

Some USB Hubs may not

work, if a USB device con-

nected using a USB Hub is

not detected, connect it to

the USB port on the TV

directly

Connect the external power

source if your USB is needed.

An external audio device that

supports SIMPLINK and ARC

must be connected using

HDMI IN eARC/ARC port

When connected with a

high-speed HDMI cable, the

external audio device that

supports ARC outputs SPDIF

audio without additional audio

cable and supports the

SIMPLINK function

ARC (Audio Return Channel)

Some USB Hubs may not

work, if a USB device con-

nected using a USB Hub is

not detected, connect it to

the USB port on the TV

directly

Connect the external power

source if your USB is needed.
