LG SMART TV Manuale utente

User Quick Guide

Network Connection

Network ConnectionNetwork Connection

* Image shown may differ from your TV.

* Image shown on a PC or mobile phone may vary depending on the Operating System (OS).

Wireless Network Connection

Network Connection

Network ConnectionNetwork Connection

* Image shown may differ from your TV.

* Image shown on a PC or mobile phone may vary depending on the Operating System (OS).

SMART TV Quick Setup Guide

Wireless Network Connection

Wireless AP

(Router)

Wired Network Connection

Wired router

Internet connection

On-Screen Remote

To use the Universal Control function (It may not be available depending upon the country/model.)

With the Magic Remote Control, you can easily control your set-top box, Blu-ray player, home theater system, and Sound Bar.

1 Check if the device is connected to the TV.

2 After pressing the ‘ ’ button on the Magic Remote

Control, select the device you want to control in the Change

Device tab.

The Screen Remote that can control the device appears.

3 You can control external devices using the Screen Remote

on the screen.

(This may not work with the ‘ ’ button for some models.)

SMART TV Quick Setup Guide

To use the Universal Control function (It may not be available depending upon the country/model.)

With the Magic Remote Control, you can easily control your set-top box, Blu-ray player, home theater system, and Sound Bar.

You can control external devices using the Screen Remote

on the screen.

(This may not work with the ‘ ’ button for some models.)

4 Control external devices using the navigation keys,

(Wheel), or (Back) button on the Magic Remote

Control.

Change Device tab

Device control buttons

Expand the ScreenRemote

Exits the Screen Remote

Moves the position of the

Screen Remote to left or right

Network Setting

1 Press the SMART button to

access the Smart HOME menu.

Select Settings and press

(Wheel).

Settings

2 Select the NETWORK

Network Connection

menu.

Network Connection

Network Status

Wi-Fi Direct

MiracastTM / Intel’s WiDi

My TV Name : NETCAST4

NETWORK

3 Select the Start Connection.

Connect to your wired or wireless network.

Enjoy various Smart TV features through network.

To connect to a wired network:

Connect a LAN cable to the back of TV.

To connect to a wireless network:

Requires a wireless router or access point.

Start Connection

Network Connection

4 The device automatically tries to connect to the network available (wired

network first).

If you select Cancel or it fails to

connect to the network, the network list

available is displayed.

Choose the network you wish to use.

SMART TV Quick Setup Guide

Select the Start Connection.

4 The device automatically tries to connect to the network available (wired

network first).

If you select Cancel or it fails to

connect to the network, the network list

available is displayed.

Choose the network you wish to use.

For wireless AP (Router) that have

the symbol, you need to enter the

security key.

5 The connected network is displayed.

Select Complete to confirm the network

connection.

If you select the Other Network List, the

available network list is displayed again.

Cancel

Connecting to the network.

Network Connection

Wireless : guusuzin

Enter security key of network.

Forgot your password? Contact your AP manufacturer.

Network Connection

Choose the network you want.

Wired Network

Wireless : Free Wifi zone

Wireless : M Cafe

Wireless : guusuzin

Wireless : KoSH is cool

Wireless : Digital Park

Manual Setup

Refresh List

Network is connected.

Select [Other Network List] to connect to another network.

Network Connection

Wireless : guusuzin

Complete Other Network List

Troubleshooting Network Problems

1 Press the SMART button to

access the Smart HOME menu.

Select Settings and press

(Wheel).

Settings

2 Select the NETWORK

Network Status menu.

Network Connection

Network Status

Wi-Fi Direct

MiracastTM / Intel’s WiDi

My TV Name : NETCAST4

NETWORK

Follow the instructions below that correlate

to your network status.

Check the TV or the AP (Router).

TV Gateway DNS Internet

When an appears on TV, but an X on

Gateway.

1 Check the connection status of the TV,

AP (Router) and cable modem.

2 Power off and power on the TV,

AP (Router) and cable modem.

3 If you are using a static IP, enter the IP

directly.

4 Contact internet companies or AP (Router)

companies.

Additional points to check when using a wireless connection

Check the password for the wireless connection in the

AP (Router) settings window.

Change the AP (Router) SSID (network name) or the

wireless channel.

Check the AP (Router) or consult your

Internet service provider.

When an app ears on TV and Gateway, but an X on DNS.

Unplug the power cord of the AP (Router), cable modem

and try to connect after 5 seconds.

Initialize (Reset) the AP (Router) or cable modem.

Contact internet companies or AP (Router) companies.

SMART TV Quick Setup Guide

Follow the instructions below that correlate

to your network status.

Check the TV or the AP (Router).

When an appears on TV, but an X on

Gateway.

1 Check the connection status of the TV,

AP (Router) and cable modem.

2 Power off and power on the TV,

AP (Router) and cable modem.

3 If you are using a static IP, enter the IP

directly.

4 Contact internet companies or AP (Router)

companies.

Additional points to check when using a wireless connection

1 Check the password for the wireless connection in the

AP (Router) settings window.

2 Change the AP (Router) SSID (network name) or the

wireless channel.

Check the AP (Router) or consult your

Internet service provider.

TV Gateway DNS Internet

When an app ears on TV and Gateway, but an X on DNS.

1 Unplug the power cord of the AP (Router), cable modem

and try to connect after 5 seconds.

2 Initialize (Reset) the AP (Router) or cable modem.

3 Contact internet companies or AP (Router) companies.

TV Gateway DNS Internet

When an appears on TV, Gateway and DNS,

but an X on Internet.

1 Unplug the power cord of the AP (Router), cable modem

and try to connect after 5 seconds.

2 Initialize (Reset) the AP (Router) or cable modem.

3 Check that the MAC address of the TV/AP (Router) is

registered with your Internet service provider. (The MAC

address displayed on the right pane of the network status

window should be registered with your Internet service

provider.)

4 Check the AP (Router) manufacturer’s website to make

sure your router has the latest firmware version installed.

WiDi (Wireless Display) Setting

Intel’s WiDi (Wireless Display) technology enables easy and fast connection without wires or internet network for mirrored and dual

monitor display on your TV. You can sit back and experience your favorite movies, videos, photos, online shows, and more in full HD

on your TV with great image clarity and sound.

NOTE

When you connect the TV and laptop, you should set up TV mode for Live TV and external input.

If not, your computer cannot detect LG Smart TV.

1 Intel’s WiDi is set to On. Connect your laptop to AP

(Router). (Without AP, it is possible to use this function;

it is recommended to connect to AP.)

Your laptop runs the Intel WiDi ( ) program.

2 It detects LG Smart TVs available, which supports WiDi.

In the list, select the TV you want and click Connect. Enter

the number ( ) shown on the screen into the input field

() on your laptop and then click Continue.

(4-digit number: under WiDi 3.1.29, 8-digit number:

above WiDi 3.5)

The TV screen appears on the laptop screen. The wireless environment may affect the screen display.

If the connection is poor, the Intel WiDi connection may be lost.

* LG TVs do not need to register.

* TV sound setting for Digital Sound Out is set to PCM.

* For more information on Intel WiDi, visit http://intel.com/go/widi.

* On the Intel’s WiDi, WiDi device is not searched. Close the Intel’s WiDi, then search WiDi.

* You can control your PC using the Magic Remote Control.

* Intel’s WiDi laptop is not appeared in the Miracast /WiDi menu in TV network menu.
